This Installation Manual contains the instructions that must be followed for proper installation
and commissioning the S2000-IPDL detector.
The detector is described and the rules to adjust and operate it are discussed in the User's
Manual (which can be found at the site of the Bolid Company
PRODUCTS at the page of S2000-IPDL).
1 SAFETY PRECAUTION
- The detector is a source of danger neither for human nor for protected material
assets (including the emergency situations).
- The design and circuitry of the detector ensure its fire safety during operation
(including emergency operation).
- As to methods of human protection against electric shock, the detector meets
the requirements of Class III as per Russian GOST 12.2.007.0.
- In terms of voltage values, the detector is not dangerous to human life and
health, but during repair, inspection, installation, and operation it is necessary to
comply with safety measures in accordance with Regulations for Operation of
Consumers' Electrical Installations and Safety Rules for Operation of
Consumers' Electrical Installations.
- While installing and maintaining the detector please comply with the rules for
working at heights.
2 MOUNTING
2.1 The units of the detector should be attached to the building structures generally with the
help of mounting kits supplied:
Kit No.1: Designed to attach the transceiver unit and to fasten the housing additionally (if
necessary) on completing commissioning.
Kit No.2: Designed for attaching an S-Type (small) reflector or a remote indicator and
control unit.
Kit No.3: For an XS-Type (extra small) reflector.
Kit No.4: For an L-Type (large) reflector.
In specific situations (for example, when the detector components can be fastened only by
means of threaded joints) another fixture elements can be used. Anyway, it is necessary to
provide reliable fastening without gaps, drifting, and any motion of the detector's elements while
in operation.
Addressable
Beam Smoke Detector
S2000-IPDL
Installation Manual
http://bolid.ru
Orion ISS
Reflective
in the section

Advertisement

loading
Need help?

Need help?

Do you have a question about the S2000-IPDL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for bolid S2000-IPDL

Summary of Contents for bolid S2000-IPDL

  • Page 1 This Installation Manual contains the instructions that must be followed for proper installation and commissioning the S2000-IPDL detector. The detector is described and the rules to adjust and operate it are discussed in the User’s Manual (which can be found at the site of the Bolid Company http://bolid.ru in the section PRODUCTS at the page of S2000-IPDL).
  • Page 2 2.2 Wires can be run either in surface way or recessed. For flush wiring wires shall be lied down by first and then the transceiver unit or remote indicator and control unit can be mounted. For surface wiring installation order doesn’t matter. 2.3 Wires should be passed through the side holes in the base located above the side notches in the mounting base.
  • Page 3 Figure 1. Overall and Mounting Dimensions...

  • Page 4: Setting Address

    Addressable Addressable device device S2000-KDL - PL - PL - PL Figure 2. Connection Diagram 4 SETTING ADDRESS 4.1 The detector provides storing its polling loop address in its non-volatile memory. The factory address of the detector is 127. An address can be given by means of the control panel, PC software utility, or S2000-APA addressable device programmer (the rules to operate which are described in its user’s manual).
  • Page 5 reflector, for example to put the transceiver on a table with the lens facing up using the ceiling as a reflector. 5.1.3 For testing operability, power up the control panel or PC and the polling loop controller with the detector connected to the last one. 5.1.4 Activate the alignment mode by sliding the DIP switch “1”...
  • Page 6 Table 1 Text on the IPDL- Condition Description 152 Tester Performance Display Flashes with The received signal meets norm red once per Norm “Норма” / “Norm” conditions four seconds Waiting for establishing communications with the PL controller Lit steady with The TEST button has been Test pressed...
  • Page 7 5.2.2 For an S2000-IPDL in field two types of verification are required: the full-range verification of detector’s operability with affecting the optical beam and the routine verification of sending the polling loop controller the messages about testing, fire, and trouble. The first testing should be performed after any actions with the transceiver when its position was changed, including, of course, commissioning.

  • Page 8: Getting Started

    4.2.3 Routine Testing 4.2.3.1 Routine testing of detector operability is performed by simulating of the Test/Fire mode (depending on the current setting) and Trouble mode by means of relevant buttons incorporated in remote control unit and duplicated in the detector. 4.2.3.2 The relevant button TEST or TROUBLE shall be pressed and held pressed at least for five seconds.
