VEK MNH
10.2

DIP switch settings

NOTE
Further information
•
You can find detailed information on settings options in the section Description of settings.
•
The Detector Tool service program offers further settings options. For information on these, read the
section on the Detector Tool.
•
If the settings are changed with the Detector Tool, the DIP switch settings are no longer valid. This
will be indicated by the blue LEDs flashing. Also read the section on the Reset button.
Function
Sensitivity
Frequency level
Hold time until readjustment
Output signal 2 mode
Output signal 2 time
Output signal inversion
Direction detection
Direction Logic
Tab. 10: Description of the settings
The single-channel variants have an 8-pole DIP switch for configuring the detector.
DIP Designation
1 Sense a
2 Sense b
3 Frequency
4
Hold time
5 Output 2
6
Edge 2
7 Inv. Out 1
8 Inv. Out 2
Tab. 11: DIP switch assignment (default)
VEK MNH Operating Manual v1.3 en
Description
Switch-on threshold for the signal output when a loop is covered
Frequency of the loop oscillating circuit in two levels
Maximum duration of the output signal up to the automatic frequency
readjustment of the loop channel
Switching between continuous and pulse signal on output 2
Time of output signal for activated pulse signal on output 2
Switching between open circuit (not inverted) and closed circuit principle
(inverted) for the output signals
Switching between presence and travel direction detection for both
outputs (dual-channel variants)
Evaluation logic of the travel direction when loops are covered,
depending on the application (see full operating manual!)
Function
Loop 1 sensitivity
Loop 1 sensitivity
Frequency step
Hold time until readjustment
Output signal 2 mode
Output signal 2 time
Output signal 1 inversion
Output signal 2 inversion
