ORiNG TGRST120-M12X-BP2-WV Quick Installation Manual

EN50155
Switch
Q I
I N D U S T R I A L
uick nstallation
Introduction
ORing's Transporter T M series managed Router switches are designed for
industrial applications such as rolling stock, vehicle, and railway. The TGRS-
T120-M12X-BP2-WV, which is compliant with the EN50155 standard, is a
m a n a g e d G i g a b i t R e d u n d a n t R i n g E t h e r n e t s w i t c h w i t h
12x10/100/1000Base-T(X) ports which is specifically designed for the
toughest and fully compliant with EN50155 requirement. The switch support
IEC 61375-2-5 TTDP (Train Topology Discovery Protocol) and
TRDP (Train Real-Time Data Protocol) for railway application, improving the
operational efficiency and minimize configuration errors. It is specifically
designed for the toughest industrial environments. TGRS-T120-M12X-BP2-
WV EN50155 Ethernet switch uses M12 connectors to ensure tight, robust
connections, and guarantee reliable operation against environmental
disturbances, such as vibration and shock. TGRS-T120-M12X-BP2-WV
EN50155 provides a wide power input range from 24 to 110VDC. TGRS-T120-
M12X-BP2-WV includes 2 sets of bypass ports that protect the network from
failures and Network maintenance by ensuring network integrity during power
loss. And support wide operating temperature from -25 C to 70 C.
T120-M12X-BP2-WV can also be managed centralized and convenient by
Open-Vision, as well as the Web-based interface, Telnet and console (CLI)
configuration. Therefore, the router switch is one of the most reliable choice
for highly-managed and railway application.
Package Contents
The device is shipped with the following items. If any of these items is
missing or damaged, please contact your customer service representative
for assistance.
Contents Pictures
TGRS-T120-M12X-BP2-WV
QIG
Preparation
Before you begin installing the device, make sure you have all of the package
contents available and a PC with Microsoft Internet Explorer 6.0 or later, for
using web-based system management tools.
Safety & Warnings
Elevated Operating Ambient: If installed in a closed environment, make sure
the operating ambient temperature is compatible with the maximum
ambient temperature (Tma) specified by the manufacturer.
Reduced Air Flow: Make sure the amount of air flow required for safe operation
of the equipment is not compromised during installation.
Mechanical Loading: Make sure the mounting of the equipment is not in a
hazardous condition due to uneven mechanical loading.
Circuit Overloading: Consideration should be given to the connection of the
equipment to the supply circuit and the effect that overloading of the circuits
might have on overcurrent protection and supply wiring. Appropriate
consideration of equipment nameplate ratings should be used when addressing
this concern.
Q I G
TGRS-T120-M12X-BP2-WV
TGRS-T120-M12X-BP2-WV
G
uide
Dimension Unit =mm (Tolerance ±0.5mm)
Reset
TGRS-T120-M12X-BP2-WV
PWR Status R.M. Ring Fault
Speed
LNK/ACT
G4 G8 G12
G3 G7 G11
G2 G6 G10
G1 G5 G9
IEC 61375-2-3 LNK/ACT Speed
RXD TXD
RSVD GND
RS-232, 115200bps, 8, N, 1
Console
Relay
3A@24VDC
Relay Output
N.C.
V+ V-
Power
24-110VDC
o o
TGRS-
Panel Layouts
Front View
6
Reset
TGRS-T120-M12X-BP2-WV
PWR Status R.M. Ring Fault
1
LNK/ACT Speed
2 3 4 5
9 G4 G8 G12 10
G3 G7 G11
G2 G6 G10
Number G1 G5 G9
LNK/ACT Speed
RXD TXD
11
N.C.
RSVD GND
RS-232, 115200bps, 8, N, 1
Console
1
12 Relay
N.C.
3A@24VDC
Relay Output
N.C.
13 N.C.
V+ V-
1
Power
24-110VDC
Installation
Wall-mount
The device can be fixed to the wall. Follow the steps below to install the device on the wall.
Step 1: Hold the d
Step 2: Insert four screws through the large opening of the keyhole-shaped apertures at the
top and bottom of the unit and fasten the screws to the wall with a screwdriver.
Step 3: Slide the d
1907-200-XX
1 BI_DA+
2 BI_DA-
3 BI_DB+ 4 5
4 BI_DB- 3 6
5 BI_DD+ 2 7
6 BI_DD- 1 8
7 BI_DC-
8 BI_DC+
G1~G12
G4 G8 G12 Power
Failure
Bypass
N.C.
G3 G7 G11
N.C.
G2 G6 G10
Power
Failure
Bypass
N.C.
G1 G5 G9
7 8
1. Power status LED
2. System status LED
1 BI_DA+
2 BI_DA-
4 5
3 BI_DB+ 3. R.M. status LED
4 BI_DB- 3 6
5 BI_DD+
2 7
6 BI_DD-
7 BI_DC- 1 8
8 BI_DC+
4. Ring status LED
G1~G12
5. Fault LED
6. Reset button
G4 G8 G12 Power
Failure
Bypass 7. Ethernet LAN ports
8. Ethernet WAN ports with bypass
9. Link/ACT LED for Gigabit ports
G3 G7 G11
10. Speed LED for Gigabit ports
11. Console port
G2 G6 G10
Power 12. Relay output
Failure
Bypass
13. Power connector
G1 G5 G9
evice upright against the wall
evice downwards and tighten the four screws for added stability.
Instead of screwing the screws in all the way, it is advised to
leave a space of about 2mm to allow room for sliding the
switch between the wall and the screws.
PRINTED ON RECYCLED PAPER
EN50155 managed router switch
Wiring
For pin assignments of power, console and relay output ports, please refer to the following tables.
Grounding
Grounding and wire routing help limit the effects of noise due to electromagnetic interference
(EMI). Run the ground connection from the grounding pin on the power connector to the grounding
surface prior to connecting devices.
Power port pinouts
The device supports one set of power supply and uses the M12 A-coded
5-pin male connector on the front panel for power input.
Step 1: Insert a power cable to the power connector on the device.
Step 2: Rotate the outer ring of the cable connector until a snug fit is
achieved. Make sure the connection is tight.
Console port pinouts
RXD TXD
N.C.
N.C. GND
RS-232, 115200bps, 8, N, 1
Relay output port pinouts
The switch uses the M12 A-coded 5-pin female connector
on the front panel for relay output. Use a cable with an M12
A-coded 5-pin male connector to connect the relay. The
relay contacts will detect user-configured events and form
an close circuit when an event is triggered.
Network Connection
The switch has twenty 10/100/1000Base-T(X) Ethernet ports in the form of M12 connector.
Depending on the link type, the switch uses CAT 3, 4, 5,5e UTP cables to connect to network
devices (PCs, servers, switches, routers, or hubs). Please refer to the following table for cable
specifications.
Cable Type Max. Length Connector
8-pin female M12
10BASE-T Cat. 3, 4, 5 100-ohm UTP 100 m (328 ft)
X-coding connector
8-pin female M12
100BASE-TX Cat. 5 100-ohm UTP UTP 100 m (328 ft)
X-coding connector
8-pin female M12
1000BASE-T Cat. 5/Cat. 5e 100-ohm UTP UTP 100 m (328 ft)
X-coding connector
For pin assignments of the Ethernet ports, please refer to the following tables.
4 5
10/100/1000Base-T(X) M12 X-coding
3 6
Pin No. Pin Definition
7
2
1 8 #1 BI_DA+
#2 BI_DA-
#3 BI_DB+
#4 BI_DB-
#5 BI_DD+
#6 BI_DD-
#7 BI_DC-
#8 BI_DC+
Quick Installation Guide
Version 1.0
N.C.
N.C.
V+ V-
Relay
N.C.
3A@24VDC
