T I T A N R A N G E
S H E D A S S E M B L Y I N S T R U C T I O N S
6
X
6
X
6
X
4ft
=
190
6ft
=
190
8ft
=
190
x
150 cm
x
190 cm
x
255 cm

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Titan Series and is the answer not in the manual?

Questions and answers

Summary of Contents for BiGDUG Titan Series

  • Page 1 T I T A N R A N G E S H E D A S S E M B L Y I N S T R U C T I O N S 150 cm 190 cm 255 cm...
  • Page 2: Component List

    COMPONENT LIST Component illustrations are given as a visual guide only and are not in proportion PART NO. PART NAME Pair * QTY PER SHED SIZE PART NO. PART NAME Pair * QTY PER SHED SIZE 6X4 6X6 6X8 6X4 6X6 6X8 FRONT / REAR BASE CHANNEL LOWER ROOF PANEL SIDE BASE CHANNEL...
  • Page 3: Tools Required

    SHED ASSEMBLY INSTRUCTIONS PLEASE READ BEFORE COMMENCING SHED CONSTRUCTION 1. Check box contents against the component list. 2. Read the instructions thoroughly. 3. We recommend securing the shed to a concrete base or paving slabs. 4. To avoid cuts and abrasions wear protective gloves. 5.
  • Page 4: Site Preparation

    SITE PREPARATION We recommend that all our sheds are sited and fastened to a concrete base (4” or 100 mm think;) or to paving slabs. BASE AREA REQUIRED 6 X 4 ft 1900mm Wide x 1500mm Long 6 X 6 ft 1900mm Wide x 1900mm Long 6 X 8 ft 1900mm Wide x 2550mm Long...
  • Page 5: Base Assembly

    BASE ASSEMBLY Identify the base components – Part No’s (1) (2) (3) and (4). also M5 Roofing Bolts No (36). Place all the components near your prepared base site. Attach one base corner bracket (3) to each end of the two front/rear base channels (1), using M5 roofing bolts (36) as shown in Figure 2.
  • Page 6: Frame Assembly

    FRAME ASSEMBLY Select the four Corner Posts (9) and attach to the top of each post one of the four Top Gussets (8) as shown in Figure 5 using nut and bolt (36) (37). DO NOT TIGHTEN. Stand the corner post upright with the corner gusset at the top. Place the base of the corner post on top of the base assembly and fasten into position using two screws (38) as shown in Figure 6.
  • Page 7 CLADDING Carefully select a Side/Rear Panel (14) and, starting at the top of the shed, screw the Panel to the Corner Posts (9) as shown in Figures 11 & 12. The next panel is slid into position and hangs on the base of the first panel and is then secured into position as shown in Figure 12 using screws (38).
  • Page 8: Roof Assembly

    GABLE ASSEMBLY Locate the two pairs of Gables (18), the Door/Gable Rain Deflector (19) and the Gable Trim (20). Place one Door/Gable Rain Deflector on top of the Front/Rear Gable Support (12). Attach one pair of Gables (18) loosely to the Front/Rear Gable Support (12) at the front of the shed using Bolts (36) (37) as shown in Figures 16 &...
  • Page 9 ROOF ASSEMBLY CONTINUED Carefully lift the Bottom Roof Panel (25) into position resting it on top of the Gables (18) each end and the Side Panel/Roof Support (22) as shown in Figure 19. Fix the bottom of the panel at each end only using a Stainless Steel Bolt (39) and Nut (37) with a Sealing Washer (26) fitted underneath the head as shown in Figure 19a.
  • Page 10 DOOR & DOORWAY FITTINGS Select the two Door Pillar Cover/Slam Pieces (30) and slot one onto the left hand Door Frame and one to the right hand frame. Secure into position inside the shed using 3 Screws (38) on each as shown in Figure Fit the Door Step (5) to the front base (1) as shown in Figure 23.
  • Page 11 DOOR BAR & HANDLE FITTING Locate the Door Handle (35) and the Door Bar Assembly (34). Fit the Door Handle to the Door as shown in Figure 26. Push the Door Bar up through the top hole in the Door and down through the bottom hole as shown in Figure 27 and 28.
