QUICK START GUIDE
60 GHz cnWave™
System Release 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the cnWave V1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cambium Networks cnWave V1000

Summary of Contents for Cambium Networks cnWave V1000

  • Page 1 QUICK START GUIDE 60 GHz cnWave™ System Release 1.1...
  • Page 2 Accuracy     While reasonable efforts have been made to assure the accuracy of this document, Cambium Networks assumes no liability resulting from any inaccuracies or omissions in this document, or from use of the information obtained herein. Cambium reserves the right to make changes to any products described...

  • Page 3: Table Of Contents

    60 GHz cnWave™ V3000/V5000 Connecting 60 GHz cnWave™ Products Installing PSU and powering the ODU Installing the 60W DC power injector Installing the AC/DC PSU Installing the V1000 power injector Operation Theory of operation Configuration and Alignment Nodes deployment Glossary Cambium Networks...

  • Page 4: Introduction

    Introduction Thank you for purchasing Cambium Networks 60 GHz cnWave™ platform equipment. This Quick Start Guide assists operators in acquiring a high-level understanding of the 60 GHz cnWave™ platform hardware, installation methods, initial login procedures, and safety/warranty information.  Introduction...

  • Page 5: Product Description

    Product Description Cambium Networks’ 60 GHz cnWave™ solution provides easy, fast, and cost- effective wireless Gigabit connectivity for edge access and/or high-capacity backhaul for edge access solutions at a significantly lower TCO than fiber infrastructure. Service providers and enterprises now have access to Gigabit for business and residential connectivity, backhaul for Wi-Fi access.

  • Page 6: Installation And Operation

    Installation following Cambium Networks instructions Confirming that the equipment settings are compliant with national or regional regulations Familiarity with training material available on the Cambium Networks website. Observe the important instructions below during installation. This sets the equipment in compliance with national regulatory regulations and ensure legal operation.

  • Page 7: Product Safety Information

    To prevent loss of life or physical injury, observe the following safety guidelines. In no event shall Cambium Networks be liable for any injury or damage caused during the installation of the Cambium 60 GHz cnWave™ radio nodes. Ensure that only qualified personnel install 60 GHz cnWave™...
  • Page 8 antenna. 11. Ensure that personnel is not exposed to unsafe levels of RF energy. The units start to radiate RF energy as soon as they are powered up. Never work in front of the antenna when the radio is powered. Install the radios to provide and maintain the minimum separation distances from all persons.

  • Page 9: Hardware Overview

    Hardware Overview .The 60 GHz cnWave™ solution includes three types of wireless nodes: V1000 Client Node V3000 Client Node (Choice of two antenna sizes 40.5 dBi or 44.5 dBi) V5000 Distribution Node V1000 Client Node Figure 1: V1000 Client Node V1000 wall and pole mount (C000000L136A and C000000L137A) The V1000 CN is supplied with a mounting plate and band clamp.

  • Page 10: V3000 Client Node

    Figure 3: V1000 adjustable pole mount V3000 Client Node V3000 Client Node with CN antenna (Choice of two antenna sizes 40.5 dBi or 44.5 dBi) Figure 4: V3000 precision bracket (C000000L125A) The precision bracket (Precision bracket figure below) is used to mount the V3000 CN on a vertical pole with diameter in the range 25 mm to 80 mm (0.98 inches to 3.14 inches).
  • Page 11 V3000 precision bracket (C000000L125A) Figure 5: V3000 precision bracket components Azimuth arm Bracket body Bracket base Long (120 mm) M8 screws and flange nuts V3000 mount 40 mm M8 screws, plain washers and Nyloc nuts Hardware Overview...

  • Page 12: V5000 Distribution Node

    28 mm M6 screws, M8 spacers and pole mount clamp V3000 tilt bracket (N000045L002A) The tilt bracket (Tilt bracket assembly figure below) is used to provide elevation adjustment when a V3000 CN or V5000 DN is mounted on a pole. The tilt bracket works with poles with diameter in the range 25 mm to 80 mm (0.98 inches to 3.14 inches).

  • Page 13: Mounting Of 60 Ghz Cnwave™ Products

    V5000 pole mount (C000000L137A) The Pole Mount (Pole mount figure below) is used to mount a V5000 DN on a vertical pole with diameter in the range 25 mm to 80 mm (0.98 inches to 3.14 inches). It provides coarse azimuth (but not elevation) adjustment.
  • Page 14 1. Insert the hose clamps through mounting plate and clamp to the pole by applying 3.0 Nm torque. 2. Insert the radio into the mounting plate on the pole. V1000 wall mount Follow the below instructions to mount V1000 to the wall: 1.

  • Page 15: 60 Ghz Cnwave™ V3000/V5000

    Adjustable pole mount Follow the below instructions to mount V1000 to the adjustable pole: 1. Insert the hose clamps through the adjustable pole mount bracket and clamp to the pole by applying 3.0 Nm torque. 2. Insert the radio into the adjustable pole mount bracket on the pole. V1000 alignment The V1000 CN requires minimal effort to align as the internal antenna can beam steer +/- 45 degrees in azimuth and +/- 20 degrees in elevation from boresight.
  • Page 16 1. Insert two of the long (120 mm) screws through the azimuth arm and the bracket body. The screws locate in the slots in the azimuth arm. 2. Fit two flanged M8 nuts to the long screws on the back of the bracket. Tighten using a 13 mm spanner.
  • Page 17 Ensure that the pivot pin in the elevation adjuster is located in the circular hole in the V3000 mount. 4. Fit plain washers and M8 Nyloc nuts to the screws on the back of the bracket base. Tighten using a 13 mm spanner.
  • Page 18 Ensure that the pivot pin in the azimuth adjuster is located in the circular hole in the bracket body. 6. Fit three sets of spacers, plain washers and M8 Nyloc nuts to the screws on the underside of the bracket base. Tighten using a 13 mm spanner. 7.
  • Page 19 8. Attach the precision bracket to the pole using the clamp and the remaining flanged nuts. Adjust azimuth approximately and tighten the nuts to 10 Nm (7.4 lbft) using a 13 mm spanner. 9. Lock the antenna alignment by tightening the five Nyloc nuts (see step 5 step 8) to 10 Nm (7.4...
  • Page 20 Precision bracket alignment telescope Follow the below instructions to align the telescope: 1. Attach the telescope mount to the V3000 radio using the knurled screw. 2. Attach the telescope by looping the two elastic O-rings over the ears of the mount, ensuring that the telescope is located securely in the mount.
  • Page 21 3. Before starting the mechanical alignment, move the fine elevation adjuster 2/3 of the way across the screw until the unit is sitting at approximately 0 degrees in elevation. 4. Move the fine azimuth adjuster to approximately the center of the available range and lock in position.
  • Page 22 8. While looking for the far node through the site, rotate the fine azimuth adjuster until the alignment is complete in the azimuth plane. One turn of the adjustment wheel is equivalent to approximately one degree of azimuth. Lock the fine azimuth adjuster screws in place. 9.
  • Page 23 3. Thread two of the nuts to the long bolts and tighten against the bracket body using a 13 mm spanner. Fit the bracket strap and thread the remaining nuts onto the long bolts. 4. Fix the assembled bracket body to the pole, adjust the azimuth angle, and tighten the nuts to a torque setting of 10.0 Nm (7.4 lb-ft) using a 13 mm spanner, ensuring that the arrow in the body is pointing upwards.
  • Page 24 V3000/V5000 tilt bracket assembly with band clamps Follow the below instructions to assemble the tilt bracket with band clamps: 1. Follow Step 1 of the V3000 tilt bracket assembly procedure. 2. Feed the band clamps through the slots in the bracket body. Secure the bracket body to the pole using band clamps (not supplied by Cambium), ensuring that the arrow in the body is pointing upwards.
  • Page 25 V5000 pole mount bracket 1. Pass the long screws through the bracket body. The screws locate in the recess in the bracket. 2. Fit two flanged nuts to the long screws on the back of the bracket. Tighten using a 13 mm spanner. 3.
  • Page 26 V5000 wall mount bracket 1. Install the mounting plate of the wall mount bracket securely on a vertical wall, using suitable fixings. Note Fixing hardware is not supplied with the wall mount bracket. 2. Fix the bracket body to the back of the radio using the four short M6 bolts, ensuring that the arrow in the plate points towards the top of the radio.

  • Page 27: Connecting 60 Ghz Cnwave™ Products

    Connecting 60 GHz cnWave™ Products Installing PSU and powering the ODU Install one of the following types of PSU: 60W DC power injector AC/DC power supply V1000 power injector Warning Always use an appropriately rated and approved AC supply cord-set in accordance with the regulations of the country of use.

  • Page 28: Installing The 60W Dc Power Injector

    Attention Ne branchez aucun périphérique autre qu'une ODU cnWave ™ 60 GHz dans le port ODU du bloc d'alimentation. D'autres appareils peuvent être endommagés en raison des techniques non standard utilisées pour injecter une alimentation CC dans la connexion Ethernet entre le bloc d'alimentation et l'ODU. Ne branchez aucun périphérique autre qu'un bloc d'alimentation cnWave ™...

  • Page 29: Installing The Ac/Dc Psu

    Installing the AC/DC PSU Connect the Input side of the AC/DC PSU to the AC power line. Connect the Output side of DC PSU to ODU through cable joiner and DC mini adapter. Figure 3: AC/DC PSU (N000000L179B) AC/DC powering diagram Figure 4: Connecting 60 GHz cnWave™...

  • Page 30: Installing The V1000 Power Injector

    Installing the V1000 power injector Connect the 56V Gigabit Data + Power port to ODU and Gigabit Data port to the network equipment. Figure 5: V1000 power injector V1000 powering diagram Figure 6: Connecting 60 GHz cnWave™ Products...

  • Page 31: Operation

    Operation Theory of operation 60 GHz cnWave™ devices support Facebook connectivity Technology called Terragraph. cnWave™ devices implement IEEE 802.11ay WLAN standard and use 60GHz frequency band for wider spectrum and higher capacity. cnWave™ devices can provide multi-gigabit throughput from 100M to 1.5 KM. Deployment of the devices use Open/R based layer3/IPv6 Mesh for efficient distribution of traffic between the nodes and higher availability of the traffic.

  • Page 32: Configuration And Alignment

    Configuration and Alignment All configurations are done on the E2E except for the initial configuration to connect the PoP DN to the E2E. The configuration parameters are: PoP/DN/CN Nodes deployment The configuration of cnWave™ nodes is handled automatically by the E2E service. However, the first PoP node must be configured manually since connectivity to the E2E controller has not yet been established.

  • Page 33: Glossary

    Glossary Term Definition Client Node Distribution Node E2E Controller End to End Controller Glossary...

  • Page 34: Cambium Networks

    Devon, TQ13 7UP, United Kingdom. www.cambiumnetworks.com Cambium Networks and the stylized circular logo are trademarks of Cambium Networks, Ltd. All other trademarks are the property of their respective owners. © Copyright 2021 Cambium Networks, Ltd. All rights reserved. Cambium Networks...
