Installation Manual
Engineered Pump Systems (EPS)
for Ordinary and Hazardous Locations
Common Components:
• Fiberglass Basin (Tank)
• Sump, Effluent, Sewage or Grinder Pump(s)
• Factory Installed Guide Rail System
• Pre-Mounted Float System
• NEMA 4X Junction Box
• Inlet Hub
• Control Panel or Alarm System
IMPORTANT: Liberty Pumps EPS are a custom product and some differences in materials, pumps, and design are unavoidable. This
manual is intended as a generic installation guideline only. Any specific questions should be directed to Technical
Customer Service at 800-543-2550 or email support@LibertyPumps.com.
7000 Apple Tree Avenue
Bergen, NY 14416
ph: 800-543-2550
fax: 585-494-1839
www.LibertyPumps.com
Copyright © Liberty Pumps, Inc. 2019 All rights reserved.
7298000D
