Campfire
Screen
©
2010 Steelcase Inc.
Grand Rapids, MI 49501 U.S.A.
Printed in U.S.A.
1
2.
Orient the cover to the frame.
NOTE: A "LH" or "RH" sticker is located
on the bottom of the frame. A
corresponding LH/RH tag is located on the
fabric sock.
NOTE: The 2" x 2" Velcro piece is the
front inside corner.
2
COVER
FRAME
R
Page 1 of 3
939500550 Rev B
Advertisement
Table of Contents
Related Manuals for Steelcase Turnstone Campfire Screen
Summary of Contents for Steelcase Turnstone Campfire Screen
- Page 1 LH/RH tag is located on the fabric sock. NOTE: The 2" x 2" Velcro piece is the FRAME front inside corner. © 2010 Steelcase Inc. Grand Rapids, MI 49501 U.S.A. Page 1 of 3 Printed in U.S.A. 939500550 Rev B...
- Page 2 Drape cover over the frame Flip the unit upside down. Pull the cover over the angle side. Align the top seams to the top of frame. Pull the inside corner (over the glide). GLIDE Page 2 of 3 939500550 Rev B...
- Page 3 Pull the cover over the 4" side. "Pull tightly" and secure the inside velcro (2" x 2" piece). Attach the remaining velcro pieces. NOTE: If there is looseness toward the bottom of the inside V, tighten up further the two Velcro pieces on either side of the center 2"...
