- Page 1 ® StarBand Field Service & Maintenance Bulletins September 15, 2013 ® ©2004-2013, MobileInternetSatellite.com StarBand Field Service & Maintenance Bulletins...
- Page 2 FSBs which are not relevant for mobile StarBand users are not included in this document. However, they are still available on the StarBand.com web site, as follows: Go to the training web site, http://training.starband.com. Click on Installation, on the right.
- Page 3 75E Antenna Elevation Correction SB-0013-1.00 05/22/01 75E Antenna Torque Specs SB-0014-1.00 06/5/01 Line Amplifier Requirements SB-0015-1.01 02/07/02 9/13/01 LNB Troubleshooting SB-0016-1.00 75E DBS Kit "SAT-129/T7" Bracket Adjustment SB-0017-1.00 11/09/01 ODU Troubleshooting SB-0018-1.00 12/21/01 Antenna Pointing Procedures SB-0019-2.00 02/24/04 IFL Troubleshooting SB-0020-1.01 03/19/02 Feed/OMT Assembly Troubleshooting SB-0021-1.00...
- Page 4 75E Antenna Torque Specs — SB-0014-1.00 Upon inspection, locking bolts on 75E antenna have been found loose in Symptom some cases. Locking bolts for skew, elevation, and/or azimuth are not tightened Possible Cause to proper torque specification. ® When installing the StarBand...
- Page 5 MHz). The outbound signal is transmitted from the LNB output to the InDoor Unit (IDU) via the VSAT Receive (Rx) IFL. ® StarBand VSAT Receive Signal Problems, exhibited in reduced or no Symptom receive signal from the LNB. VSAT receive signal levels may be insufficient for the modem to obtain receive lock, or they may be absent altogether.
- Page 6 For CONUS installations, the LNB supplied with the 75E Consult with the RF Engineering group for is being used. For OCONUS installations in Alaska and guidance on the proper LNB to use.
- Page 7 Reattach the LNB to the OMT assembly, taking care to insure the rubber O-ring Step 3 stays in place. Re-check the Signal Strength reading. If the reading is acceptable, proceed with Step 4 the rest of the installation. ® ©2004-2013, MobileInternetSatellite.com StarBand Field Service & Maintenance Bulletins...
- Page 8 Phillips head screw driver. Because the test equipment required to ® ® StarBand Field Service & Maintenance Bulletins StarBand Field Service & Maintenance Bulletins ©2004-2013,...
- Page 9 VSAT system components will be checked first. Follow the procedures to determine if the ODU or other component is the source of the problem. ® Repair ODU problems in accordance with StarBand Maintenance Bulletin MB-0002. For radiation hazard concerns stay at least two feet away from the antenna Caution feed if the IDU is powered on for ODU testing.
- Page 10 OL (for OverLoad, meaning too high of a resistance to measure). If the display shows a low resistance value (i.e., less than one ohm), there is a short in the ® ODU. It has failed and must be replaced according to StarBand Maintenance Bulletin MB-0002.
- Page 11 StarBand satellite. Installing the Mount - When setting up the tripod mount for a 75E antenna, the Step 2 mast must be perfectly plumb. A plumb mast is critical for proper antenna pointing and cross-pol performance.
- Page 12 Antenna Pointing Procedures (continued) Antenna Assembly - Set the 75E antenna elevation and skew to the values Step 3 obtained from Point Dish. See the figure on the previous page, for an illustration of how to set the elevation angle. Tighten the skew locking bolts (4) to a torque of 8 ft-lbs.
- Page 13 Caution Due to the potential for interference caused by VSAT transmissions, the 75E antenna must be peaked using the satellite providing StarBand® service. Failure to do so can cause misalignment with the assigned StarBand® satellite and generate cross-pol interference. ®...
- Page 14 All elevation and azimuth bolts must be tightened to a torque of 12 ft-lbs. Checking for Correct Satellite - Once the 75E antenna is peaked using the Step 8 receive signal and all bolts have been tightened to the proper torque, it is necessary to confirm the antenna is peaked on the correct satellite.
- Page 15 This last item is very important! If the elevation and azimuth angles are not peaked on the receive signal, the cross-pol signal will not be minimized. The StarBand® satellite modem must be online and undisturbed for at least Caution five minutes, before completing the installation as described below.
- Page 16 IFL Troubleshooting — SB-0020-1.01 ® The IFL cables carry the signals to and from the StarBand 360 satellite modem and the outdoor receive and transmit equipment. Reduced performance or no receive and/or transmit signal. Symptom Physical damage to the IFL cable and/or connectors or improper Possible Cause installation, a cable with an open or short circuit, or a kinked cable.
- Page 17 Physical Inspection ® Check the length of IFL cable used. Installations of the StarBand Model 360™ modem can use up to 140 feet (42 meters) of installer provided dual RG-6 coaxial cable, with Type F/male connectors (Comscope 5786/5787 RG-6 cable and SPC Technology Snap-N-Seal Type F/male connector part number 92N5309 or equivalents - see MB-0005).
- Page 18 IFL connector outer surface and the red probe on the connector center conductor, as shown in the Figure called “IFL With No Open or Short Circuits”. The multimeter ® ® StarBand Field Service & Maintenance Bulletins StarBand Field Service & Maintenance Bulletins ©2004-2013,...
- Page 19 A DC resistance test can be performed, to determine if the IFL has an open or a short. In either case, the IFL must be replaced. ® ©2004-2013, MobileInternetSatellite.com StarBand Field Service & Maintenance Bulletins...
- Page 20 An audible tone will be heard, if the multimeter is set to provide a tone, when a short is measured. ® ® StarBand Field Service & Maintenance Bulletins StarBand Field Service & Maintenance Bulletins ©2004-2013,...
- Page 21 (moisture) to collect inside the feed/OMT assembly, the transmit-reject filter (if installed - see FSB SB-0016), the ODU and/or the LNB. ® Occasionally the StarBand antenna receive and/or transmit Recommended Action signals may be reduced, even when the antenna is properly peaked. This can be reflected either in the Signal Quality reading from the satellite modem, lower co-pol, or higher cross-pol measurements.
- Page 22 A missing or damaged O-ring can also allow moisture penetration. The ODU, LNB, and other waveguide screws may be removed to check the O-ring seals. ® ® StarBand Field Service & Maintenance Bulletins StarBand Field Service & Maintenance Bulletins ©2004-2013,...
- Page 23 (LO) that leak signals in ® the KU-Band (11.7- 12.2 GHz), which is used by the StarBand VSAT to receive outbound transmissions. Since the signals from the distant satellite are relatively...
- Page 24 IFL is functioning properly. If the ® outbound problem has been determined to not be associated with the StarBand antenna, LNB, receive IFL, satellite modem or configuration parameters, the problem could be a radar detector interference problem.
- Page 25 Relocation of the StarBand VSAT ® If the customer is willing to pay for the additional expense, the StarBand VSAT can be relocated to a new installation location on their property, which has a clear line-of-sight to the satellite(s) and is blocked from the interference source. For example, if the antenna...
- Page 26 ® Confirmation Number for successfully completed installations. Authorized StarBand installers access CVACS by calling 888-424-4121 and selecting option 2. All new installations must complete the CVACS installation process, to commission the site and enable customer Internet access.
- Page 27 The Maintenance Bulletin (MB) outlines procedures for replacement of specific VSAT components. MBs are included in the Installer’s Field Handbook, on the CDROM that ® came with this manual. They are also available on the StarBand web site, as follows: Go to the training web site, http://training.starband.com.
- Page 28 ® ® StarBand Field Service & Maintenance Bulletins StarBand Field Service & Maintenance Bulletins ©2004-2013,...
