- Page 1 Assembly and Operating Instructions ECON F1 IP x4 Druck Nr. 29343282en/ - 37.06...
-
Page 2: Table Of Contents
Contents Installation of the control unit ..............12 Electrical installation ................13 Operation ....................14 Start-up ....................15 Switching on the unit for the first time ............15 Manual Selection of Light Color ..............15 Automatic Selection of Light Color ............15 Wiring diagram .................. -
Page 3: Installation Of The Control Unit
The colored light control units are delivered equipped for a voltage of 230 V 50 Hz as a standard and must be separately fuse protected against 10 A. Installation and connection of the sauna systems and other electrical equipment may be undertaken only by a expert; this is subject to VDE 0100, Part 703/2006-2 Sauna systems may be connected to the power supply only by hard wire. -
Page 4: Electrical Installation
The lower part is finally fastened to the cabin wall through the two lower pre-drilled holes. If the sauna cabin is not equipped with cable conduits for connecting lines, these lines must be laid visibly on the cabin wall. For this, the three mounting holes are pre- drilled also, as shown in Illust. -
Page 5: Operation
Operation 1 - 10 LEDs for color sequence time Ready LED Button functions ON/OFF switch Single color and automatic mode Program button Adjustment buttons LEDs for color LEDs for color sequence time Ready LED ON/OFF switch Single color and min. automatic mode Program button Adjustment... -
Page 6: Start-Up
Automatic Selection of Light Color Start-up After checking all connections again, Press the light button to activate connect the unit to the line power by automatic selection of the light color. switching on the circuit breakers and/or During automatic operation 5 LED's main switch. - Page 7 Effect of Colors The psychological influence of the colors is perceived by the eyes. From there the color radiation is transferred to the brain in a complex process, where it develops its effect in the form of certain impressions and energy. The colors affect the nervous system vitalizing the body's resistance.
- Page 8 Connection Schematic Electronic circuitry Line power feed 3 x 1.5 mm² Colored light unit 230 V/50 Hz Observe coding of feed lines to colored light unit Illust. 7 Attention! Dear customer, according to the valid regulations, the electrical connection of the sauna heater and the control box has to be carried out Wiring codes: green/yellow...
- Page 9 Direct warranty processing with our service department is in this case not possible. Equipment start-up date: Stamp and signature of the authorized electrician: Service address: EOS-Werke Günther GmbH Adolf-Weiß-Str. 43 35759 Driedorf-Germany tel +49 (0) 2775 82 240 fax +49 (0) 2775 82 455 servicecenter@eos-werke.de www.eos-werke.de...
