TECH NOTES
F-1000 Series Turbine Flow Meters
MAINTENANCE AND CLEANING

MAINTENANCE OVERVIEW

In clean, closed loop flow applications, turbine flow meters should
not require frequent maintenance. A suggested interval for
inspection and/or replacement of components is dependent upon
flow velocity, run time, and water quality. With 24-hour service,
visual inspection of the meter after five years has proven to be a
conservative approach to preventative maintenance.
In applications which contain more dirt or debris, the flow meter
should be inspected at regular intervals to determine the amount
and type of dirt buildup on the turbine assembly. Based on
the results of these inspections, a regular cleaning interval and
Procedure can be developed.

AVAILABLE FACTORY SERVICE

ONICON offers factory cleaning and recalibration services for F-1000 Series flow meters.
Basic Maintenance and Calibration service includes the following:
• Disassembly, cleaning and inspection of the meter's turbine assembly
• Replacement of turbines, bearings, shafts and o-rings
• Inspection and testing of circuit boards and wiring
• N.I.S.T* traceable Flow Meter Certification of Calibration
Advanced Maintenance and Calibration service includes the above and:
• Replacement of circuit boards, if required
• Replacement of flow meter stem, if required
For pricing information, to schedule a service, or obtain a Return Authorization Number, please contact ONICON Service
Department at (727) 447-6140 or service@onicon.com.
*National Institute of Standards and Technology
DOC-0003721
ONICON
Rev.A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F-1000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Onicon F-1000 Series

Summary of Contents for Onicon F-1000 Series

  • Page 1 • Replacement of circuit boards, if required • Replacement of flow meter stem, if required For pricing information, to schedule a service, or obtain a Return Authorization Number, please contact ONICON Service Department at (727) 447-6140 or service@onicon.com. *National Institute of Standards and Technology DOC-0003721 Rev.A...
  • Page 2 IMPORTANT NOTE Disassembly of the turbine is not recommended. If the turbine assembly cannot be cleaned without disassembly, please contact ONICON to obtain a Return Authorization for cleaning and maintenance service. For light debris and low scale build up: 1. Carefully remove the flow meter from the pipe, slide the hot tap adapter up to allow room for cleaning.
  • Page 3 Cleaning should be done without removing the turbine assembly from the meter body. If the turbine assembly needs to be removed, please contact ONICON for assistance. 1. Use a flashlight to visually inspect the turbine for debris, dirt or damage.
  • Page 4 F-1000 Series Turbine Flow Meters MAINTENANCE AND CLEANING F - 1134 AND F - 1101 INLINE STYLE METERS ( CONTINUED ) ends of the turbines, exposed bearings & shaft, and the turbine support brackets. • Use a wire brush to clean pipe dope or thread tape out of the body threads and flush with water to rinse.
