Black Box PSE518MA Quick Start Manual

3/ Controlling the power outlet over IP
After configuring the network parameters, start your browser and enter the address of
your Power Switch beginning with https:// to establish a secure connection.
To configure the Secure Power Switch you must
log in as administrator and type in the IP address of
the Secure Power Switch followed
/sysadmin.htm. The browser then displays the
authentication dialog box and you will now have to
type in the administrator name and password.
Both default administrator name and password are:
admin
Example: https://192.168.100.200/sysadmin.htm
To take full control of your Power Switch
(controlling all power outlets,
temperature...) you must log in as administrator and
simply type in the IP address of the Power Switch.
Example: https://192.168.100.200
The Secure Power Switch ONLY uses Secure Port 443 (HTTPS).
Ensure that your Firewall / Router is configured to allow HTTPS to pass through.
The establishment of a secure SSL session takes a bit longer to start up.
The following procedure is used:
1. Your Web browser contacts the Secure Power Switch server using a secure URL (starts with
https://).
2. The Power Switch server sends the browser its 1024-bit public key and its server certificate.
3. Your browser and the server negotiate the encryption level to use for the communications.
4. Your browser encrypts a 128-bit session key with the public key of the Secure Power Switch
server and sends the encrypted data back to the Secure Power Switch server.
5. The Secure Power Switch server decrypts the message sent by the client using its private key
and the session is established.
6. Your browser and the Secure Power Switch server use the session key to encrypt and decrypt
transmitted data.
by
reading
© Copyright 2007
Black Box Corporation
All rights reserved
Secure Power Switch
Master 8 - Port
Quick Start Guide
Detailed information can be found in the
User Guide on the provided CD-ROM
PSE518MA is an enhanced power distribution and control unit that enables
remote power management of 8 devices (extendable up to 136) over Internet.
This high security device supports the HTTPS protocol and also includes IP
device and environmental monitoring functionalities. It supports the HTTP,
HTTPS, DHCP, Syslog, SNMP, SMTP and SNTP protocols.
An internal clock allows to timestamp syslog messages, e-mails and internal
logs.
Before operating your Power Switch, please read the safety
instructions in the User Guide on the provided CD-ROM.
1/ Installation
Connect the Power Switch to your Local Area Network
Power-up the Power Switch through a properly grounded outlet
SUPPORT FREE technical support
January 2007
PSE518MA
