Cosel PCA Series Quick Start Quide

Extended UART signal - RS232 signal converter
This is a unit to convert Extended UART signal to RS232 signal mutually.
Model number Applicable power supply
PCA300F
PCA600F
PCA1000F
RBC200F
<I3 Option>
CR-PC-1
AME400F
AME600F
AME800F
AME1200F
<AI3 Option>
1 Specification
ITEM
V - Vss voltage [V]
DD
Sink current (Vcc) [mA]
INFO - Sgnd voltage [V]
ELECTRICAL
SPECIFICATIONS RXD - SG voltage [V]
RXD output short circuit current [mA]
TXD - SG voltage [V]
Number of connected
Operating temp.,humidity
Storage temp.,humidity
ENVIRONMENT
Vibration
Impact
OTHERS Weight
2 External View
1000±20
<Extended UART side>
Line color Signal name
Red V
DD
Black V
SS
White INFO
Blue Sgnd
Optional Parts
<Block Diagram>
Extended UART signal
Red line : V
DD
Black line : V
SS
White line : INFO
Blue line : Sgnd
CR-PC-1
DC -0.3 to 14.4
DC 25
DC -0.3 to 5.5
DC �4.2 typ (RXD Loaded with 3kΩ to SG)
DC �60 max
DC -15 to 15 (Input Resistance 3 to 7kΩ)
7 max
-20 to 60C, 20 to 90%RH (Non condensing)
-20 to 85C, 20 to 90%RH (Non condensing)
10 - 55Hz 19.6m/s
196.1m/s
40g max
1
40.2
<RS232>
Contents Pin number
Power input
Ground
Extended UART data
Signal ground
July 20, 2020
Appearance
Buck
converter
Buffer
circuit
2 (2G) 3minutes period, 60 minutes each along X, Y, and Z axis
2 (20G) 11ms, once each X,Y and Z axis
M2.6X0.45
6
1
5
9
14
3 18
Signal name
1 -
2 RXD RS232 received data
3 TXD RS232 send data
4 -
5 SG
6 -
7 -
8 -
9 -
Shell -
PCA Series
AME Series
RB Series
D-sub 9 Pin
Female Connector
RS232 signal D-sub 9 pin
Level conversion
circuit
2 : RXD
3 : TXD
5 : SG
* Dimensions in mm
* Tolerance : ±1
* Weight : 40g max
* AWG : 28
Contents
N.C.
N.C.
Signal ground
N.C.
N.C.
N.C.
N.C.
N.C.
Option-69
