Blodgett CB24-140G Specifications

CB-G
Gas Steam Boiler
CB-36G shown
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Foot Options
Front flanged feet
Rear flanged feet
Pressure reducing valve
Stainless steel rear panel
Stainless steel frame
Steam take off kit
Water in "Y" strainer
Ball float trap
208-240VAC operation (specify voltage)
Correctional package
One year extended warranty
Project
Item No.
Quantity
CONSTRUCTION
OPERATION
STANDARD FEATURES
*
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: (800) 331-5842 • Phone: (802) 860-3700 • Fax: (802) 864-0183
Model CB24-140G ( 24" wide 140,000 BTU gas boiler base cabinet)
Model CB24-200G ( 24" wide 200,000 BTU gas boiler base cabinet)
Model CB36-140G ( 36" wide 140,000 BTU gas boiler base cabinet)
Model CB36-200G ( 36" wide 200,000 BTU gas boiler base cabinet)
Model CB36-250G ( 36" wide 250,000 BTU gas boiler base cabinet)
Model CB36-300G ( 36" wide 300,000 BTU gas boiler base cabinet)
Full perimeter painted angle iron frame
Reinforced counter and boiler mountings
Stainless steel exterior
Hinged door(s) with magnetic latch
6" (152 mm) stainless steel legs with adjustable bullet feet on front and
adjustable flanged feet on rear
All piping is confined within cabinet
Automatic water level control
Automatic boiler blowdown
Pressure gauge
Water gauge glass
Pressure control with pressure safety control
Safety relief valve
Cathodic protector
On/Off switch with indicator light
CSD-1 secondary low water cut off
Gas operated steam boiler rated at 15 PSI (103 kPa) operating on
115VAC
Electronic ignition
Split water lines
One year parts and labor warranty*
For all international markets, contact your local distributor.
BLODGETT
