- Page 2 VEHICLE INSTRUCTIONS FITTING INSTRUCTIONS Contents PERFORMANCE SERIES General Safety Precautions PEW-9000(12V P/N 9225611 24V P/N 9226611) Winch Operation Warings PEW-9500(12V P/N 9229602 24V P/N 9230602) Installation PEWI-9500(12V P/N 9229682 24V P/N 9230682) Winch Operation ATW-4500(12V P/N 7241110) Maintenence M73081119A Autogoods “130”...
- Page 3 Autogoods “130”...
- Page 4 VEHICLE RECOVERY ELECTRIC WINCH FITTING INSTRUCTIONS SAFETY PRECAUTIONS Warning! Observe safety precautions for personal safety and the safety of others. Improper equipment operation may cause personal injury and equipment damage. Read the following carefully before attempting to operate your winch and keep the instructions for future reference.
- Page 5 VEHICLE RECOVERY ELECTRIC WINCH FITTING INSTRUCTIONS Note: 1. The above symbols in the Owner’s manual are used to indicate additional information in the installation and operation procedures. 2. ATW4500 is designed primarily for intermittent duty general use. This winch is not designed to be used in industrial or hoisting applications.
- Page 6 VEHICLE RECOVERY ELECTRIC WINCH FITTING INSTRUCTIONS snatch block and double line arrangement. 12. Draping a heavy blanket or similar object over the extended winch cable is recommended as it will dampen any back lash should a failure occur. 13. Neat, tight spooling avoids cable blinding, which is caused when a load is applied and the cable is pinched between the others.
- Page 7 VEHICLE RECOVERY ELECTRIC WINCH FITTING INSTRUCTIONS 20. The winches shown in this manual are solely for vehicle and boat mount, non-industrial applications. 21. Do not use winch in hoisting applications due to required hoist safety factors and features. 22. Do not use the winch to lift, support or otherwise transport personnel. 23.
- Page 8 VEHICLE RECOVERY ELECTRIC WINCH FITTING INSTRUCTIONS PEW9000: Step 1 Step 2 Step 3 Step 4 PEW9500: Step 1 Step2 Step1 Step3 WINCH OPERATION SUGGESTION: The best way to get acquainted with how your winch operates is to make a few test runs before you actually need to use it.
- Page 9 VEHICLE RECOVERY ELECTRIC WINCH FITTING INSTRUCTIONS of the cable for hooking onto the load or anchor point. The shifter tab located on the gear housing of the winch operates the clutch as follows: (A) To disengage the clutch, move the clutch shifter tab to the "OUT" position. Cable may be free spooled off the drum.
- Page 10 VEHICLE RECOVERY ELECTRIC WINCH FITTING INSTRUCTIONS PEW-9000 12v P/N 9225611 24v P/N 9226611 CE Version FEATURES & SPECIFICATIONS Line Speed & Amp Draw-First Layer Rated Line Pull 9000LB (4080kg) Single-line Motor 6.6hp 12V Series Wound 2000 4000 6000 8000 9000 Line Pull Control Remote switch, 12' lead (3.7m)
- Page 11 VEHICLE RECOVERY ELECTRIC WINCH FITTING INSTRUCTIONS Item Item Part No. Descreption Part No. Descreption 9225601.3-13 Sun Gear-Input 9225600.3-1 Gear Box Base 9225601.3.1 Gear Carrier Ass'y-Input 9225600.3-14 Gasket 9500 G e a r C a r r i e r A s s ' y - 9225601.3.2 9225601.3-3AB Inner Gear...
- Page 12 VEHICLE RECOVERY ELECTRIC WINCH FITTING INSTRUCTIONS PEW-9500 12v P/N 9229602(Radio Control) 24v P/N 9230602(Radio Control) CE Version Available FEATURES & SPECIFICATIONS Rated Line Pull 9500LB (4305kg) Single-line Line Pull & Cable Capacity 6.6hp 12v Series Wound;6hp24V Series Motor Wound Layer of cable Control Wireless Multi-Control Rated line...
- Page 13 VEHICLE RECOVERY ELECTRIC WINCH FITTING INSTRUCTIONS Item Item Part No. Description Part No. Description 9229600.3-20 Washer 9229600.3-1 Gear Box Base 9229600.3-13 Sun Gear-Input 9229600.3-2 Gear Housing 9229600.3.1 Gear Carrier Ass'y-Input 9229600.3-3 Inner Gear 9229600.3.2 Gear Carrier Ass'y-Intermediat 9229602.3-10 Inner Gear 9229600.3-9A Cushion 1.2mm Thickness 9229600.3-14...
- Page 14 VEHICLE RECOVERY ELECTRIC WINCH FITTING INSTRUCTIONS PEWI-9500 12v P/N 9229682 24v P/N 9230682 CE Version Available FEATURES & SPECIFICATIONS Line Speed & Amp Draw-First Layer Rated Line Pull 9500lbs (4300kgs) Single-line 2000 4000 6000 8000 9500 Line Pull LOAD 1814 2720 3630 4300...
- Page 15 VEHICLE RECOVERY ELECTRIC WINCH FITTING INSTRUCTIONS Item Item Part No. Description Part No. Description GB/T70 M4X10 Bolt M4X10 9229680.0-21 Beam Cover 9229681.3-11 Gear Box End Cover GB/T819 M6X10 Link Screw M6X 10 Fastener-Upside 9229680.3-14 Gasket 9500 9229680.0-28 9229681.3-10 Inner Gear 9229680.0-29 Fastener-Downside C o p p e r S h e e t t o...
