- Page 1 Installation and User Manual Navigation Light Control Panel TEF 4720 - TEF 4722 - TEF 4730 - TEF 4732 Signal Light Control Panel TEF 4740 Version 2.2 R. STAHL TRANBERG AS October 2017 Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved.
- Page 2 AS, Technical department R. STAHL TRANBERG AS has made every effort to provide accurate information, but makes no claims as to the accuracy or completeness of this information. R. STAHL TRANBERG AS disclaims liability for errors, omissions, misinterpretation or misuse of this information by others.
-
Page 3: Table Of Contents
ECTION ECHNICAL DATA 4.06 ..................234 ECTION PARE PARTS CHAPTER V. TEF 4732 ....................247 5.01 ..................248 ECTION NTRODUCTION 5.02 ................252 ECTION YSTEM OVERVIEW Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 3 of 27... - Page 4 ECTION NSTALLATION 6.05 .................. 342 ECTION ECHNICAL DATA 6.06 ..................352 ECTION PARE PARTS CHAPTER VII. ADDITIONAL INFORMATION ............... 364 7.01 ..............366 ECTION ECHNICAL LARIFICATIONS Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page iv of 27...
-
Page 5: Chapter I. Introduction
TEF 4740 is for controlling signal lights and for connection of 230VAC (115VAC) power supply. All panels are tested according to IEC60945 and ‘Det Norske Veritas’ certification notes. The control panels are designed and manufactured by R. STAHL TRANBERG AS. Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 5 of 27... -
Page 6: Tef 4720
Note: All panels are custom made. Refer to drawings for the specific system for overview and connections. Section 2.02 System overview Section 2.03 Functional description Power supplies Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 6 of 27... -
Page 7: Voltage Compensation
Ref. ‘Section 2.08’. This technique also allows using cables with smaller cross-section than typically for 24V supply. TEF4720 is modified for voltage compensation by R. Stahl Tranberg A.S. R. Stahl Tranberg A.S. can assist calculating voltage compensation. -
Page 8: Section 2.05 Installation
Max. power consumption: 8 circuits: 340W 12 circuits: 500W 16 circuits: 660W Load: Filament lamps 25-40W For smaller loads on request Outgoing fuses: 6.3A Fast acting. 5x20mm ceramic. Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 8 of 27... -
Page 9: Section 2.07 Spare Parts
Supply selector card P130 Ver2: 4813 Alarm card P40 Ver2: 50290089 Current sensing card P41: 2935 LED card P42: 3029 LED card P43 Ver2: 4815 Buzzer card P44 Ver2: 4814 Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 9 of 27... -
Page 10: Section 2.08 Auxiliary Equipment
400VA 230V 50/60Hz 0V-22V-24V-26V-28V-30V-32V 50860028 500VA 230V 50/60Hz 0V-22V-24V-26V-28V-30V-32V 50860032 700VA 230V 50/60Hz 0V-22V-24V-26V-28V-30V-32V 50860081 1000VA 230V 50/60Hz 0V-22V-24V-26V-28V-30V-32V Transformers for other voltages delivered on request. Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 10 of 27... -
Page 11: Tef 4730
TEF 4730 is for controlling double tier navigation lights and for connection of 24VAC/DC main and emergency power supplies. Note: All panels are custom made. Refer to drawings for the specific system for overview and connections. Section 3.02 System overview Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 11 of 27... -
Page 12: Section 3.03 Functional Description
Ref. ‘Section 2.08’. This technique also allows using cables with smaller cross-section than typically for 24V supply. TEF4730 is modified for voltage compensation by R. Stahl Tranberg A.S. R. Stahl Tranberg A.S. can assist calculating voltage compensation. -
Page 13: Section 3.05 Installation
Max. power consumption: 2x8 circuits: 340W 2x12 circuits: 500W 2x16 circuits: 660W Load: Filament lamps 25-40W For smaller loads on request Outgoing fuses: 6.3A Fast acting. 5x20mm ceramic. Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 13 of 27... -
Page 14: Section 3.07 Spare Parts
50290089 Current sensing card P41: 2935 LED card P42: 3029 LED card P43 Ver2: 4815 Buzzer card P44 Ver2: 4814 Fused terminal block: 50281172 + 3287 Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 14 of 27... -
Page 15: Auxiliary Equipment
400VA 230V 50/60Hz 0V-22V-24V-26V-28V-30V-32V 50860028 500VA 230V 50/60Hz 0V-22V-24V-26V-28V-30V-32V 50860032 700VA 230V 50/60Hz 0V-22V-24V-26V-28V-30V-32V 50860081 1000VA 230V 50/60Hz 0V-22V-24V-26V-28V-30V-32V Transformers for other voltages delivered on request. Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 15 of 27... -
Page 16: Tef 4722
Both power supplies are constantly monitored. If a power supply is missing, the alarm relay activates and a red LED lights up. When the selected (by the main switch) power supply fails, an Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 16 of 27... -
Page 17: Section 4.04 Installation
Dimensioning fuse and cable depends on number and power of navigation lights connected. Add up power of navigation lights and add 20W for total power for the system. Navigation lights Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 17 of 27... -
Page 18: Section 4.05 Technical Data
Section 4.06 Spare parts Description Part No. Main switch: 50230083 Circuit switch: 50230008 Test-button: 50230029 Dimmer potentiometer: 50211028 Main card P91: 9 circuits: 4818 13 circuits: 4817 Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 18 of 27... - Page 19 13 circuits: 4820 16 circuits: 4821 Transformer card P99: 3425 Power relay: 50231040 + 50231034 + 50231035 Fused terminal block: 50281172 + 50281173 Fuse 4.0A 5x20mm: 50232003 Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 19 of 27...
-
Page 20: Chapter V. Tef 4732
Both power supplies are constantly monitored. If a power supply is missing, the alarm relay activates and a red LED lights up. When the selected (by the main switch) power supply fails, an Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 20 of 27... - Page 21 20W for total power for the system. Note: Main and spare lights are never on simultaneously, so spare lamps is not necessary to include in calculating total power. Navigation lights Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 21 of 27...
- Page 22 192 x 384 x 160 mm Weight: Max. 6.5 kg Section 5.06 Spare parts Description Part No. Main switch: 50230083 Circuit switch: 50230024 Test-button: 50230029 Dimmer potentiometer: 50211028 Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 22 of 27...
- Page 23 13 circuits: 3434 16 circuits: 3382 Transformer card P99: 3425 Power relay: 50231040 + 50231034 + 50231035 Fused terminal block: 50281172 + 50281173 Fuse 4.0A 5x20mm: 50232003 Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 23 of 27...
-
Page 24: Section 5.01 Introduction
TEF 4740 is constructed for controlling signal lights and for connection to 230VAC (115VAC) power supply. Note: All panels are custom made. Refer to drawings for the specific system for overview and connections. Section 6.02 System overview Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 24 of 27... - Page 25 The panel is constructed for filament lamps, 20-85W. The panel can be modified for smaller loads. For other types of loads the alarm circuits are disabled. Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 25 of 27...
- Page 26 Contact R. Stahl Tranberg A.S Transformer card P99: 3467 Power relay: 50231040 + 50231034 + 50231035 Fused terminal block: 50281172 + 50281173 Fuse 4.0A 5x20mm: 50232003 Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 26 of 27...
- Page 27 Strandsvingen 6 Strandsvingen 6 N-4032 Stavanger N-4032 Stavanger NORW AY NORW AY Tel: +47 51 57 89 00 Fax: +47 51 57 89 50 info@stahl-tranberg.com www.stahl-tranberg.com Copyright © 2009-2017 R. STAHL TRANBERG AS. All rights reserved. Page 27 of 27...
