DeFelsko PosiTest HHD Verifier Instruction Manual

The PosiTest HHD Verifier is a calibrated high voltage meter used to verify
operating voltage of both Pulse DC and Continuous DC holiday detectors in the
range from 500 to 35,000 Volts.
ALWAYS ensure that the ground lead is plugged into the PosiTest
WARNING:
HHD Verifier and that the other end of the ground lead is connected to the ground
lead of the high voltage holiday detector that is being verified. Failure to ensure
proper grounding may result in electrical shock.
DO NOT touch the TIP of the probe or the RED High Voltage Shield
WARNING:
with bare hands while the probe is in contact with a high voltage source. Electrical
shock could occur if operator touches the tip or shield with bare hands while in use.
DO NOT use this equipment in damp, wet or rainy conditions.
WARNING:
Electrical shock could occur if the operator uses this equipment in damp, wet or
rainy conditions.
DO wear gloves and appropriate footwear
IMPORTANT:
Instruction Manual v. 1.0
Display
Power Button
Ground (earth) wire jack

Introduction

Introduction
Probe Tip
RED High Voltage Shield
