Prostat PRF-911 Operation Manual

Concentric ring
Hide thumbs

Advertisement

Quick Links

Download this manual
P R O F E S S I O N A L
S T A T I C
C O N T R O L
P R O D U C T S
Concentric Ring
PRF-911
Operations Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the PRF-911 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Prostat PRF-911

  • Page 1 P R O F E S S I O N A L S T A T I C C O N T R O L P R O D U C T S Concentric Ring PRF-911 Operations Manual...
  • Page 2 Copyright © 2001-2007 by PROSTAT® Corporation. All rights reserved. Printed in the United States of America. No part of this manual may be used or reproduced in any manner whatsoever without written permission. For information contact PROSTAT Corporation, 1072 Tower Lane, Bensenville, IL 60106...

  • Page 3: Table Of Contents

    PRF-911 Concentric Ring TABLE OF CONTENTS ® PROSTAT PRF-911 CONCENTRIC RING Title Page # Introduction ........................3 Cautions & Warnings ...................... 3 III. Equipment Inspection & Initial Preparation for use ............5 General Operation......................13 Maintenance........................20 General Specifications ....................21...

  • Page 4: Introduction

    ESD STM 11.11-2001 guidelines. 2. The metal (plated aluminum) surface is used for volume resistance and resistivity measurements made using ESD STM 11.12-2000 guidelines. C. A BNC/Dual Banana Receptacle adapter is provided for use with the PRF-911 Concentric Ring fixture. Cautions & Warnings A.
  • Page 5 To avoid electrical shock, do not touch the fixture, electrodes or test bed when power is being applied. B. The PRF-911 is designed to be used in audit environments at test voltages of 100 volts or less. Exceeding 100 volts greatly enhances the risk of personnel shock hazards, and may damage or change materials being measured.

  • Page 6: Equipment Inspection & Initial Preparation For Use

    F. Do Not Touch Electrode Surfaces: Electrodes will become contaminated with skin oils. G. Do not store or use in damp environments H. Always store the PRF-911 with its protective cap in place. III. Equipment Inspection & Initial Preparation for use A.
  • Page 7 ESD STM 11.12-2000. Figure 3: Dual Test Bed C. Inspection of the PRF-911 Concentric Ring Figure 3 Dual Test Bed Fixture 1. Before inspecting the PRF-911 Concentric Ring, confirm the calibration of your resistance instrument. Performing low Resistance Calibration on the Prostat PRS- 801 and PRS-812 Resistance Instruments.
  • Page 8 3. Remove RED protective cap covering the electrode surfaces 4. Confirming the Fixture Ground and BNC Connection a. Place PRF-911 Concentric Ring fixture on a flat surface with the electrodes facing UP . b. Plug one PRS-801 or PRS-812 Resistance Meter test lead to the BLACK BNC/Dual Banana adapter receptacles.
  • Page 9 ) through the installed BNC/Dual Banana adapter. NOTE: Review resistance instrumentr operating instructions before proceeding: a. Place PRF-911 Concentric Ring fixture on a flat surface with the electrodes facing UP. b. Plug one PRS-801 or PRS-812 Resistance Instrument test lead the RED BNC/Dual Banana adapter receptacle.
  • Page 10 ) through the frame installed BLACK banana receptacle. NOTE: Review the resistance instrument’s operating instructions before proceeding. a. Place PRF-911 Concentric Ring fixture on a flat surface with the electrodes facing UP . b. Plug one PRS-801 or PRS-812 Resistance Meter test lead into the BLACK OUTER RING banana receptacle located in the side of the fixture frame.
  • Page 11 PRF-911 Concentric Ring d. Hold the second PRS-801 or PRS-812 test lead by the insulated collar just behind the alligator clip. e. GENTLY touch the tip of the alligator clip to the narrow outer electrode ring. (see figure 7) Figure 7: Confirming Outer Electrode f.
  • Page 12 Connect the second PRS-801 or PRS-812 Resistance Meter test lead to the metal test bed banana receptacle. d. Place one five pound NFPA electrode on the PRF-911 fixture housing; (1) NOTE the compression of the center electrode spring assembly...
  • Page 13 PRF-911 Concentric Ring e. Select Ohms Mode by pressing the “Mode” button once of the PRS-801 or PRS-812 Resistance Instrument. 1. Push Test Button 2. Resistance Should be < 20 Ω (1) If proper connection is made to the BNC/Dual Banana adapter and the center electrode is in contact with the metal test bed, the resistance instrument will indicate low resistance.

  • Page 14: General Operation

    ASTM D-257. The following procedure is used to measure surface resistance in ohms, and convert it to ohms/square if necessary. 1. Items necessary for this procedure a. PRF-911 Concentric Ring Fixture b. BNC/Dual Banana Adapter c. PTB-920 Dual Test Bed d.
  • Page 15 Install the BNC/Dual Banana adapter on the PRF-911 fixture b. Check proper battery level of the PRS-801 or PRS-812 Resistance Instrument and connect the meter leads to the PRF-911 Fixture as follows: (1) Install the instrument negative (-) lead of the PRS-801 or PRS-812 Resistance Instrument to the RED BNC adapter receptacle connected to the center INNER RING electrode (D1).
  • Page 16 Place the five pound PROSTAT NFPA electrode directly on top of the PRF-911 fixture housing. Note the center electrode spring compression and contact of the outer electrode ring with the material under test.
  • Page 17 PTB-920 Dual Test Bed d. PRS-801 or PRS-812 Resistance Meter and test leads e. One PROSTAT five pound NFPA electrode. f. One GREEN auxiliary ground lead (OPTIONAL) g. A micrometer to accurately measure the test materials thickness in cm h.
  • Page 18 3. PRF-911 Concentric Ring Fixture Preparation a. Install the BNC/Dual Banana adapter on the PRF-911 fixture b. Check proper battery level of the Resistance Instrument and connect its leads to the PRF-911 Fixture as follows:...
  • Page 19 Remove the PRF-911 fixture electrode protective cap and position the fixture on the test material in the approximate center of the test bed. c. Place the five pound PROSTAT NFPA electrode directly on top of the PRF-911 fixture housing. Note the center electrode spring compression and contact of the outer electrode ring with the material under test.
  • Page 20 PRF-911 Concentric Ring OPERATIONAL WARNING TO AVOID PERSONNEL SHOCK, DO NOT TOUCH THE MATERIAL UNDER TEST, THE PRF-911 CONCENTRIC FIXTURE OR TEST BED DURING ANY MEASUREMENT CYCLE. Proper test voltage protocol for resistance measurements of ESD Control materials follows: Test Voltage (V) Remarks Resistance Range (Ω)

  • Page 21: Maintenance

    2. Functional testing of the equipment is conducted using the procedures described in Section III. EQUIPMENT INSPECTION & INITIAL PREPARATION FOR USE. 3. Periodically tighten the BNC connection locking nut located on the PRF-911 fixture housing. 4. Calibration of the contact surfaces requires surface dressing and a calibration fixture described in ESD STM S11.11-2001.

  • Page 22: General Specifications

    3/8 inch stainless steel, or plated aluminum. Power: Not Applicable. The fixture and test bed are used in conjunction with the PROSTAT PRS-801 or PRS-812 Resistance Instrument and test leads. Warranty: PROSTAT Limited One Year Rev: PRF-911 – 12-2005...
  • Page 24 Copyright 2001-2007, Prostat Corporation Printed in U.S.A. 1072 Tower Lane, Bensenville, IL 60106 USA www.prostatcorp.com...
