Single Zone Controller - LR-TW
The single zone Tunable white controller enables control of the tunable
white LED Strip lighting. This remote allows the user to access 3 pre-set
lighting levels from the touch of a button and adjust the lighting levels
with smooth dimming (5%-100%) via the touch sensitive wheel.
* 5%-100% Smooth Dimming
* Touch sensitive remote & colour Wheel
* 20 Automatic Play modes to choose from
* Remote and receiver supplied together as
standard
PART NO.
Remote
LR-TW
PART NO.
Reciever
LRR-TW
52mm
Feature
Parameter
INPUT
VOLTAGE
3.6VDC
INPUT
VOLTAGE
12-24VDC
Produc t Size
110mm
page 1
* Last settings memory function when powered On
* Dimming & colour changing
* Wireless RF range of 10 - 20 meters (Dependent
on signal obstacles within the installation area)
OPERATION
DIMENSIONS
FREQUENCY
2.4GHZ
52x110x20
CURRENT
2x6A
2x(72-144)W
REMARKS
(mm)
2xAAA
BATTERIES
OUTPUT
REMARKS
Receiver
20mm
RF
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TEUCER LR-TW
Summary of Contents for TEUCER LR-TW
- Page 1 Single Zone Controller - LR-TW The single zone Tunable white controller enables control of the tunable white LED Strip lighting. This remote allows the user to access 3 pre-set lighting levels from the touch of a button and adjust the lighting levels with smooth dimming (5%-100%) via the touch sensitive wheel.
- Page 2 Controller Layout High Brightness Medium Brightness ON Button OFF Button Brightness low High Brightness Warm White colour temperature Low Brightness White colour temperature RF technology allows for great flexibility when it comes to controlling simple or complex lighting installations without the need of wiring. There are limitations in some cases due to receivers installed in enclosed electrical boxes or in ceiling voids hence reducing the RF signal strength and the communication range.
- Page 3 Synchronising The Remote To Receiver Please Note: All controllers & receivers sold in a pack are pre-synchronised. There is no need to sync the remote to the receiver. *Only follow the instructions below if you are adding another receiver with the same remote NOTE: Steps 2 &...
- Page 4 * Never install product whilst connected to power and double check connections before switching on to avoid short circuits. * For any further help or advice please contact Teucer on 0207 350 4429 or find us online at www.teucerled.co.uk Warran ty Agreemen t * 3 Year Warranty: This warranty is for free repair and replacement of the product and covers manufacturing faults only.
