SmoothTalker BTEUX430 Manual

Remote Area Booster RX and
Coverage TX Network Friendly
Made in
Canada
Fabriqué au
Canada
1-877-726-3444
Approved Equipment List
Smoothtalker approved accessories most be used with this booster to maintain
warranty.
ANTENNA CABLES
ACX100, ACX900
CBXmaXfe10,20,30,40,50,60
CBNmaNfe10,20,30,40,50,60
CBGmaGfe 10,20,30,40,50,60
ANTENNAS
SEM2, 11, 14, series
SEM2M, 11M, 14M, series
SEM2LGM, 11LGM, 14LGM, 26LGM series
SEM2LGML 11LGML, 14LGML, 26LGML series
SEM2TH, 11TH, 14TH, 26TH series
SEM2THL, 11THL, 14THL, 26THL series
SEMTHMM series
SEMTHPB series
SEMRP1X , SEMRP1XL
SRBL series
SEMD1 series
SEMDA2 series
SEMO series
SEMDP1 series
SEMDY series
SEMDYD series
5
Multiple Users Increase Data Speeds
up to 30 times
Automatic power
stealth
control protects the
tech
®
Mobile Network
Smoothtalker.com
Gwelectronics.se
COUPLING HOLDERS
BTH Series
Mobile CX4 4G LTE
Coupling Cradle Connect Cellular
Signal Booster - Extreme Power
User Manual
Cellular
RX/TX 30dB 4 BAND
Signal Booster
MULTI BAND 30dB
Connect
CRADLE TYPE
Extreme Power
2G, 3G, 3G+, 4G, 4G+
GSM,HSPA,CDMA,LTE, LTE A
Band 20 800MHz
Band 8 900MHz
Band 3 1800MHz
Band 1 2100MHz
1-877-726-3444
Installation
1) Connect the outside antenna to the side of the booster marked as
"outside antenna. "
Connect the inside antenna to the side of the booster marked as "inside antenna. "
2) Placement
Placement: Place the outside antenna in the middle of the vehicle roof. If the
vehicle has a sunroof please place the antenna on the roof towards the back
window. Place the Patch(inside) antenna in desired location. For cars and trucks
the console between the front seats is recommended. Connect the booster as
shown in Fig.1 & 2 on Pg. 1 or Fig. 3 on Pg. 4.
Important: Use only the power supply included with the booster. Connecting
another power supply at any time will result in damage to the booster and will
void the warranty. Do not turn on the power switch until ALL cables have been
screwed or plugged into the booster or you can cause damage to the booster.
The Mobile CX4
Can easily be moved from vehicle to vehicle
4 BAND
MULTI BAND
Vehicle
30dB
BTEUX430
stealth
tech
®
POWER 12V DC CLA or 12V DC FUSED
SUPPLY or 220V AC/DC
Weight 0.249 kg
Smoothtalker.com
2
