CONTROLLER MANUAL
SPINCHILLER C.D.A
Data creazione 10/09/03
DS03I009GB--00
Pagina 1 di 59

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TALK and is the answer not in the manual?

Questions and answers

Related Manuals for CLIVET TALK

Summary of Contents for CLIVET TALK

  • Page 1 CONTROLLER MANUAL SPINCHILLER C.D.A Data creazione 10/09/03 DS03I009GB--00 Pagina 1 di 59...

  • Page 2: Table Of Contents

    SUMMARY CLIVET TALK LOCAL INTERFACE......................... 3 DESCRIPTION OF THE BUTTONS ..........................4 DESCRIPTION OF THE MAIN SCREEN.........................5 SYSTEM COMPOSITION..........................6 CENTRAL MODULE CLIVETTALK.LOCAL.M1.......................6 DESCRIPTION OF THE JUMPERS..........................7 I/O CLIVETTALK.LOCAL.M1 ............................7 EVAPORATOR MODULE CLIVETTALK.LOCAL.EX1 .....................9 DESCRIPTION OF THE JUMPERS..........................9 I/O CLIVETTALK.LOCAL.EX1............................10 TANDEM COMPRESSOR MODULE CLIVETTALK.LOCAL.C2 ..................11 TRIO COMPRESSOR MODULE CLIVETTALK.LOCAL.C3...................11...

  • Page 3: Clivet Talk Local Interface

    CLIVET TALK LOCAL INTERFACE Figure 1 Clivet code C5110612 Figure 1 represents the layout of the control keypad corresponding to the ClivetTalk modular control system. The functions of the buttons and the meaning of the configuration screens are described below.

  • Page 4: Description Of The Buttons

    DESCRIPTION OF THE BUTTONS 15 / 02 / 03 08:03:51 C O O L °C °C STEP: °C 03 / 12 MODE ALARM SETUP STATE HOME NUMBER SYMBOL MEANING LED = on when unit ON LED = off when unit OFF “ON-OFF”...

  • Page 5: Description Of The Main Screen

    DESCRIPTION OF THE MAIN SCREEN 15 / 02 / 03 08:03:51 C O O L °C °C STEP: °C 03 / 12 MODE ALARM SETUP STATE NUMBER SYMBOL MEANING 00/00 No. of steps activated in reference to the no. of steps available Capacity-control steps STEP No alarm active...

  • Page 6: System Composition

    SYSTEM COMPOSITION The Clivet Talk modular system is made up of the following modules, which can communicate with each other over the local network: • Central module (Code = C5110671) • Evaporator module (Code = C5110674) • Trio module(Code = C5110672) •...

  • Page 7: Description Of The Jumpers

    DESCRIPTION OF THE JUMPERS DIP1 To be defined DIP2 Board address for CAN BUS JUMP1 Reset board (jumper for normal operation) JUMP2 programming (jumper for programming) JUMP3 programming (jumper for programming) JUMP4 CAN Bus terminator (jumper for insert terminator) STRIP Programming strip (pin sequence) •...
  • Page 8 Connector Terminal Description Note J17-1 CAN OPEN J17-2 J17-3 J18-1 NTC input, outside air temperature J18-2 10K=25°C J18-3 NTC input, water temperature OUT 1 J18-4 J18-5 NTC input, water temperature IN J18-6 J18-7 +15V 4-20mA 4-20mA input, outside RH% J18-8 J19-1 +15V 4-20mA or 0-10V...

  • Page 9: Evaporator Module Clivettalk.local.ex1

    EVAPORATOR MODULE ClivetTalk.local.ex1 TOut 0-10V STRIP JUMP2 JUMP3 JUMP1 JUMP4 DIP1 DIP2 DESCRIPTION OF THE JUMPERS DIP1 To be defined DIP2 Board address for CAN BUS JUMP1 Reset board (jumper for normal operation) JUMP2 programming (jumper for programming) JUMP3 programming (jumper for programming) JUMP4 CAN Bus terminator (jumper for insert terminator) STRIP...

  • Page 10: I/O Clivettalk.local.ex1

    I/O CLIVETTALK.LOCAL.EX1 Connector Terminal Description Note CN1-1 12Vac power Max. 4VA 12Vac power CN1-2 CN1-3 Differential pressure switch Max. 10mA for each input CN1-4 CN1-5 Check system charge CN1-6 CN1-7 Safety devices pump 1 CN1-8 CN1-9 Safety devices pump 2 CN1-10 CN2-1 Water inlet temperature NTC...

  • Page 11: Tandem Compressor Module Clivettalk.local.c2

    TANDEM COMPRESSOR MODULE CLIVETTALK.LOCAL.C2 TRIO COMPRESSOR MODULE CLIVETTALK.LOCAL.C3 T. Rec. T. Batt STRIP DIP1 JUMP2 JUMP3 JUMP1 DIP2 JUMP4 DESCRIPTION OF THE JUMPERS DIP1 To be defined DIP2 Board address for CAN BUS JUMP1 Reset board (jumper for normal operation) JUMP2 Firmware programming (jumper when programming) JUMP3...

  • Page 12: Clivettalk.local.c2 And Clivettalk.local.c3

    CLIVETTALK.LOCAL.C2 AND CLIVETTALK.LOCAL.C3 Connector Terminal Description Note CN1-1 12Vac power Max. 7VA 12Vac power CN1-2 CN1-3 Fan protector Max 10mA for each input CN1-4 CN1-5 High pressure CN1-6 CN1-7 Low pressure CN1-8 CN1-9 Compressor 1 protector CN1-10 CN1-11 Compressor 2 protector CN1-12 CN1-13 Compressor 3 protector...

  • Page 13: Initialising The Modules

    INITIALISING THE MODULES Each module configured and present in the Clivet Talk control system must be recognised by the local network, which needs to know which device it is communicating with. A series of basic rules must be observed when configuring the system, so as to avoid incorrect settings.

  • Page 14: Setting The Software Address

    SETTING THE SOFTWARE ADDRESS The following parameters are used for the configuration of the system: UNIT 1 Code Description Default U1_Mcomp1 Type of compressors, module 1 unit 1 U1_RecoverEn1 Enable recovery, compressor module 1 unit 1 U1_Mcomp2 Type of compressors, module 2 unit 1 U1_RecoverEn2 Enable recovery, compressor module 2 unit 1 U1_Mcomp3...

  • Page 15: Setting The Hardware Address Of The Central Module

    SETTING THE HARDWARE ADDRESS OF THE CENTRAL MODULE DIP2 = Dipswitches for setting the serial address DIP2 DIP1 The address of the central module is always = 25 JUMP4 JUMP1 SETTING THE HARDWARE ADDRESS OF THE EVAPORATOR MODULE JUMP2 JUMP3 The address of the evaporator module is always DIP1 higher than the address of the compressor modules...
  • Page 16 TABLE FOR SETTING THE HARDWARE ADDRESS Configuration DIP1 - DIP2 ADDRESS Device NOT ALLOWED CENTRAL MODULE NOTE The hardware address of the modules that make up the system must be set before any other configuration operation. Data creazione 10/09/03 DS03I009GB--00 Pagina 16 di 59...

  • Page 17: Local Interface Address

    HOME Figure 2 NOTE Figure 2 shows how the address of the local keypad requires a password (known by the Clivet service centres). REMOTE INTERFACE ADDRESS By definition, it has been established that the REMOTE KEYPAD is recognised by the local network layout as the module with address = 27.

  • Page 18: Configuration Example

    CONFIGURATION EXAMPLE To better understand the configuration mode of the local network, the following refrigeration unit will be used as an example: Type of unit = WSAT-SC 65D_R-407C No. of Central Modules = 1 No. of Evaporator Modules = 0 No.

  • Page 19: Setting The Software Address

    SETTING THE SOFTWARE ADDRESS To correctly configure the modules in a local network, set the parameters as shown below UNIT 1 Code Description Default U1_Mcomp1 Type of compressors, module 1 unit 1 U1_RecoverEn1 Enable recovery, compressor module 1 unit 1 U1_Mcomp2 Type of compressors, module 2 unit 1 U1_RecoverEn2...

  • Page 20: Parameter Menu Tree

    PARAMETER MENU TREE 12/12/04 13:00 12.2 °C COOL °C °C STEP: 03 / 12 MODE ALARM SETUP STATI > COOL Configuration Unit Compressors List PARAMETERS SCHEDULING CLOCK SETUP LANGUAGE Evaporators List STEP: 03 / 12 ENTER Defrost List Fans List Various List Multi...
  • Page 21 Configuration Unit Compressors Code Description Pass 131/CMP hp2enabled Enable HP pre-alarm 2 YES- The pre-alarm disconnects power from the circuit so as to avoid shutting down the unit due to the HP alarm, when the threshold set for parameter 193 is exceeded 132/CMP nprehp2hour Max number of HP pre-alarm 2 When the number of activations/hour indicated is exceeded, an alarm with manual reset is activated on the circuit...
  • Page 22 189/CMP setprehp2 High pressure pre-alarm 2 set point HP pre-alarm 2 activation threshold 190/CMP diffhp2 High pressure pre-alarm 2 reset differential 191/CMP setprelp1 Low pressure pre-alarm 1 set point Low pressure pre-alarm 1 activation threshold 192/CMP difflp1 Low pressure pre-alarm 1 reset differential 193/CMP deltapmax Maximum value of the evap / condenser pressure difference.
  • Page 23 Configuration Unit Evaporators Code Description Pass Antifreeze heater set point 37/EVA SetResist °C Activation threshold for the antifreeze heaters 39/EVA ALLFreeze Antifreeze alarm set point °C Activation threshold for the alarm antifreeze 41/EVA PreAF Antifreeze pre-alarm set point °C Antifreeze pre-alarm activation threshold 231/EVA IsPreAF Antifreeze pre-alarm reset hysteresis °C...
  • Page 24 Configuration Unit Defrost Code Description Pass 139/CMP bplpdrf Low pressure bypass time in defrost Time counted from when 4-way valve switches for defrosting, during which the low pressure alarm is ignored. 201/CMP pstartdfr Start defrost count pressure threshold From when the evaporation pressure falls and remains below this threshold, the defrost delay timer starts counting down (only when the compressors are on).
  • Page 25 211/CMP tmaxcntdfr Maximum defrost delay count time Time limit that cannot be exceeded in the calculations performed by the system when determining the delay between the activation of the timer and the actual defrost. 212/CMP textmindly Outside temperature for minimum defrost delay °C Temperature of the outside air at which the defrost delay is set to the minimum (equal to the value of parameter 214) This value must be greater...
  • Page 26 Configuration Unit Fans Code Description Pass 172/CMP tstartup Fan start time Duration of the fan start-up phase. 173/CMP tbycutoff Minimum operating time from compressor start Time that the fans are operated for even without the required pressure conditions. 174/CMP maxfan Maximum fan speed Maximum value allowed for the fan control signal.
  • Page 27 Configuration Unit Various Code Description Pass 8/CEN EnReversCycle Enable heat pump Enable the unit for reverse-cycle operation 12/CEN RemoteMode Enable remote mode Enable the remote control from digital inputs or from the supervisor system via the serial protocol. 38/CEN KPUMP Enable pump control for rotation With KPUMP=1, the system, when choosing the next step to be activated or deactivated, will consider which circuit pumps are already on, giving...
  • Page 28 Configuration Multi Comp Code Description Pass 141/CMP rotenabled Enable rotation in the circuit* Used to define whether the compressors in the same “compressor module” can be rotated or not. 142/CMP numerocp Number of compressors* Defines the number of compressors in the same “compressor module”...
  • Page 29 Configuration Multi Evap Code Description Pass Total hours pump 1* 246/EVA OrePompa1 247/EVA NPump Number of pumps present* Defines the number of pumps present on the single evaporator module 249/EVA OrePompa2 Total hours pump 2* 250/EVA DoubleprobeEn Enable double water outlet probe* Defines the number of water outlet temperature probes present on the single evaporator module.
  • Page 30 Configuration Pumps Code Description Pass 68/CEN MainPumpEn Enable main pump on central Refers to components connected to the central module 69/CEN NPumps Number of pumps on central Refers to components connected to the central module Total hours pump 1 central 122/CEN OrePompa1 Refers to components connected to the central module 123/CEN OrePompa2...
  • Page 31 Configuration Unit_1 ModComp1 Code Description Pass Type of compressors, module 1 unit 1 40/CEN U1_Mcomp1 42/CEN U1_RecoverEn1 Enable recovery, compressor module 1 unit 1 Configuration Unit_1 ModComp2 Code Description Pass 43/CEN U1_Mcomp2 Type of compressors, module 2 unit 1 44/CEN U1_RecoverEn2 Enable recovery, compressor module 2 unit 1 Configuration Unit_1...
  • Page 32 Configuration Unit_2 ModComp1 Code Description Pass 49/CEN U2_Mcomp1 Type of compressors, module 1 unit 2 Enable recovery, compressor module 1 unit 2 50/CEN U2_RecoverEn1 Configuration Unit_2 ModComp2 Code Description Pass 51/CEN U2_Mcomp2 Type of compressors, module 2 unit 2 52/CEN U2_RecoverEn2 Enable recovery, compressor module 2 unit 2 Configuration Unit_2 ModComp3...
  • Page 33 Configuration Unit_3 ModComp1 Code Description Pass 57/CEN U3_Mcomp1 Type of compressors, module 1 unit 3 Enable recovery, compressor module 1 unit 3 58/CEN U3_RecoverEn1 Configuration Unit_3 ModComp2 Code Description Pass 59/CEN U3_Mcomp2 Type of compressors, module 2 unit 3 60/CEN U3_RecoverEn2 Enable recovery, compressor module 2 unit 3 Configuration Unit_3...
  • Page 34 Antifrost Controls CENTRAL MODULE ANTIFREEZE MANAGEMENT PARAMETERS Code Description Pass 21/CEN IsPreAF Antifreeze pre-alarm hysteresis °C 22/CEN IstAllFreeze Antifreeze alarm hysteresis °C 92/CEN ByPassFreeze Antifreeze alarm bypass time Antifreeze alarm bypass time from the activation in heat pump mode. With the unit in standby and an alarm active, heating operation can be activated by bypassing the alarm for the time indicated.
  • Page 35 Controls Time compens Code Description Pass CompONEN Enable running time compensation Enables the compensation function on the compressor running time TimeOnMax Upper running time compensation time Compressor operating time considered sufficient. TimeOnMin Lower running time compensation time Compressor operating time considered too short. MaxCON Maximum running time compensation value °C...
  • Page 36 Controls Outside temp.Compens. Code Description Pass 1/CEN EnCompExt Enable external compensation Used to enable or disable the function 4/CEN MaxCExtC Maximum external compensation value in cooling °C Maximum value than can be added to the “Current Set point” in conditions of minimum outside temperature 5/CEN MaxCExtH Maximum external compensation value in heating...
  • Page 37 Controls Free Cooling Code Description Pass 31/CEN DeltaFC Temperature difference to start freecooling °C 32/CEN IstStopFC Temperature hysteresis to end freecooling °C 33/CEN IsValveFC Temperature hysteresis to close prop. freecooling valve °C 34/CEN DeltaMaxFC Max fan speed threshold in freecooling °C 35/CEN DeltaMinFC Min fan speed threshold in freecooling...
  • Page 38 Controls Dripping time Code Description Pass 17/CEN DeltaTC Design temperature difference in cooling °C 18/CEN DeltaTH Design temperature difference in heating °C 19/CEN IsLastStep Hysteresis to stop last active step °C 20/CEN IsFirstStep Hysteresis to start first step °C 109/CEN TScanMax Maximum step activation scan time 116/CEN TScanMin Minimum step activation scan time...

  • Page 39: Operating Status Menu Tree

    OPERATING STATUS MENU TREE 12/12/04 13:00 12.2 COOL °C Generals List °C STEP: °C 03 / 12 Unit_1 Mod_comp1 List MODE ALARM SETUP STATUS Mod_comp2 List Mod_comp3 List Mod_Evap List Unit_2 Mod_comp1 List Mod_comp2 List Mod_comp3 List Mod_Evap List Unit_3 Mod_comp1 List Mod_comp2...

  • Page 40: General Unit Status Menu

    GENERAL UNIT STATUS MENU Generals Item Description Unit status ON-OFF status Unit mode Unit operating mode Current set point Current set point value °C Inlet Temperature Unit inlet temperature value °C Outlet Temperature Unit outlet temperature value °C Number of active steps Capacity-control steps currently active Current step offset Value, calculated by the temperature controller...
  • Page 41 Unit_1...3 Comp_mod1...3 Item Description Compressor 1 status Current status of compressor 1 Compressor 2 status Current status of compressor 2 Compressor 3 status Current status of compressor 3 Cp 1 timer status Status of safety timeouts Cp 2 timer status Status of safety timeouts Cp 3 timer status Status of safety timeouts...

  • Page 42: List Of Alarms

    LIST OF ALARMS CENTRAL MODULE ALARMS Code displayed Reset Description-actions E001 H2O IN temp. probe fault on Automatic Disable load compensation and freecooling control module E002 H2O OUT temp. probe fault on Automatic Total shut-down – pump on control module E003 Outside air temp.

  • Page 43: Compressor Module Alarms

    COMPRESSOR MODULE ALARMS Code displayed Reset Description-actions E101 Cond./ Evap. temp. probe fault Automatic TypeCE=0; Cooling: signal only, Heating: stop circuit in question (see example) E102 Condensing pressure probe fault Automatic Stop circuit in question (see example) E103 Evaporation pressure probe fault Automatic Stop circuit in question (see example) E104 Recovery temp.

  • Page 44: Evaporator Module Alarms

    EVAPORATOR MODULE ALARMS Code displayed Reset Description-actions E201 Evaporator inlet probe fault Automatic Disable load compensation and freecooling E202 Evaporator outlet probe 1 fault Automatic Shut-down “UNIT-i” – pump on E202 Evaporator outlet probe 2 probe Automatic Shut-down “UNIT-i” – pump on fault E203 Programmable evaporator input Automatic...

  • Page 45: Operation Of The Temperature Controller

    OPERATION OF THE TEMPERATURE CONTROLLER COOLING The temperature controller acts by comparing the water outlet temperature to the system (average of the evaporator water outlet temperatures), against the current set point, and considering a number of threshold values. The temperature controller will tend to deactivate capacity-control steps when the water outlet temperature falls below the current set point Vice-versa, it will tend to activate capacity-control steps when the outlet temperature exceeds the sum of current set point + the theoretical value of the temperature difference between the water inlet and outlet due...

  • Page 46: Freecooling

    FREECOOLING There are two different freecooling modes: INTERNAL: the freecooling coil is located near the condenser coil. During the freecooling phase, the condensing fans (managed by the compressor modules) are controlled according to the average evaporator outlet temperature, as shown below (that is, independently from the configuration of the system). OUT temperature CENTRAL MODULE Outside air probe...
  • Page 47 EXTERNAL: the freecooling coil and fans are installed separately from the unit. They are managed directly by the module using an independent output. OUT temperature CENTRAL MODULE Outside air probe H20 inlet probe 0-10V freecooling valve output ON-OFF freecooling valve output Freecooling fan output Freecooling fans...
  • Page 48 The freecooling phase is enabled (starts) if: a) The temperature of the outside air is less than: Current set point + DeltaFC. b) The return water temperature from the system (measured by probe BT1 located at the inlet to the FC coil) is higher than: Outside air temperature + IstStopFC The freecooling phase is disabled (stops) if: c) The temperature of the outside air exceeds:...
  • Page 49 During the freecooling phase, the corresponding valve deviates the flow of water to the freecooling coil, located upstream of the evaporators. At the same time, the freecooling fans are activated according to the average evaporator outlet temperature. In this way, as the outside temperature is less than the return water temperature, the latter is cooled.
  • Page 50 ON-OFF valve and fans YV1 ON-OFF. (DO12) Ventilation ON-OFF 100% Average evaporator outlet IsValveFC Delta MaxFC temperature Delta MinFC Current Set Point IsLastStep Data creazione 10/09/03 DS03I009GB--00 Pagina 50 di 59...

  • Page 51: Heating

    HEATING The temperature controller acts by comparing the water outlet temperature to the system (average of the exchanger water outlet temperatures), against the current set point, and considering a number of threshold values. The temperature controller will tend to deactivate capacity-control steps when the water outlet temperature rises above the current set point Vice-versa, it will tend to activate capacity-control steps when the outlet temperature falls below the difference of the current set point - the theoretical value of the temperature difference between the water inlet...

  • Page 52: Step Activation - Scan Times

    STEP ACTIVATION – SCAN TIMES The temperature controller can activate one and one only step at a time, and only at the expiry of the activation scan time. At all other times no steps may be activated. The activation scan time is not fixed, but rather varies according to the temperature difference between the water outlet temperature and the current set point.

  • Page 53: Set Point Correction In Cooling

    SET POINT CORRECTION IN COOLING The current set point in cooling is defined by the parameter SetCool and by the following corrections: • OutsideT correction: Value of the correction based on the outside temperature (between 0 and MaxCextC). If the outside humidity probe is present, the correction of the set point will also depend on the factor Enthalpy Ext correction (between 0 and MaxCextC).

  • Page 54: Set Point Correction In Heating

    SET POINT CORRECTION IN HEATING The current set point in heating is defined by the parameter SetHeat and by the following corrections: • OutsideT correction: value of the correction based on the outside temperature (between 0 and MaxCextH). • WR correction: value of the Water Reset correction according to the external signal (between 0 and MaxCWRH).

  • Page 55: Second Set Point From Digital Input

    SECOND SET POINT FROM DIGITAL INPUT Two different set points can be used, depending on the status of digital input 2Set. The following parameters are used. Description Limits Default 0 ÷ 1 Enable second set point 2SetEn Flag 0 = NO 1 = YES MinSetC ÷...

  • Page 56: Demand Limit

    DEMAND LIMIT Enabling the DEMAND LIMIT function limits the capacity delivered so as to contain the power consumed by the unit. Configuration parameters: Description Limits Default Pass Add. Enable demand limit DemandLimitEn NO - YES Flag D.L. reaction time TReation 0 - 999 Control logic: The number of compressors available to the unit to satisfy the heating or cooling requirements is determined...
  • Page 57 UNIT WITH 3 COMPRESSORS NOTE As the 0-10Vdc/4..20mA signal changes, to avoid unwanted and continuous changes in the number of resources available to the temperature controller, a time = “Treation” is considered, in which the signal must remain stable above the step activation or 3 comp.

  • Page 58: Maintenance Set Point

    MAINTENANCE SET POINT The unit can be enabled to operate with a MAINTENANCE set point, which controls the water temperature even when the unit is OFF or in Standby. The following configuration parameters are used: Description Limits Default Pass 0 ÷ 1 Enable Maintenance in Cool MantCoolEn Flag...

  • Page 59: Resource Management Algorithm

    RESOURCE MANAGEMENT ALGORITHM The steps are activated following the request from the temperature controller according to the following rules: BALANCING OF THE CAPACITY DELIVERED The algorithm chooses the compressor to be activated based on the thermal demand in reference to the following distribution logic.
