- Page 1 MSC 1512 v.1.1 MSC 12V/1,5A-24V/1A/M PSU module for CCTV. Edition: 2nd (5 Mar 2012) Supersedes the 1st (8 Apr 2009) edition...
- Page 2 1.1. General description The MSC 1512 PSU module is intended for supplying devices that require voltage of 12V or 24V DC. The module is designed as a supplying component in CCTV systems, KD access control, SSWiN alarm systems, etc. It is intended to be wall-mounted or fixed inside a device (e.g.
- Page 3 MSC1512 1.2. Block diagram (fig.1). Fig.1. Block diagram of the PSU module. 1.3 Description of components and connectors Table 1. The components of the PSU module (see fig. 2). Element no. Description J-Uout, pin- AUX output voltage adjustment •...
- Page 4 MSC1512 1.4. Specifications: - electrical specifications (tab.3) - mechanical specifications (tab.4) - operating specifications (tab.5) Electrical specifications (tab. 3). Supply voltage 16V÷30V/AC or 22V÷42V/DC @ AUX=12VDC 24V÷30V/AC or 33V÷42V/DC @ AUX=24VDC (measured at the ~AC~ terminals of the module) Current consumption 1.9A@16V/AC–1A@30V/AC max.
- Page 5 MSC1512 As the PSU module is designed for a continuous operation and is not equipped with a power-switch, therefore an appropriate overload protection shall be guaranteed in the power supply circuit. Moreover, the user shall be informed about the method of unplugging (most frequently through separating and assigning an appropriate fuse in the fuse-box).
- Page 6 MSC1512 Fig.4. Typical application of the MSC1512 module and the PSAC04244 power supply unit. (Conditions: camera’s power (a group of cameras) P=13W max.).
- Page 7 MSC1512 3. Operating status indication. The PSU is equipped with 2 LEDs that indicate operating status of: AC and AUX. • AC- red diode: Under normal status (AC power) the diode is permanently illuminated. The absence of AC power is indicated by the AC diode going out.
- Page 8 WEEE separately. GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a two-year warranty for the equipment, starting from the initial product date of purchase placed on the receipt.
