Put On The Tank Cover And Test The Flush Mechanism; Mount The Toilet Seat - Fresca ANTILA FTL2351 Installation Manual

5. Put on the tank cover and test the flush mechanism
a
Put on the tank cover(C) gently.

6. Mount the toilet seat

a
Insert the expansion rubbers(N) into the
installation hole.
Replace a new toilet seat please refer to below illustrated.
a
Press the button and loose your hand until
you hear a click.
©2014 Fresca ™ All rights reserved. This material may not be reproduced, displayed, modified or distributed without the express prior written permission of the copyright holder.
b
N
M
Put the plastic gaskets(L) and bolts(K)
through the hinge base(M) making them
aligned with the holes of bulgy rubber and
fasten it.
b
B
Botton
Take away the toilet seat(B).
Test the flush mechanism.
b
C
K
L
Insert the toilet seat(B) into hinge base by
track.
Insert the new toilet seat(B) into hinge base
by track.
c
B
c
B
PAGE 5
