Vulcan-Hart OUTLAW 195 Owner's Manual & Safety Instructions page 26

Basic Stick Welding
tO pREVEnt SERiOUS inJURy and dEatH:
do not weld without grounding clamp.
When the operator is not holding the Electrode Holder, it must be
sitting on a nonconductive, nonflammable surface.
1. Place the Welder on a level surface that
can bear its weight near the work area.
2. Secure the Grounding Clamp to a clean, exposed
metal part of the workpiece, or to metal work
bench where the workpiece is clamped.
3. To connect the Electrode Holder and
Ground Clamp Cables, refer to the electrode
manufacturer's package for correct polarity.
For DC Electrode Positive:
a. Connect the Electrode Holder Cable to
the Positive Output Socket (+) on the
front panel of the Welder/Generator.
b. Connect the Ground Clamp Cable to
the Negative Output Socket (-) on the
front panel of the Welder/Generator.
For DC Electrode Negative:
a. Connect the Electrode Holder Cable to
the Negative Output Socket (-) on the
front panel of the Welder/Generator.
b. Connect the Ground Clamp Cable to
the Positive Output Socket (+) on the
front panel of theWelder/Generator.
4. Turn the Amperage Control Knob to
adjust the welding current.
Min
Page 26
Max
For technical questions, please call 1-888-866-5797.
Set amperage according to Stick
Settings Chart below.
nOtE: Settings are approximate. Adjust as necessary.
Stick Settings chart
Electrode
Electrode type
diameter
E6010 dc+
E6011 dc+
E6013 dc+
E7014 DC+
E7018 dc+
E7024 DC+
The approximate current setting can be read
on the digital display on the Front Panel.
amperage
Range
3/32" 40 – 70
1/8" 75 – 130
5/32" 90 – 175
3/16" 140 – 1 95
1/16" 25 – 4 0
3/32" 40 – 9 0
1/8" 75 – 125
5/32" 105 – 175
3/16" 150 – 1 95
3/32" 75 – 110
1/8" 105 – 160
5/32" 150 – 1 95
3/32" 70 – 110
1/8" 90 – 160
5/32" 130 – 1 95
3/32" 100 – 145
1/8" 110 – 175
5/32" 160 – 1 95
Item 57167
