- Page 1 BS017 FUNCTIONAL TRAINER...
- Page 6 Item No. Description Item No. Description Right Stand Short handle Left Stand Long Lat Strap Right Guide Bar Triceps Rope Left Guide Bar Foot Lat Strap Right Slip Frame Lat Strap Left Slip Frame Shaft For Pulley Bracket Cross Brace Cable Assembly Hook Cross Brace Plastic Tube Guide Transverse beam...
- Page 7 Item No. Description Item No. Description Bumper Hex Bolts M8*95 Mount Sleeve Socket Head Cap Bolts M8*30 Weight Bumper Hex Bolts M8*20 Nylon Bumper Hex Bolts M8*15 Nylon Spacer Button Head Cap Screw M6*12 Six angle flange nut M12 Flat Head Cap Screw M6*15 Gourd hook φ8 Socket Set Screw M5*3 Weight Plate...
- Page 8 STEP 1 Item No. Description Item No. Description Right Stand Transverse beam Left Stand Hex Bolts M10*25 Cross Brace Spring Washer φ10 Hook Cross Brace Washer φ11*φ20*2...
- Page 9 STEP 2 Item No. Description Item No. Description Right Stand Hex Bolts M8*20 Left Stand Hex Bolts M8*15 Shroud Spring Washer φ8 L-shaped plate Washer φ9*φ16*1.5...
- Page 10 STEP 3 Item No. Description Item No. Description Long handle Triceps Rope Foot Lat Strap Short pull handle assembly Short handle Lat Strap Long Lat Strap...
