- Page 1 584L SIDE BY SIDE FRIDGE KAMSBSF527B & KAMSBSF527C...
-
Page 3: Safety And Warnings
• If the supply cord is damaged, it must be replaced by Kogan in order to avoid a hazard. •... - Page 4 Do not allow the power cable to become pinned by the refrigerator or trampled by people. Do not use damaged power cables or plugs; if you note any damage to the cable or plug, contact Kogan support. WARNING: The R600a refrigerant and cyclopentane foaming material used for the refrigerator are flammable.
- Page 5 • Do not spray or rinse the refrigerator with water, and install the refrigerator in a dry place free of moisture so as not to affect the electrical insulation of the appliance. • Never attempt to dismantle or modify the refrigerator and avoid damage to the cooling pipes.
- Page 6 OVERVIEW Freezer door rack Freezer compartment glass shelf Freezer compartment drawer Refrigerator compartment glass shelf Vegetable crisper Refrigerator door rack Not pictured: Included ice tray in freezer compartment (2)
-
Page 7: Before Use
BEFORE USE • Remove all packaging material before using the new refrigerator. This includes the foam base and all adhesive tape holding the refrigerator accessories inside and outside. • Clean both the inside and outside of the refrigerator with wet cloth. A small amount of neutral detergent can be added to warm water to wash the cloth, and continue wiping the appliance with clean water. - Page 8 Recommendations for refrigerator food storage As the cycle of air-conditioning in the refrigerator will affect the temperature of each section differently, different food varieties should be placed in an area of appropriate temperature. Pasta, canned foods, milk, etc. Fast food, dairy products, etc. Cooked meat and sausages, etc.
- Page 9 Recommendations for freezer food storage The freezer compartment maintains a below-zero temperature to keep stored food fresh for an extended period. Always comply with the storage time marked on food packaging. Short-term storage of food and ice cream. General frozen foods. Frozen foods, such as fish, meat and ice cream.
-
Page 10: Installation
INSTALLATION Door height adjustment Before adjusting the height of the door, rotate the downward adjusting nut clockwise (as shown in Figure I) with a wrench for 2 full rotations to loosen. Rotate the upward adjusting nut (as shown in Figure I) to adjust the height and then tighten the downward adjusting nut counter-clockwise. - Page 11 Refrigerator compartment • Place foods for short-term storage or imminent consumption in the refrigerator section. • The refrigerator will maintain an average temperature between 0-10°C and is not intended for the long-term preservation of food. Use the freezer for extended storage.
-
Page 12: Operation
OPERATION First Use Affix the lower cover inside the refrigerator as shown in “Before Use”. Note: If the door is misaligned, refer to the adjustment instructions above (also located in the lower left comer of the refrigerator’s right panel) to adjust. Connect the refrigerator to the power supply After being connected to power, the refrigerator will show the current chilled and frozen temperature. - Page 13 Functions Button Operation Display A Refrigerator temperature Refrigerator compartment adjustment Freezer temperature 2 Freezer compartment adjustment C Super cool/Super FRZ. 3 Close refrigerator compartment D Vacation mode 4 Lock icon E Lock/Unlock 5 Super cool mode 6 Super FRZ. Mode Vacation mode...
- Page 14 Lock/Unlock Press and hold the Lock/Unlock key (E) for 3 seconds and the refrigerator will lock, showing the locked icon (4). Repeat this process and the refrigerator will unlock, showing the open icon (4). Vacation mode Press the Vacation mode key (D) and the icon will illuminate (7). Press the Lock/Unlock key (E) to confirm, and the refrigerator will enter Vacation mode.
-
Page 15: Cleaning And Care
CLEANING & CARE Defrosting freezer The freezer compartment will defrost automatically, with no need for manual intervention. Cleaning • Dust behind and on the floor around the refrigerator to improve cooling and energy saving. • Check the door gasket regularly to ensure there is no debris within. Clean the door gasket with a soft cloth dampened with soapy water or a diluted neutral detergent. - Page 16 Storage • The appliance should be located in the coolest area of the room, away from heat producing appliances or heating ducts, and out of direct sunlight. • Let hot foods cool to room temperature before placing them in the appliance. •...
-
Page 17: Troubleshooting
TROUBLESHOOTING Ensure the unit is securely connected to the power socket Failed operation Check whether the voltage is too low Check for a power failure or if partial circuits have tripped Ensure odorous foods are tightly wrapped before storage Odour Check for any rotten food that may be inside Clean the inside of the refrigerator This is normal in summer when the ambient temperature is high:... - Page 18 NOTES...
- Page 20 Need more information? We hope that this user guide has given you the assistance needed for a simple set-up. For the most up-to-date guide for your product, as well as any additional assistance you may require, head online to help.kogan.com...
