Schlage EncodePlus Manual

Smart wifi deadbolt
Hide thumbs

Advertisement

Table of Contents

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EncodePlus and is the answer not in the manual?

Questions and answers

Sam Coulter
May 17, 2025

Door bolt not responding to set up code

0

Subscribe to Our Youtube Channel

Related Manuals for Schlage EncodePlus

Summary of Contents for Schlage EncodePlus

  • Page 2 Parts Backup Backplate Battery Touchscreen Cover Assembly Inside Assembly Bolt Strike and Reinforcement Reinforcement Strike Plate Backplate Reinforcement Screws Screws Bolt/Strike Inside Assembly Screws Screws...

  • Page 3: Start Here

    Start here! Visit for an improved alle.co/encodeplus installation experience. Access online interactive instructions, warranty, and reference information. alle.co/encodeplus...
  • Page 4 Touchscreen Programming and Input Communication Icon • Flashes when lock is connecting to WiFi to check for updates. • Amber when using manual programming mode. Low Battery Icon • Flashes after code is entered Home Button and when battery is low. Checkmark Icon •...
  • Page 5 Don’t use a power drill! step Remove existing lock. Remove the entire deadbolt, including the bolt. You may also want to remove the strike. A standard Schlage deadbolt is shown. Check with your specific deadbolt manufacturer if you need help.

  • Page 6: Need Help

    Need Help? alle.co/encodeplus Visit Install the bolt. You may have to adjust your bolt length. Make sure the slot in the bolt is centered in the hole. Slot is Make sure the centered word “TOP” is in the hole.
  • Page 7 Trouble installing the strike reinforcer? Visit alle.co/encodeplus Install the strike into the door frame. If you have a window next to your door, you may not be able to use the longer wood screws to install the strike. Do not reuse existing strike for proper operation.
  • Page 8 Is the tailpiece not installing correctly? If your through hole seems too small, you may need to remove the spacer. Visit alle.co/encodeplus. Install the touchscreen. Route the cable through the door BELOW the bolt. Align the tailpiece as shown and push the touchscreen onto the door.
  • Page 9 step Phillips screwdriver Don’t use a power drill! You may damage your lock! Install the backplate. Route the cable under the bolt and through the hole on the bottom of the backplate. Secure the backplate with screws. Make sure the outside touchscreen is straight before tightening screws all the way.

  • Page 10: Connect The Cable

    step Connect the cable. Tuck the cable and connector in the space above the spindle.
  • Page 11 step Phillips screwdriver Don’t use a power drill! You may damage your lock! Secure the lock to the door. If the bump on the tailpiece doesn’t align with the slot in the back of the inside assembly, make sure your thumbturn is vertical (up and down).
  • Page 12 step Install batteries and slide the cover on. Pull out battery Install holder. batteries. Reinstall battery holder. Turn the battery holder around so the batteries face the door.

  • Page 13: Final Test

    If the bolt 3. Make sure the bolt retracts doesn’t smoothly. extend or 4. Open your door. retract during testing,visit 5. Extend the bolt using the alle.co/ inside thumbturn. encodeplus. 6. Now enter a user code at the touchscreen.
  • Page 14 Now that your lock is installed you can use the Schlage Home app to lock and unlock your door from anywhere and add codes for guests and household members.
  • Page 15 Or set it up using the Apple Home app For iPhone XS and newer, simply press the button on the lock, then tap your phone to the label. For older models, turn the page.
  • Page 16 Older than iPhone XS Press the button on your lock Remove battery cover and press the button. Your lock will be in pairing mode for 5 minutes. Open the Apple Home app Press “+” and Add Accessory. Follow directions on your phone. Note: Your lock must be fully installed on door with batteries before pairing with an app.
  • Page 17 For iPhone 7 - iPhone X Tap your iPhone to the HomeKit label Tap the top of your phone to the label. Follow directions on your phone. For older than iPhone 7 or iPad These are your backup codes. Scan the label PLACE LABEL You will need these codes if you HERE...

  • Page 18: Lock And Unlock

    Lock and unlock To lock your door just tap the lock icon. You can also lock your door from inside by turning the thumbturn toward the door edge. To unlock your door enter a user code. Once paired with a smart home system, the default codes will not work.

  • Page 19: Apple Homekit

    Apple HomeKit Apple HomeKit technology provides an easy, secure way to control your home’s doors and more using the Apple Home app and Siri on your iPhone, iPad, Apple Watch, HomePod, or Mac. A customer who owns an Apple TV (4th generation or later) with tvOS 10 or later, an iPad with iOS 10 or later, or a HomePod can control HomeKit-enabled accessories away from home and automatically,...
  • Page 20 You will need these codes if you HERE ever factory default reset your lock. Keep these safe! Questions about your new Please don’t return it to the store! Let us help you first! alle.co/encodeplus *47360452* © Allegion 2021 Printed in U.S.A. 47360452 47360452 Rev. 06/21-c...
