Service-Management
Service Manual
Challenge 600 A CD SR
Inhaltsverzeichnis
D
Abgleichvorschriften .............................. 2 ... 3
Druckplattenabbildungen ..................... 5 ... 22
Bauteilhinweise .............................................................................. 5
Schaltpläne
CD-Teil ........................................................................................ 6
HF-Teil ........................................................................................ 7
Prozessor-Teil ........................................................................... 11
NF-Teil ...................................................................................... 15
Druckplattenabbildungen ............................................................. 19
Ersatzteilliste ....................................... 23 ... 24
Zusätzlich erforderliche Unterlagen für den Komplettservice
Additionally required Documents for the Complete Service
Service
Manual
Sicherheit
Safety
Sach-Nr./Part No.
72010 800 0000
All manuals and user guides at all-guides.com
Seite

Table of Contents

GB
Adjustment Procedures .......................... 3 ... 4
and Layout of PCBs .............................. 5 ... 22
Notes on Components ................................................................... 5
Circuit Diagrams
CD Part ....................................................................................... 6
RF Part ....................................................................................... 7
Processor Part .......................................................................... 11
AF Part ...................................................................................... 15
Layout of PCBs ............................................................................ 19
Spare Parts List ................................... 23 ... 24
Dieses Service Manual ist nur in Datenform verfügbar
This Service Manual is only available as data
Änderungen vorbehalten
Subject to alteration
Made by GRUNDIG in Germany
E-BS 36 0999
