Summary of Contents for ADDAC System ADDAC812A
- Page 2 ADDAC812A Assembly Guide July.2017 Parts included in the kit: 1x Front Panel 2x Pcbs (front and back) 1x 12mm male/female spacer 1x 12mm female/female spacer 1x 10mm female/female spacer 3x M3 fiber washer 6x M3 screws 4x 4 pin male pinheaders...
- Page 3 ADDAC812A Assembly Guide STEP 2: Place all leds as show in the picture below. STEP 3: Place the four jacks in the pcb and attach the front panel. Hold the front panel in place by tightening the bottom screw. Also tighten the jack nuts and solder one leg of the top jack, this will keep the front panel secure to the pcb.
- Page 4 ADDAC812A Assembly Guide STEP 5: To help soldering the leds with the flat top matching the panel, have a few a standard business/credit/debit cards at hand and place them between the last nut and the bottom screw. STEP 6: Force the pcb against the cards and solder one leg of each led.
- Page 5 ADDAC812A Assembly Guide STEP 7: After one leg of each led is soldered check the front of the module to verify if all leds are aligned. STEP 8: Next cut the soldered leg of all leds, this will help soldering the second leg.
- Page 6 ADDAC812A Assembly Guide STEP 10: Solder the remaining jack legs. STEP 11: Locate and place the Power connector on the back pcb like shown below. STEP 12: Solder the Power connector. ADDAC SYSTEM page 6...
- Page 7 ADDAC812A Assembly Guide STEP 13: Place the top spacer and hold it with a screw. STEP 14: Locate and connect all pinheaders like shown below. STEP 15: Place the connectors of the front pcb, attach the back pcb on top and hold the two pcbs by screwing the two spacers with two screws.
- Page 8 ADDAC812A Assembly Guide STEP 13: Solder all pinheaders on both top and bottom pcbs. Congratulations, you’re done! ADDAC SYSTEM page 8...
-
Page 9: Assembly Guide
For feedback, comments or problems please contact us at: addac@addacsystem.com ADDAC812A ASSEMBLY GUIDE Revision.01 July.2017...
