OWNER'S/INSTALLATION MANUAL
MSP-1-N/MSP-1-P/MSP-2-N/MSP-2-P
MUST READ!
This manual contains important information regarding your MOTAK unit. Please read the
manual thoroughly prior to equipment set-up and operation maintenance. Failure to comply
with regular maintenance guidelines out-lined in the manual may void the warranty. Improper
installation, adjustment, alteration, service or maintenance can cause property damage,
injury or death. Read this manual thoroughly before installing or servicing this equipment.
MOTAK STOCK POT MANUAL
FOR WARRANTY SERVICE CALL 833-474-0367
1
Advertisement
Table of Contents
Summary of Contents for Motak MSP-1-N
- Page 1 MSP-1-N/MSP-1-P/MSP-2-N/MSP-2-P MUST READ! This manual contains important information regarding your MOTAK unit. Please read the manual thoroughly prior to equipment set-up and operation maintenance. Failure to comply with regular maintenance guidelines out-lined in the manual may void the warranty. Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death.
-
Page 2: Specifications
You have purchased one of the finest pieces of commercial cooking equipment on the market. You will find that your new equipment, like all MOTAK equipment, has been designed and manufactured to meet the toughest standards in the industry. Each piece of MOTAK equipment is carefully engineered and designs are verified through laboratory tests and field installations. -
Page 3: Safety Precautions
• The appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve (supplied by others), during any pressure testing of the gas supply piping system at test pressures equal to or less than ½ P.S.I. (3.5kPa) MOTAK STOCK POT MANUAL FOR WARRANTY SERVICE CALL 833-474-0367... -
Page 4: For Your Safety
Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance. WARNING FIRE HAZARD – Do not install or use without the eight-inch (8”) legs. Use of this equipment without legs can cause the appliance to overheat and cause fire. MOTAK STOCK POT MANUAL FOR WARRANTY SERVICE CALL 833-474-0367... -
Page 5: Lighting The Pilot
Smoke appearing on initial use of the appliance is normal. This is a result of the rust preventative coating burning off. Allow the equipment to “burn in” for at least 15 minutes before the first use. MOTAK STOCK POT MANUAL FOR WARRANTY SERVICE CALL 833-474-0367... -
Page 6: Operation
2. Check the drip tray frequently. 3. To ignite the burner, depress and turn the gas control knob to high position. 4. Adjust the valve set-point to obtain the desired level of heat. MOTAK STOCK POT MANUAL FOR WARRANTY SERVICE CALL 833-474-0367... - Page 7 • Install equipment under efficient exhaust hood with flameproof filters with a distance of no less than four (4) feet between the top of the equipment and the filters or any other combustible materials. MOTAK STOCK POT MANUAL FOR WARRANTY SERVICE CALL 833-474-0367...
- Page 8 Cast Iron Burner tube SP10011 Cast Iron Burner Grate Right rail Tube connecting to pilot Stiffening plate Round head screw (M4-12) Support for foot Mounting Bracket for Flat head screw (M8-12) Pilot MOTAK STOCK POT MANUAL FOR WARRANTY SERVICE CALL 833-474-0367...
- Page 9 Left Side Panel Connecting Pipe B SP10014 Connecting Pipe A (Pilot) SP10019 (Pilot) Supporting Plate SP10015 Connector (Gas Valve) (Burner) Guide Rail (Right) SP10020 Burner SP10001 Adjustable Leg Guide Rail (Left) MOTAK STOCK POT MANUAL FOR WARRANTY SERVICE CALL 833-474-0367...
- Page 10 THIS PAGE LEFT BLANK INTENTIONALLY MOTAK STOCK POT MANUAL FOR WARRANTY SERVICE CALL 833-474-0367...
- Page 11 THIS PAGE LEFT BLANK INTENTIONALLY MOTAK STOCK POT MANUAL FOR WARRANTY SERVICE CALL 833-474-0367...
- Page 12 Phone : 865-225-1545 For Warranty Service Call 833-474-0367 A product with the MOTAK name incorporates the best in durability and low maintenance. We all recognize, however, that replacement parts and occasional professional service may be necessary to extend the useful life of this unit.
