Motorfan
Function:
Technical data:
Pressure switch
Function:
Technical data:
Main board
Function:
Technical data:
1.1.0 5.2007
It moves the fan that refrigerate the condenser in the cooling unit
Electric connectors: FASTOM
Resistance: 0,85KΩ
Feels the pressure of a gas and it gives a signal to the main board
when arrived to the programmed value.
T 1.5 NA-20/06
Electric connectors: FASTOM
Resistance: none
Controls all sensors and probes, and decides to switch on or off
all components plugged to it when its software says so.
Ref.:
Power connectors: none
Resistance: 0,82KΩ
17/40
