UML -202-90
1
2
3
4
5
6
7
8
11 11
Fig. 3.2 Side and Bottom Panels UML -202-90
Reference #
1
2
3
4
5
6
7
8
9
10
11
Bosch Security Systems, Inc.
9
10 10
12 12
13 13
Side Panel
Connector
Video 1 (AV1) IN
Video 1 (AV1) OUT
Video 2 (AV2) IN
Video 2 (AV2) OUT
S-Video (Y/C) IN
S-Video (Y/C) OUT
Audio IN (AV1, S-Video)
Audio OUT (AV1,
S-Video)
Audio IN (AV2)
Audio OUT (AV2)
12 V Adaptor
Instruction Manual
15 16 15 16 18 18
14 14 17 17
Bottom Panel
Reference # Connector
12 HDMI IN
13 DVI IN
14 D-SUB IN
15 PC Stereo IN
16 Audio OUT
17 Component Y, Pb, Pr
and Sound L, R
18 DC 12 V IN
F01U076723 | 1.0 | 2007.09
Exploded View | en 11
