MKX10 & HX10
Swing-Away Grain Auger
Assembly Manual
This manual applies to:
Westfield MKX10-53, MKX10-63, MKX10-73, MKX10-83
Hutchinson HX10-53
Mayrath HX10-53
Read this manual before using product. Failure to
follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
Part Number: 30908 R4
Revised: May 2021
Original Instructions
