  • Page 1 EBW-E100...
  • Page 3 Copyright © April 15 INSYS MICROELECTRONICS GmbH Any duplication of this manual is prohibited. All rights on this documentation and the devices are with INSYS MICROELECTRONICS GmbH Regensburg. Trademarks The use of a trademark not shown below is not an indication that it is freely availa- ble for use.
  • Page 4 Content Preface ..................... 7 Defects Liability Terms ..................7 Feedback ....................... 7 Marking of Warnings and Notes ................8 Symbols and the Formatting in this Manual ............9 Safety ..................... 10 Intended Use ....................... 10 Permissible Technical Limits ................11 Responsibilities of the Operator ................

  • Page 5: Table Of Contents

    Contents Functions ....................35 12.1 Basic Settings ...................... 35 12.1.1 Configuring Web Interface Access ............35 12.1.2 Setting IP Addresses ................36 12.1.3 Entering a Static Route................37 12.1.4 Entering Host Names ................37 12.1.5 Configuring MAC Filter ................38 12.1.6 Configuring Access Protection via Radius Server ........
  • Page 6 Content Maintenance, Repair and Troubleshooting ..........89 13.1 Maintenance ......................89 13.2 Troubleshooting ....................89 13.3 Repair ........................89 Waste Disposal ..................90 14.1 Repurchasing of Legacy Systems ................ 90 Declaration of Conformity ..............91 FCC Statement ..................92 Licenses ....................93 17.1 GNU GENERAL PUBLIC LICENSE ...............
  • Page 7 We are looking forward to any of your feed- back. Please send an e-mail to support@insys-tec.de. We'd like to know your applications. Please send us a few headwords that we know the applications you solve using products of INSYS icom.
  • Page 8 Preface EBW-E100 Marking of Warnings and Notes Symbols and Key Words Danger! Risk of severe or fatal injury One of these symbols in conjunction with the key word Danger indicates an imminent danger. It will cause death or severe injuries if not avoided.
  • Page 9 EBW-E100 Preface Symbols and the Formatting in this Manual This section describes the definition, formatting and symbols used in this manual. The various symbols are meant to help you read and find the information relevant to you. The following text is structured like a typical operating instruction of this manual.
  • Page 10 Safety EBW-E100 Safety The Safety section provides an overview about the safety instructions, which must be observed for the operation of the product. The product is constructed according to the currently valid state-of-the-art technol- ogy and reliable in operation. It has been checked and left the factory in flawless condition concerning safety.
  • Page 11 EBW-E100 Safety Permissible Technical Limits The product is only intended for the use within the permissible technical limits specified in the data sheets. The following permissible limits must be observed:  The ambient temperature limits must not be fallen below or exceeded.
  • Page 12 Safety EBW-E100 Markings on the Product The identification plate of the product is either a print or a label on a face of the product. Amongst other things, it can contain the following markings, which are explained in detail here.
  • Page 13 EBW-E100 Safety Safety Instructions for Electrical Installation The electrical connection must only be made by authorised expert personnel ac- cording to the wiring diagrams. The notes to the electrical connection in the manual must be observed. Otherwise, the protection category might be affected.
  • Page 14 Safety EBW-E100 Caution! Overvoltage and voltage peaks from the mains supply! Fire hazard and damage of the product due to overvoltage. Install suitable overvoltage protection. Caution! Damage due to chemicals! Ketones and chlorinated hydrocarbons dissolve the plastic housing and damage the surface of the device.
  • Page 15 Using Open Source Software General Information Our product EBW-E100 contains, amongst others, so-called open-source software that is provided by third parties and has been published for free public use. The open-source software is subject to special open-source software licenses and the copyright of third parties.
  • Page 16 Using Open Source Software EBW-E100 Special Liability Regulations We do not assume any warranty or liability, if the open-source software programs contained in our product are used by the customer in a manner that does not com- ply any more with the purpose of the contract, which is the basis of the acquisition of our product.
  • Page 17 INSYS icom:  DIN rail power supplies The following related documents can be found in the download area and on the product page of the EBW-E100 under www.insys-icom.com:  Add-On Manual ASCII Configuration File  Add-On Manual Automatic Update ...
  • Page 18 Technical Data EBW-E100 Technical Data Physical features All specified data was measured with nominal input voltage, at full load, and an ambient temperature of 25 ℃ . The limit value tolerances are subject to the usual var- iations. Physical Feature...
  • Page 19 EBW-E100 Display and Control Elements Display and Control Elements Figure 1: Display and control elements on the front of the device Position Description Reset key Power LED COM LED Signal LED Status LED Activity LED for LAN ext. Link LED for LAN ext.
  • Page 20 Display and Control Elements EBW-E100 Meaning of the display elements Colour Function flashing blinking Link 10/100 green 10 MBit/s 100 MBit/s MBit/s Activity not con- Data orange Activity connected nected traffic Power green Supply missing present green PPP link establishing...
  • Page 21 EBW-E100 Connections Connections Front Panel Connections Figure 2: Connections on the front panel of the device Position Description Ethernet port LAN 1 (RJ45, 10/100 BT) Ethernet port LAN 2 / ext. (RJ45, 10/100 BT) Table 6: Description of the connections on the front panel of the device...
  • Page 22 Connections EBW-E100 Terminal Connections on the Top Figure 3: Connections on the top of the device Terminal Designation Description 10 ... 48 VDC Power supply 10 V – 48 V DC Ground Reset Reset input Table 7: Description of the connections on the top of the device ...
  • Page 23 EBW-E100 Function Overview Function Overview The EBW-E100 provides you with the following functions:  Configuration via web interface command line (CLI) or configuration file All functions can be configured and set via a web interface or a command line interface (CLI). The access to the interface is protected with a user name and password query.
  • Page 24 Function Overview EBW-E100  Dynamic DSL connection set-up A DSL (PPPoE) connection can be established independently if required. The connection will be terminated again after a configurable idle time or after a configurable maximum connection time.  Dialling filters for DSL connection set-up The dialling filters allow to define, which data packets lead to a PPPoE connection set-up.
  • Page 25 EBW-E100 Function Overview  IPT protocol Support of communication via IPT (Internet-Protokoll Telemetrie). The router can connect to an IPT master as IPT slave and tunnel payload of the serial Ethernet gateway to another IPT slave.  Dynamic DNS update The assigned IP address can be deposited at a dynamic DNS service (e.g.
  • Page 26 Function Overview EBW-E100  HTTP and HTTPS proxy with URL filter The proxy is used to limit the access to web addresses for applications in the local network of the router, and to avoid connection timeouts. The protocols HTTP and HTTPS are supported.
  • Page 27 EBW-E100 Assembly Assembly This section describes how to mount the EBW-E100 to a DIN rail, connect the power supply and uninstall it again. Observe the instructions in the "Safety" section of this manual, in particular the "Safety Instructions for Electrical Installation"...
  • Page 28 EBW-E100 Mounting the device to the DIN rail How to mount the EBW-E100 to a DIN rail: Position the device at the DIN rail as seen in the following diagram. There are two snap-in hooks at the upper and lower edge of the DIN rail groove.
  • Page 29  The EBW-E100 is disconnected from the power supply. Removing the device from the DIN rail How to uninstall the EBW-E100 from a DIN rail in a switch cabinet:  You will need a small flat-blade screwdriver. ...
  • Page 30 The plastic spring of the snap-in hook is stretched. While you hold the plastic spring apart with the lower snap-in hooks, pull the device away from the DIN rail. Un-hook the device and take it off perpendicularly to the DIN rail.  The EBW-E100 is now removed.
  • Page 31 EBW-E100 Commissioning Commissioning This chapter describes how to activate the EBW-E100, i.e. how to connect it to a PC, and how to prepare it for the configuration. Connecting to a LAN and a PC How to connect the EBW-E100 to a PC for configuration and an external LAN.
  • Page 32  As an alternative, you may also configure your network card to "Automatic address allocation". The integrated DHCP server of the EBW-E100 will then allocate an address from the according address range to your network card.  Do not use the address 192.168.1.1; this is the factory default IP address of the device.
  • Page 33 EBW-E100 Operating Principle Operating Principle This chapter describes how to operate and configure the EBW-E100. Configuration and operation are performed using a web-based interface (web interface). The web interface itself is displayed and operated using a web browser. 11.1 Operating the Web Interface The web interface allows easy configuration using a web browser.
  • Page 34 In order to avoid this browser warning as well, you must enter the Common Name of the EBW-E100 to be accessed into the address bar of your browser. The Common Name must be connected with the IP address of the device that the URL leads to the correct device.

  • Page 35: Functions

    12.1.1 Configuring Web Interface Access The web interface is used to configure the EBW-E100. It will be protected against unauthorised access by requesting user name and password (alternatively also via a Radius server). The web interface can be configured for a configuration from a computer in the internal network or for remote configuration from the WAN via the HTTP or HTTPS protocol.

  • Page 36: Setting Ip Addresses

    12.1.2 Setting IP Addresses It must be possible to access the EBW-E100 in the LAN under a certain IP address. You must assign a static IP address for this. You can enter an IPv4 and an IPv6 address here. The router can configure one or several IPv6 addresses for itself using SLAAC (StateLess Address AutoConfiguration).

  • Page 37: Entering A Static Route

    Functions 12.1.3 Entering a Static Route You can define static routes for forwarding data packets in the EBW-E100, which are loaded during system start. Configuration via web interface (menu "Basic Settings", page "Routing") In order to enter a static route, enter in the section "Add new route" the Net address, the netmask as well as the Gateway into the respective fields for IPv4 or IPv6.

  • Page 38: Configuring Mac Filter

    Functions EBW-E100 12.1.5 Configuring MAC Filter A MAC filter can be enabled in the EBW-E100. This will then only accept packets at the local Ethernet interface that come from network devices that are explicitly permitted in the filter.  This is only effective for connections that are initiated by the device in the local LAN, not for connections that are initiated from the WAN side.

  • Page 39: Configuring Access Protection Via Radius Server

    The access to the web interface or command line interface (CLI) can be protected against unauthorised access using an optional Radius server in the network. The access data for the Radius server must be configured in the EBW-E100 for this. Configuration via web interface (menu "Basic Settings", page "Radius") In order to configure access protection via a Radius server, enter its address and port into the respective fields.

  • Page 40: Configuring Command Line Interface Cli Access

    12.1.7 Configuring Command Line Interface CLI Access Besides the configuration via the web-interface or configuration file, a EBW-E100 can also be configured via a CLI (Command Line Interface). It will be protected against unauthorised access by requesting user name and password (alternatively also via a Radius server).

  • Page 41: Lan (Ext)

    LAN ext interface. This IP address must be in the address range of the external LAN, into which the EBW-E100 shall route. The router can configure one or several IPv6 addresses for itself using SLAAC (StateLess Address AutoConfiguration).

  • Page 42: Configuring Dsl

    12.2.2 Configuring DSL The EBW-E100 can connect to a WAN using a DSL modem. The DSL modem is connected using the LAN ext interface. The device can communicate with the DSL modem via a PPPoE connection. You must configure the LAN ext interface for PPPoE operation for this.

  • Page 43: Configuring Leased Line Operation

    Functions 12.2.3 Configuring Leased Line Operation You can configure the EBW-E100 to permanently maintain the previously configured DSL connection. The connection will immediately be established the connection after system start in this operating mode. The device checks the connection for its function periodically. The connection check can be performed either via a DNS request of a host name or via PING at a host.

  • Page 44: Configuring A Periodical Dsl Connection Establishment

    Save your settings by clicking "OK". 12.2.5 Routing Routing is the core function of the EBW-E100. Routing means that incoming data packets are routed to certain network devices according to certain rules defined by you. The routes determine whereto packets are forwarded. A net address and netmask are used to distinguish, whether a route is applied to a IP packet or not.
  • Page 45 EBW-E100 Functions Configuration via web interface (menu "LAN (ext)", page "Routing") In order to configure an IPv4 default route, check the checkbox "Set default route to gateway" and enter the default gateway behind. The entry field is not visible in DSL operation.

  • Page 46: Setting Up A Dialling Filter

    Functions EBW-E100 12.2.6 Setting up a Dialling Filter The dialling filter can restrict the network traffic which could trigger a connection establishment. All packets with external destination initiate a connection establishment without dialling filter. If the dialling filter is enabled, only the packets, which are permitted by the rules, can initiate a connection establishment.

  • Page 47: Creating Or Deleting A Firewall Rule

    EBW-E100 Functions 12.2.7 Creating or Deleting a Firewall Rule A firewall is available for all connections via the LAN ext interface. It is used to prevent unauthorized data traffic. The logic of the firewall states that any data traffic is forbidden, which is not explicitly permitted through a rule. If you enable the firewall for the connection type "Dial-Out", only connections will be possible...

  • Page 48: Creating Or Deleting An Ip Forwarding Rule

    Functions EBW-E100 12.2.8 Creating or Deleting an IP Forwarding Rule IP forwarding rules create additional IP addresses at the LAN (ext) interface, if "static IP address" has been selected on the "LAN (ext)" page. Packets to one of these IP addresses will be forwarded to the IP address in the local LAN that is assigned to it.

  • Page 49: Creating Or Deleting A Port Forwarding Rule

    LAN, which have been specified in the port forwarding rules. Only the WAN IP address of the EBW-E100 is accessible from the WAN, if NAT is enabled for packets going into the WAN. The local terminal devices in the network of the device can still be accessed with this IP address using port forwarding.

  • Page 50: Defining The Exposed Host

    The exposed host contains all packets which have not been requested by the local network of the EBW-E100 or which have not been forwarded to a participant in the local network by a port forwarding rule. If no exposed host is configured, these incoming packets are discarded.

  • Page 51: Vpn

    The data is transmitted tamper-proof to a destination and cannot be read by third parties. You can configure the EBW-E100 for an OpenVPN, PPTP or IPsec connection. The exact proceeding for creating a certificate structure and configuring a VPN participant is described in a series of configuration guides.
  • Page 52 This will limit the communication to the port at which the OpenVPN tunnel is established (default setting: UDP port 1194). The EBW-E100 supports several authentication methods when establishing the VPN tunnel: Authentication type...

  • Page 53: Setting Up An Openvpn Server

    In order to use the OpenVPN server for a connection, check the checkbox "Activate OpenVPN server". In order to define the local port at the EBW-E100 as well as the port at the remote terminal, enter a value for the required port into the entry fields "Tunnelling over port (local / remote)"...
  • Page 54 In order to adjust the VPN ping interval, use the entry field "Ping interval". Enter the interval in the amount of seconds, in which the OpenVPN server of the EBW-E100 sends ping packets to the remote VPN terminal. The frequent ping is used to keep the connection open via several routers and gateways, which may participate in the connection and would close the channel in case there was no communication.
  • Page 55 EBW-E100 Functions In order to configure the authentication with certificates, select the radio button "Authentication based on certificate". It is indicated under the option here, whether the individual certificates and keys are present (green checkmark) or not (red cross). Present certificates can also be downloaded (blue arrow) or deleted again (red cross on white box).

  • Page 56: Setting Up An Openvpn Client

    12.3.4 Setting Up an OpenVPN Client You can use the EBW-E100 as OpenVPN client, if you want to connect to an OpenVPN server via an unsecured network. This section describes the set-up of an OpenVPN client. The basic settings are reasonable factory defaults, which you need to adjust to the VPN which will be connected to the EBW-E100.
  • Page 57 Enter an IP address or domain name into the "Alternative remote site" field for this. In order to define the local port at the EBW-E100 as well as the port at the remote terminal, enter a value for the required port into the entry fields "Tunnelling over port (local / remote)".
  • Page 58 In order to adjust the VPN ping interval, use the entry field "Ping interval". Enter the interval in the amount of seconds, in which the OpenVPN client of the EBW-E100 sends ping packets to the remote VPN terminal. The frequent ping is used to keep the connection open via several routers and gateways, which may participate in the connection and would close the channel in case there was no communication.
  • Page 59 EBW-E100 Functions In order to configure the authentication with certificates, select the radio button "Authentication based on certificate". It is indicated under the option here, whether the individual certificates and keys are present (green checkmark) or not (red cross). Present certificates can also be downloaded (blue arrow) or deleted again (red cross on white box).

  • Page 60: Pptp General

    12.3.6 Setting Up a PPTP Server The settings for the EBW-E100 as PPTP server are configured here. A maximum of 5 PPTP clients can log on to this server at the same time. However, it is possible to create more users, but only 5 tunnels can be active at the same time.

  • Page 61: Setting Up A Pptp Client

    EBW-E100 with its tunnel address. Configuration via web interface (menu "LAN (ext)", page "PPTP client") In order to use the EBW-E100 as PPTP client, check the checkbox "Activate PPTP client". In order to display the messages of the last connection, select the link "Display log of last connection".
  • Page 62 Functions EBW-E100  The default settings of MTU and MRU are suitable for most applications and do not need to be modified usually. In order to configure a connection check using a ping via ICMP protocol to a domain or an IP address, enter this into the entry field "Additional ICMP ping to".

  • Page 63: Setting Up Ipsec

    EBW-E100 Functions 12.3.8 Setting Up IPsec IPsec (Internet Protocol Security) is a security protocol for the safe communication via IP networks and can be used to set-up virtual private networks (VPN). Two subnets can be connected together using two suitable routers (e.g. INSYS MoRoS 2.1) via a secure tunnel.
  • Page 64 "hold", since no new incoming connection request can be accepted any more in case the existing connection has been terminated. In order to define a network behind the switch of the EBW-E100 to be tunnelled, enter this network with according netmask into the field "Local subnet".
  • Page 65 In order to mask the received packets with the local IP address of the EBW-E100, check the checkbox "Mask packets through tunnel". The recipient of the packets will see the local IP address of the EBW-E100 as sender than, not the address of the original sender from the local net of the remote terminal.
  • Page 66 Functions EBW-E100 In order to configure the authentication for an IPsec connection, select either the radio button "Authentication based on certificates" or the radio button "Authentication with pre shared key (PSK)“. The authentication with certificates can be used for the main mode. It is indicated under the option here, whether the individual certificates and keys are present (green checkmark) or not (red cross).

  • Page 67: Configuring A Gre Tunnel

    EBW-E100 Functions 12.3.9 Configuring a GRE Tunnel The Generic Routing Encapsulation protocol allows to transmit data transparently through an existing connection without changing the original packets. Configuration via web interface (menu "LAN (ext)", page "GRE") In order to enable a GRE tunnel, check the checkbox "Activate GRE tunnel".

  • Page 68: Messages

    12.4.1 Configuring the Message Dispatch The EBW-E100 can send an e-mail to any recipient on different events or trigger an SNMP trap. A series of pre-define events are available for this, like set-up of connections or VPN tunnels for example.

  • Page 69: Configuring E-Mail Dispatch

    Select from the drop-down list "Attachment" the respective log file to be attached to the e-mail. If this file is not present on the EBW-E100, the e-mail will be sent without attachment. Check the checkbox "Attach current status to message text", if the status page of the web interface is to be attached to...

  • Page 70: Configuring Snmp Trap Triggering

    12.4.3 Configuring SNMP Trap Triggering The EBW-E100 can trigger an SNMP trap that sends a message to any recipient on different predefined events. It is possible to create and manage a series of different combinations of recipient and event. The SNMP traps are described in the MIB (Management Information Base).

  • Page 71: Server Services

    12.5.1 Setting up DNS Forwarding You may use the EBW-E100 as DNS relay server. If it is configured as DNS server at the locally connected network devices, it will either forward the DNS requests to the previously configured DNS servers in the Internet, or will use the DNS server sent during the connection establishment.

  • Page 72: Dynamic Dns Update

    12.5.2 Dynamic DNS Update The EBW-E100 can forward the IP address, which it was allocated during the dial- in into the Internet, to a DynDNS provider, so it can be reached from the Internet with a domain name. This means that the network behind the router can always be reached with the same domain name from the Internet, also for dynamically allocated IP addresses (if incoming connections are not blocked by the provider).

  • Page 73: Setting Up The Dhcp Server

    DHCP server are controlled via the "Lease time". If there is already a DHCP server in the network, in which the EBW-E100 is used, this function must absolutely be disabled in the device. Otherwise, clients would let their IP address be assigned by a wrong DHCP server.

  • Page 74: Configuring The Router Advertiser

    (SLAAC) independently using these received prefixes. In order to support the configuration of the prefixes to be distributed, it will be displayed, which prefix is set in the EBW-E100 and which prefixes are indicated at the LAN (ext) interface. Configuration via web interface (menu "Server services", page "Router advertiser")

  • Page 75: Configuring A Proxy Server

    12.5.5 Configuring a Proxy Server The EBW-E100 provides a proxy server. This does not serve as a cache for frequently accessed websites. It is used to delay the connection timeouts for connections that load slowly and to filter undesired URLs (e.g. www.xyz.xx).

  • Page 76: Configuring An Url Filter

    Save your settings by clicking "OK". 12.5.7 Configuring IPT The EBW-E100 also allows data transfer via an IPT channel. It can act as IPT slave here. Configuration via web interface (menu "Server services", page "IPT") In order to enable IPT, check the checkbox "Activate IPT slave".
  • Page 77 "Increase reconnection interval". In this case, the interval between the connection attempts will increase (1, 5, 15, 30, 60 minutes). Otherwise, the EBW-E100 will try to establish a connection every minute. In order to specify the maximum time between IPT request and IPT...

  • Page 78: Configuring The Snmp Agent

    12.5.8 Configuring the SNMP Agent The EBW-E100 provides an SNMP agent that responds to incoming SNMP Get requests. All parameters that exist in the ASCII configuration file, can be read via SNMP Get requests (except user name and password of the web interface authentication).

  • Page 79: Configuring Mcip

    "Exclusively allow MCIP local". No MCIP connections will then be accepted via the WAN interface. Assign an Object ID to the objects contained in the EBW-E100 by entering this into the field behind the respective object. An OID is a number between 1001 and 65534.

  • Page 80: System Configuration

    12.6.1 Displaying the System Log The EBW-E100 allows to display the detailed system log in the menu "System" on the page "System data". The number of displayed lines and the update interval can be configured. Configuration via web interface (menu "System", page "System data") In order to view the detailed system messages via the web interface, click on the link "Show the extensive system log".

  • Page 81: Setting Time And Time Zone

    12.6.3 Setting Time and Time Zone The EBW-E100 has an internal clock to control time-controlled events. This clock must be set to ensure that time-controlled events are processed precisely to the desired time, and that system messages are dated correctly. The clock can be updated automatically via an NTP server from the Internet.

  • Page 82: Reset

    12.6.4 Reset You can reset the EBW-E100 via the web interface or by pressing the reset key on the front of the device. A software reset can be initiated by briefly pressing the reset key once. Pressing the reset key for at least three seconds initiates a hardware reset.

  • Page 83: Update

    Functions 12.6.5 Update You can update the EBW-E100 with a new firmware or provide a new configuration using the web interface. A detailed description about these processes can be found in the following sections "Updating the Firmware" and "Uploading the Configuration File"...

  • Page 84: Updating The Firmware

    Functions EBW-E100 12.6.6 Updating the Firmware You can update the firmware of the EBW-E100 manually. The firmware is a combination of operating system and programs, in which the device functions are implemented. You'll find the latest firmware under www.insys-icom.com/firmware. Note...

  • Page 85: Uploading The Configuration File

    E100, to replace the current configuration by the settings in the file. Uploading the Configuration File  You have a configuration file for your version of the EBW-E100. In the web interface under "System", switch to the page "Update". Click on Browse... in the "Manual update" section and select the configuration file (e.g.

  • Page 86: Download

    EBW-E100 12.6.8 Download You can download the complete configuration file of the EBW-E100 in binary, encoded form via the web interface. With this file, you can configure other, identical devices, or safely store a working configuration. Moreover, it is possible to download an ASCII text file of the configuration or an "empty"...

  • Page 87: Debugging

    Functions 12.6.9 Debugging Various tools of the EBW-E100 enable to analyse problems with network connections. The "PING" tool allows to send ICMP pings (ping packets). This enables to test, whether a specific machine is available in the network, easily. The "TRACEROUTE"...

  • Page 88: Monitoring

    EBW-E100 12.7 Monitoring The Monitoring App of the EBW-E100 is displayed in a separate browser window upon selecting the menu item "Monitoring". It is a software application that runs on the device and is configured independently from the device. It must be kept in mind that the functionality of the monitoring application can be affected by settings at the device (e.g.

  • Page 89: Maintenance, Repair And Troubleshooting

    Repair Send defect devices with detailed failure description to the source of supply of your device. If you have purchased the device directly from INSYS icom, send the device to: INSYS MICROELECTRONICS GmbH, Hermann-Köhl-Str. 22, 93049 Regensburg. Before dispatching the device: ...

  • Page 90: Waste Disposal

    Waste Disposal EBW-E100 Waste Disposal 14.1 Repurchasing of Legacy Systems According to the new WEEE guidelines, the repurchasing and recycling of legacy systems for our clients is regulated as follows: Please send those legacy systems to the following address, carriage prepaid:...

  • Page 91: Declaration Of Conformity

    EBW-E100 Declaration of Conformity Declaration of Conformity Hereby, INSYS Microelectronics GmbH declares that herein described device types are in compliance with Directives 2004/108/EC and 2011/65/EC. The full text of the EC Declaration of Conformity is available under the following Internet address:...

  • Page 92: Fcc Statement

    FCC Statement EBW-E100 FCC Statement Note: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 93: Licenses

    Licenses Licenses The software technologies and programs of the firmware used in the EBW-E100 are partly bound to the following licenses. The source code of the firmware components of the EBW-E100 which are bound to these licenses may be obtained from INSYS MICROELECTRONICS on request.
  • Page 94 Licenses EBW-E100 Activities other than copying, distribution and modification are not covered by this License; they are out- side its scope. The act of running the Program is not restricted, and the output from the Program is cov- ered only if its contents constitute a work based on the Program (independent of having been made by running the Program).
  • Page 95 EBW-E100 Licenses on) of the operating system on which the executable runs, unless that component itself accompanies the executable. If distribution of executable or object code is made by offering access to copy from a designated place, then offering equivalent access to copy the source code from the same place counts as distribution of the source code, even though third parties are not compelled to copy the source along with the object code.

  • Page 96: Gnu Library General Public License

    Licenses EBW-E100 11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHER- WISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM "AS IS"...
  • Page 97 EBW-E100 Licenses Finally, any free program is threatened constantly by software patents. We wish to avoid the danger that companies distributing free software will individually obtain patent licenses, thus in effect transforming the program into proprietary software. To prevent this, we have made it clear that any patent must be li- censed for everyone's free use or not licensed at all.
  • Page 98 Licenses EBW-E100 2. You may modify your copy or copies of the Library or any portion of it, thus forming a work based on the Library, and copy and distribute such modifications or work under the terms of Section 1 above, pro- vided that you also meet all of these conditions: ...
  • Page 99 EBW-E100 Licenses If such an object file uses only numerical parameters, data structure layouts and accessors, and small macros and small inline functions (ten lines or less in length), then the use of the object file is unre- stricted, regardless of whether it is legally a derivative work. (Executables containing this object code plus portions of the Library will still fall under Section 6.)
  • Page 100 Licenses EBW-E100 9. You are not required to accept this License, since you have not signed it. However, nothing else grants you permission to modify or distribute the Library or its derivative works. These actions are prohib- ited by law if you do not accept this License. Therefore, by modifying or distributing the Library (or any work based on the Library), you indicate your acceptance of this License to do so, and all its terms and conditions for copying, distributing or modifying the Library or works based on it.

  • Page 101: Other Licenses

    EBW-E100 Licenses THE LIBRARY AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GEN- ERAL, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR IN- ABILITY TO USE THE LIBRARY (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BE-...
  • Page 102 Licenses EBW-E100 "This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/)" THIS SOFTWARE IS PROVIDED BY THE OpenSSL PROJECT ``AS IS'' AND ANY EXPRESSED OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MER- CHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED.
  • Page 103 EBW-E100 Licenses The licence and distribution terms for any publically available version or derivative of this code cannot be changed. i.e. this code cannot simply be copied and put under another distribution licence [including the GNU Public Licence.]...

  • Page 104: Glossary

    Glossary EBW-E100 Glossary This describes the most important terms and abbreviations of this manual. APN: Access Point Name, computer name that provides cellular subscribers of the GPRS network with Internet access. AT command: Commands to devices such as modems to set up this device.
  • Page 105 EBW-E100 Glossary GSM: Global System for Mobile communications; cellular network for voice and data transmission. ICMP: Internet Control Message Protocol; protocol that is often used to con- trol a network. The program "ping" uses ICMP for example. IP address: Internet Protocol address; The IP address of a device in a network un- der which it can be accessed.
  • Page 106 Glossary EBW-E100 SCN: Service Center Number, phone number of the computer that accepts short messages (->SMS) via the GSM network and forwards them to the recipients. Server: Device that provides services, e.g. web server, to other devices (cli- ent). SMS: Short Message Service;...

  • Page 107: Tables And Diagrams

    EBW-E100 Tables and Diagrams Tables and Diagrams 19.1 List of Tables Table 1: Physical Features ..................18 Table 2: Technological Features ................18 Table 3: Description of the display and control elements on the front panel of the device ........................19 Table 4: Meaning of display elements ..............

  • Page 108: Index

    Index EBW-E100 Index Access data ........42 Connection timeout ......75 Access Point Name ....... 104 Daily connection termination ..44 Accessories ........17 Data direction ........47 Activity LED ....... 19, 20 Date ..........81 Additional information ....... 9 Dead peer detection ......
  • Page 109 EBW-E100 Index Encryption ......... 60, 61 IP address ... 32, 36, 61, 64, 72, 73, 76, Encryption algorithm ....53, 56 IP address range ......73 Encryption method ....54, 58 IP forwarding ......24, 48 Environment ......13, 27 IP packet .........
  • Page 110 Index EBW-E100 Monitoring App ......26, 88 Ping restart interval ....54, 58 Monitoring application ....88 Port ......49, 52, 53, 57, 105 MPPE..........60 Port forwarding ... 24, 49, 50, 105 MRU ........42, 60, 61 Port of the web interface ....35 MS-CHAP ........
  • Page 111 EBW-E100 Index Service Center Number ....106 System log ........80 Short-cut ........13, 89 System messages ..... 80, 81 Siemens LOGO!™ ......26 System time ........25 Siemens S7 ........26 TCP ..........106 Signal LED ......... 19, 20 TCP connection .......
