Start Here
Quickstart Guide - AyrMesh
Check Contents of the box:
1. ReceiverC
2. Power Supply
3. (2) Ethernet Cables
4. Metallic strap
1
3
2
4
Turn over for shorter instructions
®
ReceiverC
Open the door on the bottom of the Receiver -
just put your thumb on the grip lines on the
door, press gently, and pull. The MAC address is
inside the bottom of the door. Write down the
MAC address of your Receiver here (if it's not
here already) and store it with these directions.
MAC Address
If you don't have an account on AyrMesh.com,
create one now using a device connected to your
network (not a cellphone unless it's connected to
your router via WiFi):
20:0D:B0:00:00:00
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AYRSTONE AyrMesh ReceiverC
Summary of Contents for AYRSTONE AyrMesh ReceiverC
- Page 1 Turn over for shorter instructions Start Here Quickstart Guide - AyrMesh ® ReceiverC Open the door on the bottom of the Receiver - Check Contents of the box: just put your thumb on the grip lines on the door, press gently, and pull. The MAC address is inside the bottom of the door.
- Page 2 Assemble the ReceiverC and initialize Plug an Ethernet cable into either port on The door of your the Receiver - slide in until it clicks in place: Receiver should already be open; if it's not, please open it: DO NOT FORCE CONNECTORS IN OR OUT OF PORTS! Use another Ethernet cable to connect...
- Page 3 Make Sure ReceiverC is Working It usually takes about 1-2 minutes for the The signal lights (4 top lights) will start out Receiver to check in and show up on "running" from bottom to top (or left to right if it's AyrMesh.com, but sometimes it takes a bit laying down).
- Page 4 Signal lights on the ReceiverC The Power light should be on steady and the signal lights indicating signal strength as Top Signal light shown: Third Signal light Second Signal light No lights - no signal First Signal light First Signal light - very weak signal Wireless light Second Signal light - fair signal LAN light...
- Page 5 IP subnets and NAT. - Check for network loops - commonly caused by devices with multiple ways to connect to the network (e.g. laptops, printers, or cameras with both Ethernet and WiFi) See http://support.ayrstone.com for additional information, hints, and troubleshooting tips.
- Page 6 (which must be kept dry) to the Receiver - remember to leave a "drip loop" where the cable enters the building to prevent water from coming down the cable inside. Drip Loop See http://support.ayrstone.com for additional information, hints, and troubleshooting tips.
Need help?
Do you have a question about the AyrMesh ReceiverC and is the answer not in the manual?
Questions and answers
Been over 30 minutes and receiver C will not check in. Lights are flashing as described as if it is trying to check in but will not. I have manually entered the MAC address, added the device It states "no checkin yet". All 4 green lights are on, flashing LAN and occasional WAN flicker. 2 signal red lights and 2 signal green lights are alternating every second. I have a HubDuo already set up on top of the house.
If the AYRSTONE ReceiverC is not checking in and the lights are flashing, wait up to 5 minutes. If it still doesn't check in, try adding it manually using the MAC address.
