Electric valve + turbine
Function:
Technical data:
Gaiser Jet
Function:
Technical data:
1.1.0 5.2007
Resistance: 3,9KΩ x 3
This is the valve at the beginning of the hydraulic circuit. It's
plugged to the water inlet. It also send pulses to the main board
when water passes by.
Ref.: ELTEK 10155170
220V-50Hz
Electric connectors: FASTOM
Water IN: ¾"
Water OUT: 10mm
4l/min
Tm 90°C 3/5min
Tm 25°C 100% ED
Resistance: 3,7KΩ
Loads CO2 gas into the water, thanks to the pressure of the
pump.
Capacity: 0.66l
Height: 160mm
2 level probes (MAX / MIN)
Water connectors: For 6mm tube
Probe connectors: FASTOM
13/40
