Parts list - Variants

Front mount

Part No.
FR1 Front mount bracket [ALU 15mm]
FR2 Front mount side plate [Left]
FR3 Front mount side plate [Right]
FR4 Bolt - DIN 912 (Black steel, 20mm, M6)
FR5 Bolt - DIN 912 (Black steel, 20mm, M8)
FR6 Bolt - DIN 912 (Black steel, 40mm, M8)
FR7 Spacer - male / female (10mm, M6)
FR8 Corner bracket (40x40)
FR9 Cover cap for connector bracket (40x40)
FR10 Nut (M8, DIN 985 locknut, Galvanised)
FR11 Washer (Black steel, M8, Plain black)
FR12 Slot 8 nut (M8)
FR13 Bolt - DIN 7991 (Black steel, 30mm, M8)
FR14 Bolt - DIN 7991 (Black steel, 25mm, M8)

Wheeldeck plate

Part No.
WH1 Wheeldeck to plate
WH2 Wheeldeck side plate [LEFT]
WH3 Wheeldeck side plate [RIGHT]
WH4 Bolt - DIN 912 (Black steel, 16mm, M8)
WH5 Bolt - DIN 912 (Black steel, 20mm, M8)
WH6 Bolt - DIN 7991 (Black steel, 16mm, M8)
WH7 Bolt - DIN 7991 (Black steel, 25mm, M8)
WH8 Washer (Black steel, M8, Plain black)
WH9 Corner bracket (40x40)
WH10 Cover cap for connector bracket (40x40)
WH11 Nut (M8, DIN 985 locknut, Galvanised)
WH12 Slot 8 nut (M8)

Fanatec Podium mounting bracket

Part No.
DD1 Fanatec DD sidemount base holder [Left]
DD2 Fanatec DD sidemount base holder [Right]
DD3 Fanatec DD sidemount profile holder [Left]
DD4 Fanatec DD sidemount profile holder [Right]
DD5 Profile 40mm slot 8 (Black, 40x80L) - 194mm
DD6 Slot 8 nut (M8)
DD7 Bolt - DIN 7991 (Black steel, 20mm, M8)
DD8 Bolt - DIN 912 (Black steel, 20mm, M8)
DD9 Bolt - DIN 912 (Black steel, 20mm, M6)
DD10 Washer (Black steel, M8, Plain black)
BOX D
Sim Feet (Optional)
Part No.
F1 Leveling feet Diameter 80mm - M16x125
F2 Nut (M16, DIN 934 nut, Galvanised)
F3 Washer (Galvanised, M16, Plain black)
F4 Slot 8 nut (M8)
F5 Bolt - DIN 912 (Black steel, 25mm, M8)
F6 Feet support plate (alu 15mm)
Part name
Part name
Part name
Part name
QTY UoM
1 Units
1 Units
1 Units
4 Units
6 Units
4 Units
4 Units
4 Units
4 Units
12 Units
4 Units
4 Units
4 Units
4 Units
QTY UoM
1 Units
1 Units
1 Units
4 Units
8 Units
2 Units
8 Units
18 Units
4 Units
4 Units
10 Units
10 Units
QTY UoM
1 Units
1 Units
1 Units
1 Units
2 Units
8 Units
8 Units
8 Units
4 Units
8 Units
QTY UoM
4 Units
8 Units
8 Units
8 Units
8 Units
4 Units
Note
Note
Note
Note
11
