  • Page 1 Active Parallel Multi-Function Filter AFQm INSTRUCTION MANUAL (M217B01-03-21A)
  • Page 2 AFQm Instruction Manual...

  • Page 3: Safety Precautions

    CIRCUTOR, SA reserves the right to make modifications to the device or the unit specifications set out in this instruction manual without prior notice. CIRCUTOR, SA on its web site, supplies its customers with the latest versions of the device specifica- tions and the most updated manuals.

  • Page 4: Table Of Contents

    AFQm CONTENTS SAFETY PRECAUTIONS ���������������������������������������������������������������������������������������������������������������������������������������������������������3 DISCLAIMER ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������3 CONTENTS �����������������������������������������������������������������������������������������������������������������������������������������������������������������������������4 REVISION LOG �����������������������������������������������������������������������������������������������������������������������������������������������������������������������6 SYMBOLS �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������6 1�- VERIFICATION UPON RECEPTION ������������������������������������������������������������������������������������������������������������������������������������ 7 1�1�- RECEPTION PROTOCOL ��������������������������������������������������������������������������������������������������������������������������������������������� 7 1�2�- TRANSPORT AND HANDLING ����������������������������������������������������������������������������������������������������������������������������������� 7 1�3�- STORAGE ������������������������������������������������������������������������������������������������������������������������������������������������������������������9 2�- PRODUCT DESCRIPTION ����������������������������������������������������������������������������������������������������������������������������������������������� 10 3�- DEVICE INSTALLATION �������������������������������������������������������������������������������������������������������������������������������������������������� 14 3�1�- PRELIMINARY RECOMMENDATIONS ����������������������������������������������������������������������������������������������������������������������...
  • Page 5 AFQm 6�7�- POWER AND COS ɸ OF LOAD �������������������������������������������������������������������������������������������������������������������������������52 6�8�- VOLTAGE HARMONICS �������������������������������������������������������������������������������������������������������������������������������������������53 6�9�- CURRENT HARMONICS (MAINS) ���������������������������������������������������������������������������������������������������������������������������53 6�10�- CURRENT HARMONICS (LOAD) ����������������������������������������������������������������������������������������������������������������������������54 6�11�- TABLE OF HARMONICS �����������������������������������������������������������������������������������������������������������������������������������������54 6�12�- WAVE SHAPE OF MAIN CURRENT ������������������������������������������������������������������������������������������������������������������������55 6�13�- WAVE SHAPE OF LOAD CURRENT ������������������������������������������������������������������������������������������������������������������������55 6�14�- MAINS PHASORS �������������������������������������������������������������������������������������������������������������������������������������������������56 6�15�- LOAD PHASORS ���������������������������������������������������������������������������������������������������������������������������������������������������56 6�16�- ALARMS ���������������������������������������������������������������������������������������������������������������������������������������������������������������57...

  • Page 6: Revision Log

    AFQm REVISION LOG Table 1: Revision log� Date Revision Description 10/18 M217B01-03-18A Initial Version Change in the following sections: 03/19 M217B01-03-19A 2.- 3.2.1.1. - 3.2.1.3. - 3.4.3. - 3.7. - 3.8. - 3.8.1. - 3.8.2. - 4.1.3. - 6.17. - 8.1.

  • Page 7: 1�- Verification Upon Reception

    Perform an external and internal visual inspection of the device prior to connecting it. If any problem is noticed upon reception, immediately contact the transport com- pany and/or CIRCUTOR's after-sales service. 1�2�- TRANSPORT AND HANDLING The transport, loading and unloading and handling of the device must be carried out with proper precautions and using the proper manual and mechanical tools so as not to damage it.
  • Page 8 AFQm The centre of gravity of some devices may be found at a considerable height. There- fore, when handling with a forklift, it is recommended that the device be securely fastened and that no abrupt manoeuvres made. The device should not be lifted more than 20 cm off the ground When unloading and moving the device, use a forklift with forks long enough to support the entire length of the base.

  • Page 9: 1�3�- Storage

    AFQm 1�3�- STORAGE The device should be stored according to the following recommendations:  Avoid placing them on uneven surfaces. Do not store them in outdoor areas, humid areas or areas exposed to splashing water. Avoid hot spots (maximum ambient temperature: 50ºC) Avoid salty and corrosive environments.

  • Page 10: 2�- Product Description

    AFQm 2.- PRODUCT DESCRIPTION The AFQm active multi-function filters can be used to: Reduce the harmonic currents up to order 50. Correct the unbalanced current consumption in each phase of the electrical installation. Correct the power factor. For both backward (inductive) and forward (capacitive) currents. There are different models of the device, for different currents: ...
  • Page 11 AFQm Table 4:Relation of models AFQm of 60A� 3 Wires 4 Wires Mains voltage Model ( L1, L2, L3) ( L1, L2, L3, N) (Un) AFQm-3WF-060M-480 208 ... 480 V  AFQm-4WF-060M-400 208 ... 400 V   70 A filters, The device features: - 3/4-wire multifunction, for installation in three-phase mains with or without neutral.
  • Page 12 AFQm  100 A filters, The device features: - 3/4-wire multifunction, for installation in three-phase mains with or without neutral. - Parallel installation of up to 100 devices. - LCD touch display, to view the parameters. - RS-485 and Ethernet communications. - EMI filters�...
  • Page 13 AFQm  140 A, 200 A, 210 A, 280 A, 300 A and 400 A filters, The 200A is a Cabinet model with two 100A devices connected in parallel; the 300A model has three devices connected, and the 400A model has four. The 140A is a Cabinet model with two 70A devices connected in parallel;...

  • Page 14: 3�- Device Installation

    AFQm 3.- DEVICE INSTALLATION 3�1�- PRELIMINARY RECOMMENDATIONS The device installation and the maintenance operations must only be carried out by authorised and qualified personnel� In order to use the device safely, it is critical that individuals who handle it follow the safety measures set out in the standards of the country where it is being used, use the personal protective equipment necessary (rubber gloves, face protection and approved flame-resistant clothing) to prevent injuries due to electric shock or electric arc due...

  • Page 15: 3�2�- Installation Location

    AFQm 3�2�- INSTALLATION LOCATION The device must be installed in an environment where the temperature outside the cabinet is between -10ºC and 45ºC, with a maximum humidity of 95% without condensation. Do not install the device close to a hot spot and keep it out of direct sunlight. Install the AFQm in a place protected from water, dust, flammable liquids, gases and corrosive substances.
  • Page 16 AFQm It should be noted that, depending on the installation conditions in the cabinet and in the room where this is placed, the outflows of hot air may be sucked back in by the device’s fans, causing a feedback of hot air that will lower the performance of the device. It is also necessary to bear in mind the power dissipated by the device when choosing where to install it, to ensure proper air recirculation, to make sure that the intake air is a suitable temperature.

  • Page 17: 3�3�- Storage For Long Periods

    AFQm 3�3�- STORAGE FOR LONG PERIODS If the device is not installed after receipt, the following recommendations must be observed to keep the device in a good state: Keep the device in a dry atmosphere and at a temperature of between -20ºC and 50ºC. Avoid exposure to direct sunlight.

  • Page 18: 3�4�2�- Rack-Type Afqm

    AFQm Fixing screws Fixing screws Figure 5: Installation Wall-type AFQm� Use 4 M8 fixing screws. The ventilation grilles must not obstructed or covered at any time. 3�4�2�- RACK-TYPE AFQm The Rack-type AFQm should be installed in a 19” rack cabinet. The height of the device is equivalent to 9U.

  • Page 19: 3�4�3�- Cabinet-Type Afqm

    AFQm Fit the device with the help of another person. 4�- Fasten the device to the points provided for this purpose. Use 4 M6 fixing screws. 3�4�3�- CABINET-TYPE AFQm The Cabinet-type AFQm models are free-standing cabinets with 4 bearing supports on the floor. The mounting surface must be solid, support the device’s weight and be level.

  • Page 20: 3�5�- Connection

    AFQm 3�5�- CONNECTION Wall and Rack type AFQm models: Use cables of a cross-section suitable for the rated current of the filter and that comply with the standards of the country in which they are being installed. The earth conductor must have at least the same cross-section as the phase conduc- tors.
  • Page 21 AFQm The correct connection of the current transformers is vital for the AFQm filters to op- erate properly. If the phases L1, L2 and L3 are switched in the secondary, the filter will not work properly. The AFQm devices have built-in fuse overcurrent protection. Install external protection according to the type of installation, the facility’s maximum short-circuit current, the maximum fuse current, and the regulations in force at the place of installation.

  • Page 22: 3�6�- Device Terminals

    AFQm 3�6�- DEVICE TERMINALS 3�6�1�- WALL-TYPE AFQm: AFQm-xxx-030M, AFQm-xxx-060M and AFQm-xxx-100M The connection terminals of the Wall-type AFQm model are located on the lower face of the device. The device has a terminal cover on the mains connection terminals. Figure 8: Terminal cover, AFQm-xxx-030M and AFQm-xxx-060M� Figure 9: Terminal cover, AFQm-xxx-100M�...
  • Page 23 AFQm Table 12:List of terminals� Device terminals 1: ETHERNET, Ethernet Connector 11: S2, Current input L2 2: R , Terminator switch for parallel connection 12: S1, Current input L3 3: IN, Input for parallel connection 13: S2, Current input L3 4: OUT, Output for parallel connection 14: L1, Mains connection L1 5: A, RS-485 communications...

  • Page 24: 3�6�2�- Rack-Type Afqm: Afqm-Xxx-100R

    AFQm 3�6�2�- RACK-TYPE AFQm: AFQm-xxx-100R The AFQm-xxx-100R connection terminals are located at the front and rear of the device. Table 13:List of terminals� Device terminals 1: ETHERNET, Ethernet Connector 11: S2, Current input L2 2: R , Terminator switch for parallel connection 12: S1, Current input L3 3: IN, Input for parallel connection 13: S2, Current input L3...

  • Page 25: 3�6�3�- Cabinet-Type Afqm: Afqm-Xxx-100C, Afqm-Xxx-200C, Afqm-Xxx-300C And Afqm-Xxx-400C

    3�6�3�- CABINET-TYPE AFQm: AFQm-xxx-100C, AFQm-xxx-200C, AFQm-xxx-300C AND AFQm-xxx- 400C CIRCUTOR has two types of cabinets: cabinets with connections at the top and cabinets with connec- tions at the bottom. There are sliding windows at the bottom of the cabinet so that the connection wiring can be slotted inside, .
  • Page 26 AFQm nections at the top) Figure 16 Cabinet with connections at the bottom Cabinet with connections at the top Figure 16: Screws� Once the front cover is open, the device’s terminals can be accessed, Figure 17, Figure 18 Figure 19 Figure 17:AFQm (100, 200, 300 and 400A) cabinet-type terminals (connections at the bottom)�...

  • Page 27: 3�6�4�- Cabinet-Type Afqm: Afqm-Xxx-070C, Afqm-Xxx-140C, Afqm-Xxx-210C And Afqm-Xxx-280C

    AFQm Figure 19:AFQm cabinet-type earth terminal� Table 14:List of terminals� Device terminals 1: S1, Current input L1 6: S2, Current input L3 2: S2, Current inpu 7: L1, Mains connection L1 3: S1, Current input L2 8: L2, Mains connection L2 4: S2, Current input L2 9: L3, Mains connection L3 5: S1, Current input L3...
  • Page 28 AFQm Protectores de sobretensión Surge voltage protection Figure 20: Screws� The green lights on the surge voltage protection indicate that they are working cor- rectly. Immediately replace those whose indicator is red, see “10.8.- MAINTENANCE OF SURGE PROTECTIVE DEVICES:70A, 140A, 210A AND 280A CABINET AFQm” Once the front cover is open, the device’s terminals can be accessed, Figure 21 Figure 21: AFQm (70, 140, 210 and 280A) cabinet-type terminals�...

  • Page 29: 3�7�- Connection Diagrams

    AFQm 3�7�- CONNECTION DIAGRAMS 3�7�1�- 4-WIRE CONNECTION AND CURRENT MEASUREMENT ON THE MAINS SIDE� P2 P1 L1 L2 L3 S1 S2 S1 S2 S1 S2 CARGA / LOAD RED/ MAINS P2 S1 Figure 22: Three-phase measuring with 4-wire connection and current measurement on the mains side� Use the 2 neutral current terminals, as In can be:In ≈...

  • Page 30: 3�7�2�- 4-Wire Connection And Current Measurement On The Load Side

    AFQm 3�7�2�- 4-WIRE CONNECTION AND CURRENT MEASUREMENT ON THE LOAD SIDE� P2 P1 S1 S2 S1 S2 S1 S2 CARGA / LOAD RED/ MAINS P2 S1 Figure 23: Three-phase measuring with 4-wire connection and current measurement on the load side� Use the 2 neutral current terminals, as In can be: In ≈...

  • Page 31: 3�7�3�- 3-Wire Connection And Current Measurement On The Mains Side

    AFQm 3�7�3�- 3-WIRE CONNECTION AND CURRENT MEASUREMENT ON THE MAINS SIDE� P2 P1 L1 L2 L3 S1 S2 S1 S2 S1 S2 RED/ MAINS CARGA / LOAD P2 S1 Figure 24: Three-phase measuring with 3-wire connection and current measurement on the mains side� Instruction Manual...

  • Page 32: 3�7�4�- 3-Wire Connection And Current Measurement On The Load Side

    AFQm 3�7�4�- 3-WIRE CONNECTION AND CURRENT MEASUREMENT ON THE LOAD SIDE� P2 P1 S1 S2 S1 S2 S1 S2 CARGA / LOAD RED/ MAINS P2 S1 Figure 25: Three-phase measuring with 3-wire connection and current measurement on the load side� Instruction Manual...

  • Page 33: 3�7�5�- 3-Wire Connection And 2 Current Transformers On The Mains Side

    AFQm 3�7�5�- 3-WIRE CONNECTION AND 2 CURRENT TRANSFORMERS ON THE MAINS SIDE� P2 P1 L1 L2 L3 S1 S2 S1 S2 S1 S2 RED/ MAINS CARGA / LOAD Figure 26: Three-phase measuring with a 3-wire connection and 2 current transformers on the mains side� The connection of 2 current transformers is only possible in three-phase mains without neutral (3 wires).

  • Page 34: 3�7�6�- 3-Wire Connection And 2 Current Transformers On The Load Side

    AFQm 3�7�6�- 3-WIRE CONNECTION AND 2 CURRENT TRANSFORMERS ON THE LOAD SIDE� P2 P1 S1 S2 S1 S2 S1 S2 CARGA / LOAD RED/ MAINS Figure 27: Three-phase measuring with a 3-wire connection and 2 current transformers on the load side� The connection of 2 current transformers is only possible in three-phase mains without neutral (3 wires).

  • Page 35: 3�8�- Parallel Connection Of 2 To 100 Active Filters

    AFQm 3�8�- PARALLEL CONNECTION OF 2 TO 100 ACTIVE FILTERS The AFQm devices can be arranged in parallel to increase the available filtering power. Up to 100 devices can be arranged in parallel, either of the 30A, 60A, 70A or 100A models. In the case of installations with devices in parallel, a device must be defined as the “master”, while all others will have “slave”...

  • Page 36: 3�8�1�- Connecting Individual Devices

    AFQm 3�8�1�- CONNECTING INDIVIDUAL DEVICES To connect multiple individual devices in parallel, follow these steps: 1�- Select the device that will operate as the “master”. 2�- Connect the “master” device. The current transformers are only connected to the “master” device. 3�- Connect all of the “slave”...

  • Page 37: 3�8�2�- Connecting Cabinets

    AFQm 3�8�2�- CONNECTING CABINETS Note: The 200A (AFQm-xxx-200C), 300A (AFQm-xxx-300C) and 400A (AFQm-xxx-400C) cabinets are made up of 2, 3 and 4 100A devices in parallel. Both the parallel configuration and connection are factory-set. The 140A (AFQm-xxx-140C), 210A (AFQm-xxx-210C) and 280A (AFQm-xxx-280C) cabinets are made up of 2, 3 and 4 70A devices in parallel.

  • Page 38: 4�- Operation

    AFQm 4.- OPERATION 4�1�- HARMONICS Non-linear loads such as: rectifiers, inverters, variable speed drives, ovens, etc., absorb periodic non sine-wave currents from the mains. These currents are composed of a fundamental frequency component, rated at 50 or 60 Hz, plus a series of overlapping currents, with frequencies that are multiples of the fundamental frequency;...

  • Page 39: 4�1�2�- Most Common Harmonics

    �������� �������� ∗ 100 �������� �������� �������� �������� AFQm �������� ∗ 100 �������� �������� �������� ���� ���� ∗ 100 ���� Individual distortion rate (U % or I %): A ratio in % between the RMS value of the voltage or ����...

  • Page 40: 4�1�3�- Harmonic Compensation

    AFQm Table 18: Most common harmonics� Harmonic spectrum Type of load Wave shape THD(I) 6-pulse converters Variable speed drives Three-phase rectifiers Converters for electrolysis and baths Discharge lamps Single-phase converters Lighting lines Computer lines Sound and image devices 4�1�3�- HARMONIC COMPENSATION Active filters are devices responsible for the compensation of harmonic currents.

  • Page 41: 4�2�- Operating Principle

    AFQm 4�2�- OPERATING PRINCIPLE Active filters are based on the following principle: FILTER MAINS LOAD Equation 5:Operating principle� In other words, they detect the difference between the desired sine wave (I ) of the current and the ainS signal deformed by the harmonics (I ).
  • Page 42 ���� = ����� + ���� + ���� + ���� + ⋯ AFQm ����� + ���� + ���� + ⋯ harmonics measured in the load by a safety factor (FS ). In other words: ������������ ( ���� ) % = ���� (AFQm) = [FS * THD(I)] FiLTER...

  • Page 43: 4�4�- Resonance Detection

    AFQm Figure 36:Approximate graph for calculating the FS � 4�4�- RESONANCE DETECTION The AFQm acts as a current, frequency and variable amplitude generator. This current circulates via the path of least impedance, which should be the mains. In certain cases, there may be a load that provides less impedance than the mains, in which case a res- onance phenomenon will be produced with that load.

  • Page 44: 4�6�- Thermal Protection

    AFQm 4�6�- THERMAL PROTECTION The device features several levels of thermal protection: Ventilation regulation, the fan speed is adjusted as needed at any given time, thus minimising the noise in the device. Static temperature limitation, the device reduces its power if the internal temperature exceeds certain limits.

  • Page 45: 4�7�1�- Upper Area

    AFQm Upper area Central area Lower area Figure 38:The display is divided into three areas� 4�7�1�- UPPER AREA The following will be displayed on the upper area:  A short description of the status of the device.  The symbol, when the device requires maintenance, see section “ ”.

  • Page 46: 4�7�3�- Lower Area

    AFQm Table 19: Central area keys� Function Restarts the device after an alarm. Starts the active filter. Stops the active filter. 4�7�3�- LOWER AREA Figure 40: Lower area� The lower area displays the navigation and configuration keys of the device. Table 20: Lower area keys�...

  • Page 47: 5�- Start-Up

    AFQm 5.- START-UP When the device has been powered, one of the screens in appears on the display. Figure 41 Screen of a “Single” device or “Master” Screen of a “Slave” device Figure 41: Home screen� Before starting the active filter, it is necessary to follow the steps below: 1�- Use the key to navigate to the configuration screen and implement the appropriate configu- ration according to the existing installation (see...

  • Page 48: 6�- Display

    AFQm 6.- DISPLAY 6�1�- MAIN SCREEN 6�1�1� - DEVICE SINGLE OR MASTER shows the main screen of a “single” or “master” device. Figure 42 % of lter power Status messages Arrancando ... RESET key RUN / STOP key Load Mains Active Power Active Power Reactive Power...

  • Page 49: 6�1�2� - Device Slave

    AFQm Table 21 (Cont�) : Status messages Status messages Calibration Description Calibrating the internal sensors. Configuration Description Configuring the device. Description Device is operating. Sync Description The AFQm is synchronising with the mains. Charging Bus DC Description Charging process of the internal bus prior to start-up. Stop Description Device stopped.

  • Page 50: 6�2�- Thd

    AFQm 6�2�- THD Note: This screen is not visible on the “slave” devices. By pressing the key from the main screen, the THD display screen is accessed. Figure 44: THD display� It shows:  The voltage THD in each of the phases, L1, L2 and L3. ...

  • Page 51: 6�4�- Harmonic Current

    AFQm 6�4�- HARMONIC CURRENT Note: This screen is not visible on the “slave” devices. displays the harmonic current in absolute value for each of the mains and load phases. Figure 46 Figure 46: Harmonic current� Use the keys to navigate through the different display screens. 6�5�- VOLTAGE, CURRENT AND FREQUENCY Note: This screen is not visible on the “slave”...

  • Page 52: 6�6�- Power And Cos ɸ Of Mains

    AFQm 6�6�- POWER AND COS ɸ OF MAINS Note: This screen is not visible on the “slave” devices. shows the power and cos ɸ of the mains. Figure 48 Figure 48: Display of the power and cos ɸ of the mains� It shows: ...

  • Page 53: 6�8�- Voltage Harmonics

    AFQm  The cos ɸ. Note: The - sign in reactive power indicates that it is capacitive and the + sign that it is inductive. Use the keys to navigate through the different display screens. 6�8�- VOLTAGE HARMONICS Note: This screen is not visible on the “slave” devices. In this screen, , the odd voltage harmonics from 3 to 25, are shown for each of the phases.

  • Page 54: 6�10�- Current Harmonics (Load)

    AFQm 6�10�- CURRENT HARMONICS (LOAD) Note: This screen is not visible on the “slave” devices. In this screen, , the odd harmonics of the Load from 3 to 25 are shown for each of the phases. Figure 52 Figure 52: Display of the Load harmonics� Use the keys to navigate through the different display screens.

  • Page 55: 6�12�- Wave Shape Of Main Current

    AFQm 6�12�- WAVE SHAPE OF MAIN CURRENT Note: This screen is not visible on the “slave” devices. In this screen, , the wave shape of the mains current is shown for each of the phases. Figure 54 Figure 54: Wave shape of mains current� Press on the graphs to select the separate display of each phase.

  • Page 56: 6�14�- Mains Phasors

    AFQm 6�14�- MAINS PHASORS Note: This screen is not visible on the “slave” devices. In this screen, , the mains phasors are shown. Figure 56 Figure 56: Mains phasors� Use the keys to navigate through the different display screens. 6�15�- LOAD PHASORS Note: This screen is not visible on the “slave”...

  • Page 57: 6�16�- Alarms

    AFQm 6�16�- ALARMS Note: This screen is not visible on the “slave” devices. In this screen, , the alarms that have occurred are shown. Figure 58 Figure 58: Alarms� A brief description of the alarm is displayed on the screen, as well as the date and time at which it occurred.
  • Page 58 AFQm Use the keys to navigate through the different display screens. Table 22:Alarm messages� Alarm messages Overcurrent L1/L2/L3 Description The AFQm current is too high. Corrective This alarm may be associated with transients and noise in the power supply voltage. Check the quality action of the power supply voltage.

  • Page 59: 6�17�- Warnings

    AFQm 6�17�- WARNINGS Note: This screen is not visible on the “slave” devices. When the device generates a warning, it will continue to operate, but the symbol will be dis- played on the main screen. On pressing the key; if there are active warnings, the screen shown in , will be dis- Figure 60 played and the user will be asked for confirmation to continue with the filter start-up process.
  • Page 60 AFQm Table 23 (Cont�) : Warnings messages� Alarm and event messages Load polarity Description Detection of an error in the load polarity. Corrective Check the transformer connections. See section “7.9.- TRANSFORMER CONFIGURATION” action Disabled X harmonic Description Harmonic X has been disabled due to resonance. Corrective The resonance detection function can be activated erroneously in installations with a very high volt- action...

  • Page 61: 6�18�- Temperature

    AFQm Table 23 (Cont�) : Warnings messages� Alarm and event messages Corrective Confirm that the connections are correct. action Reverse power Description The power value measured is negative (generated power), which might indicate that the transformers have been connected inversely. Corrective Confirm that the connections are correct.

  • Page 62: 6�19�- Ethernet Communications

    AFQm 6�19�- ETHERNET COMMUNICATIONS In this screen, , the IP address of the device and the netmask are shown. Figure 63 Figure 63: Communications� Use the keys to navigate through the different display screens. 6�20�- DEVICE INFORMATION In this screen, , the serial number, HMI and DSP versions of the device are shown.

  • Page 63: 6�21�- Slave Device Status

    AFQm Figure 65: Calibrate touch sensor� Note: You have accessed the calibration screen by accident, wait until the line that surrounds the central circle is complete and you will be returned automatically to the information screen of the device ( Figure 64 Use the keys to navigate through the different display screens.
  • Page 64 AFQm Figure 67: Slave device status screen (2)� Note: If there is a communication error, the message “Communication error” will appear when you select the affected device. Instruction Manual...

  • Page 65: 7�- Configuration

    AFQm 7.- CONFIGURATION shows the main configuration screen. Figure 68 Figure 68: Main configuration screen� By pressing the key, the setup menu is accessed in display mode, i.e., all parameters of the device are shown but they cannot be modified. By pressing the key, the setup menu is accessed in edit mode, i.e., the parameters of the device can be modified.

  • Page 66: 7�1�- Language

    AFQm 7�1�- LANGUAGE In this screen, , the language of the display is selected. Figure 70 Figure 70: Configuration screen: Language� ● Language, display language. Press the key to access the next configuration step Press the key to access the main screen of the device without saving the configuration values. 7�2�- DEVICE SPECIFICATIONS Note: This screen is informative, it can not be modified.

  • Page 67: 7�3�- Installed Devices

    AFQm ● Type, device range:  30A: 30 A model.  60A: 30 A model.  70A: 70 A model.  100A: 100 A model. Press the key to access the next configuration step Press the key to access the main screen of the device without saving the configuration values. 7�3�- INSTALLED DEVICES The type of device are configured in this screen, Figure 72...

  • Page 68: 7�4�- Working Mode

    AFQm 7�4�- WORKING MODE Note: This screen is not visible on the “slave” devices. In this screen, , the following parameters of the device's operating mode are configured: Figure 73 Figure 73: Configuration screen: Operation mode� ● Mode In this parameter, the control algorithm that the device will use for harmonic filtering is selected, the options are: ...
  • Page 69 AFQm The phase balancing option in AFQm-3WF-xxxx works in unbalances produced by loads connected between phases in three-phase mains without neutral. The AFQm-3WF-xxxx does not compensate unbalances produced by single-phase loads connected between phase and neutral. Use a AFQm-4WF-xxxx to correct this type of unbalances. Priority Enable this option so that the device prioritises the functions in case of filter current saturation due to overload:...

  • Page 70: 7�5�- Harmonics Selection

    AFQm 7�5�- HARMONICS SELECTION Note: This screen is not visible on the “slave” devices. Note: The screen that appears if you have selected the operating mode FREQ: Frequency mode (“7.4.- WORKING MODE”) The harmonics to be filtered are selected in this screen, Figure 74 Figure 74: Configuration screen: Harmonic selection�...

  • Page 71: 7�7�- Cos Φ

    AFQm Range of values: Minimum value: 0 A Maximum value: 5000 A ● Current limit This parameter allows the maximum power of the active filter to be limited. The value is configured as a percentage with respect to the device's rated power. Range of values: Minimum value: 20% Maximum value: 100%...

  • Page 72: 7�8�- Ieee519

    AFQm This mode minimises the amount of power used by the device to compensate for reactive power, thus reducing its energy consumption. Range of values: 0.7... -0.7 Press the key to access the next configuration step Press the key to access the main screen of the device without saving the configuration values. 7�8�- IEEE519 Note: This screen is not visible on the “slave”...
  • Page 73 AFQm ● Generator The IEEE519-2014 standard establishes more restrictive limits for a generating installation. In such a case, i.e., where energy may be exported, the appropriate box must be ticked. The first two parameters may be obtained from the rating plate on the network connection transformer. If this function is enabled, the device will only correct the harmonics to meet the requirements of the established limits, instead of trying to cancel the harmonics altogether.

  • Page 74: 7�9�- Transformer Configuration

    AFQm 7�9�- TRANSFORMER CONFIGURATION Note: This screen is not visible on the “slave” devices. The transformers that will be installed with the device are configured in this screen, Figure 78 Figure 78: Configuration screen: Transformer configuration� ● Num transformers The number of transformers that will be installed is configured with this parameter, the options are: ...

  • Page 75: 7�10�- Alarms

    AFQm ● Invert This parameter is used to select the phase whose filter is going to switch the current direction of the load measurement transformer, so installation faults may be corrected. Press the key to access the next configuration step Press the key to access the main screen of the device without saving the configuration values.

  • Page 76: 7�11�- Ethernet Communications

    AFQm 7�11�- ETHERNET COMMUNICATIONS The Ethernet communication parameters are configured in this screen, Figure 80 Figure 80: Configuration screen: Ethernet communications� By activating the DHCP option , the device assigns the IP automatically. If this option is not activated, the parameters must be configured manually: ●...

  • Page 77: 7�13�- Date / Time

    AFQm Press the key to access the next configuration step Press the key to access the main screen of the device without saving the configuration values. 7�13�- DATE / TIME The time parameters are configured in this screen, Figure 82 Figure 82: Configuration screen: Date / Time ●...

  • Page 78: 7�15�- Save Data

    AFQm ● Setup Password. This parameter enables the device’s configuration access password to be modified. ● Stop Password. key may be configured with a password; if enabled, the device will request the password on being pressed and will not stop unless the correct password is entered. Press the key to access the next configuration step Press the...

  • Page 79: 8�- Rs-485 Communications

    AFQm 8.- RS-485 COMMUNICATIONS AFQm devices have an RS-485 serial communication output with the MODBUS RTU ® communica- tions protocol. For an installation with devices in parallel, the RS-485 connection can be made on any device. 8�1�- CONNECTIONS The RS-485 cable must be wired with twisted pair cable with mesh shield (minimum 3 wires), with a maximum distance between the AFQm and the master device of 1200 metres.

  • Page 80: 8�2�- Protocol

    AFQm 8�2�- PROTOCOL In the Modbus protocol, the AFQm uses the RTU (Remote Terminal Unit) mode. The Modbus functions implemented in the device are as follows: Functions 03 and 04: Reading of n Words (2 bytes). 8�2�1�- EXAMPLE OF MODBUS QUERY Query: Value of the Load current of L1 Initial No�...
  • Page 81 AFQm Table 26:Modbus memory map: Measurements with Load (Table 2)� Parameter Current L1 Current L2 Current L3 Units Fundamental harmonic 3rd order harmonic 5th order harmonic 7th order harmonic 9th order harmonic 11th order harmonic 13th order harmonic 15th order harmonic 17th order harmonic 19th order harmonic 21st order harmonic...
  • Page 82 AFQm Table 30:Modbus memory map: Measurements in the Mains (Table 2)� Parameter Current L1 Current L2 Current L3 Units Fundamental harmonic 3rd order harmonic 5th order harmonic 7th order harmonic 9th order harmonic 11th order harmonic 13th order harmonic 15th order harmonic 17th order harmonic 19th order harmonic 21st order harmonic...
  • Page 83 AFQm Table 33 (Cont�): Modbus memory map: Filter parameters (Table 1)� Parameter Address Units Temperature IGBT 4 ºC with 1 decimal (2) (3) Temperature IGBT 5 ºC with 1 decimal (2) (3) Temperature IGBT 6 ºC with 1 decimal (2) (3) Temperature Inductor 3 ºC with 1 decimal (2) (3)
  • Page 84 AFQm Table 37 (Cont�): Modbus memory map: Filter messages (Table 2)� Description 0x00000008 L3 overcurrent alarm 0x00000010 L1 overvoltage alarm 0x00000020 L2 overvoltage alarm 0x00000040 L3 overvoltage alarm 0x00004000 Temperature IGBT 1 alarm 0x00008000 Temperature Inductor 1 alarm 0x00010000 Initial Conditions Error 0x00020000 Resonance Alarm 0x00100000...
  • Page 85 AFQm Table 40:Modbus memory map: Filter messages (Table 5)� Parameter Address Harmonics status Description Status 0x0001 Harmonic 3 0x0002 Harmonic 5 0x0004 Harmonic 7 0x0008 Harmonic 9 0x0010 Harmonic 11 1: Harmonic filtering 0x0020 Harmonic 13 0: Harmonic disabled due 0x0040 Harmonic 15 to resonance...

  • Page 86: 9�- Ethernet Communications

    AFQm 9.- ETHERNET COMMUNICATIONS For an installation with devices in parallel, the Ethernet connection can be made on any device. 9�1�- CONNECTION The AFQm has an Ethernet port. This type of communication creates an intranet with IP communica- tions. If the device that connects to this port is a computer, the network cable must be a crossover Ethernet cable, as shown in Figure 86 Figure 86:RJ-45 connector: Crossover Ethernet connection diagram�...
  • Page 87 AFQm The language of the web site can be modified using the buttons that appear on the upper right part of the page. To modify the Configuration parameters, it is necessary to enter the User and Password in the Admin- istrator section.

  • Page 88: 10�- Maintenance

    AFQm 10.- MAINTENANCE The AFQm active filter requires minimum preventive maintenance. It is recommended to follow the notes described in this chapter to avoid premature damage to the device's components. shows the maintenance jobs with their respective time intervals. Table 43 Table 43: Active filter maintenance�...
  • Page 89 AFQm The points to be inspected are: 1�- Set the AFQm in STOP mode and open the main switch (OFF position). 2�- Wait 1 minute for the capacitors to discharge. 3�- Clean the ventilation grilles, removing the dust. 4�- Check the status and torque of the electrical connections, as well as the mechanical attachment to the wall.

  • Page 90: 10�2�- Cooling Fans

    The set of fans must be replaced if they have exceeded their useful life or show signs of deterioration. In such cases, Circutor will provide a spare part that consists of a set of fans so that the device can be repaired quickly and easily.
  • Page 91 AFQm To proceed to change the set of fans: Place the AFQm in STOP mode and disconnect the device from the power. If necessary, disconnect all the connection cables and short-circuit the current transformers. Wait for 1 minute for the capacitors to discharge before opening the device. Front cover Wall bushing Figure 91:Steps to change fans�...
  • Page 92 AFQm 11 Fit the fan cover, passing the fan cable through the wall bushing. 1�5 Nm 12 Connect the fans. 13 Tighten the fuse screws and the neutral connection bar. 2�2 Nm 14 Place the insulators. 15 Connect the display. 16 Tighten front cover screws.

  • Page 93: 10�4�- Change Of Cooling Fans: Afqm

    AFQm 19 Reset the fans maintenance meter by pressing the key. 10�4�- CHANGE OF COOLING FANS: AFQm OF 60A Table 45:Tools needed (AFQm-xxx-060M) Tools needed Fan assembly replacement AFQm-xxx-060M, Code: 920122 Screwdriver for PH2 head screws Screwdriver for Allen 3 head screws Figure 93: Location of the cooling fans�...
  • Page 94 AFQm Front cover Wall bushing Lower cover Figure 94:Steps to change fans (Part 1)� Figure 95:Steps to change fans (Part 2)� 3 Remove the 8 screws from the front cover. 4 Disconnect the display. Instruction Manual...
  • Page 95 AFQm 5 Remove the insulators. 6 Remove the screws from the fuses and the neutral connection bar from the side of the board 7 Loosen the fuse screws on the side of the terminal block� 8 Remove de fuses. 9 Remove the 5 screws from the terminal block. Remove the bar from each of the phases. 10 Disconnect the upper floor fans.

  • Page 96: 10�5�- Change Of Cooling Fans: Afqm Of 100A Rack

    AFQm 24 Tighten the front cover screws. 1�5 Nm 25 Connect, power and start the AFQm. 26 Check the correct operation of the fans. Follow steps 18 and 19, section “10.3. CHANGE OF COOLING FANS: AFQm OF 30A” 10�5�- CHANGE OF COOLING FANS: AFQm OF 100A RACK Table 46:Tools needed (AFQm-xxx-100R) Tools needed Fan assembly replacement AFQm-xxx-100x, Code: 920124...
  • Page 97 AFQm 4 Disconnect the flat belts, Hall-effect sensors and fans. Figure 97:AFQm-xxx-100R Change of cooling fans (Step 4)� Remove the 4 screws from the board bracket and carefully disassemble the boards. Remove the wall bushing from the fan cables to allow disassembly. 6 Remove the screws from the driver board.
  • Page 98 AFQm Figure 99:AFQm-xxx-100R Change of cooling fans (Step 9)� 10 Remove the fan assembly by pulling it up, and replace it with the new fans. Figure 100:AFQm-xxx-100R Change of cooling fans (Step 10)� 11 Tighten the fan assembly screws. 5�5 Nm 12 Mount the bars.

  • Page 99: 10�6�- Change Of Cooling Fans: Afqm Of 100A Wall

    AFQm 16 Connect the flat belts, Hall-effect sensors and fans. 17 Mount the top cover. 4�5 Nm 18 Connect, power and start the AFQm. 19 Check the correct operation of the fans. Follow steps 18 and 19, section “10.3. CHANGE OF COOLING FANS: AFQm OF 30A” 10�6�- CHANGE OF COOLING FANS: AFQm OF 100A WALL Table 47:Tools needed (AFQm-xxx-100M) Tools needed...

  • Page 100: 10�7�- Change Of Cooling Fans: Cabinet Type Afqm

    AFQm 4 Disconnect the display. Figure 102: AFQm-xxx-100M Change of cooling fans (Step 4)� 5 Follow the steps from step 4 in section “10.5.- CHANGE OF COOLING FANS: AFQm OF 100A RACK” 10�7�- CHANGE OF COOLING FANS: CABINET TYPE AFQm Table 48:Tools needed (cabinet type AFQm) Tools needed AFQm-xxx-100C and AFQm-xxx-070C:...

  • Page 101: 10�8�- Maintenace Of Surge Protective Decives: 70A, 140A, 210A And 280A Cabinet Afqm

    AFQm of the device’s 100A modules. Note: When checking the fans in the “master” device, the slave device fans will be activated automat- ically. 10�8�- MAINTENACE OF SURGE PROTECTIVE DECIVES: 70A, 140A, 210A AND 280A CABINET AFQm The device has removable surge protective that are accessible from the front. They feature a green indicator to signal the correct operation of the protective.

  • Page 102: 11�- Technical Features

    AFQm 11.- TECHNICAL FEATURES Mains voltage AFQm-3WF-xxxx-480 AFQm-4WF-xxxx-400 208 ... 480 V~ ± 10% 208 ... 400 V~ ± 10% Ph-Ph Ph-Ph Rated voltage Un AFQm-3WF-xxxx-690 AFQm-4WF-xxxx-550 230 ... 690 V~ ± 10% 230 ... 550 V~ ± 10% Ph-Ph Ph-Ph Frequency Fn 50 / 60 Hz ±...
  • Page 103 AFQm (Continuation) AFQm-xxx-300C AFQm-xxx-400C Rated conditional short-circuit current Icc 40 kA 40 kA Simultaneity RDF Maximum consumption 6210 W 8280 W Maximum current (phase) 300 A RMS 400 A RMS Maximum current (neutral) 900 A RMS 1200 A RMS Crest factor (current) AFQm-3WF-300C AFQm-3WF-400C 480V...
  • Page 104 AFQm (Continuation) AFQm-xxx-210C AFQm-xxx-280C Maximum current (neutral) 630 A RMS 840 A RMS Crest factor (current) AFQm-3WF-210C AFQm-3WF-280C 690V 252000 VA 336000 VA Maximum power AFQm-4WF-210C AFQm-4WF-280C 550V 201000 VA 268000 VA Current measurement Type Transformer: 5/5A ... 5000/5A Frequency response up to 2500 Hz / 3000 Hz (60 Hz) Consumption 1.5 VA per transformer...
  • Page 105 AFQm RS-485 Communications Field bus RS-485 Communications protocol Modbus RTU Baud rate 9600 bps Stop bits Parity none Ethernet communications Network protocol TCP/IP, Modbus TCP User interface 3.5” TFT colour touch screen Display Web server and datalogger Environmental features Environmental conditions Indoor conditioned IEC 60721-3-3 Operating temperature -10ºC ...
  • Page 106 AFQm Mechanical features AFQm-xxx-030M Dimensions (mm) Figure 104 Weight 21 kg Enclosure Galvanised steel 1.5 mm Noise 58 dBA Connections Type Mains M6 ring terminal 12 mm 2.2 ... 2.4 Nm Earth M6 ring terminal 16 mm 2.2 ... 2.4 Nm Connections Type Current...
  • Page 107 AFQm AFQm-xxx-060M Dimensions (mm) Figure 105 Weight 39 kg Enclosure Galvanised steel 1.5 mm Noise 60 dBA Connections Type Mains M6 ring terminal 12 mm 2.2 ... 2.4 Nm Earth M6 ring terminal 16 mm 2.2 ... 2.4 Nm Connections Type Current 6-pole connector...
  • Page 108 AFQm AFQm-xxx-100M Dimensions (mm) Figure 106 Weight 56 Kg Enclosure Galvanised steel 1.5 mm Noise < 60 dBA Connections Type Mains M8 ring terminal 23 mm 8 ... 10 Nm Earth M10 ring terminal 10 ... 14 Nm Hex 17 mm Connections Type Current...
  • Page 109 AFQm AFQm-xxx-100R Dimensions (mm) Figure 107 Weight 55 kg Enclosure Galvanised steel 1.5 mm Noise < 60 dBA Connections Type Mains Ring terminal M8 23 mm 8 ... 10 Nm Earth Ring terminal M10 10 ... 14 Nm Hex 17 mm Connections Type Current...
  • Page 110 AFQm AFQm-xxx-070C, AFQm-xxx-100C, AFQm-xxx-140C, AFQm-xxx-200C, AFQm-xxx-210C, AFQm-xxx-280C, AFQm-xxx-300C, AFQm-xxx-400C Dimensions (mm) Figure 108 AFQm-xxx-070C AFQm-xxx-100C AFQm-xxx-140C AFQm-xxx-200C 192 kg 190 kg 249 kg 245 kg Weight AFQm-xxx-210C AFQm-xxx-280C AFQm-xxx-300C AFQm-xxx-400C 306 kg 363 kg 300 kg 355 kg Enclosure Free-standing sheet steel cabinet, for installation indoors, without removable parts. AFQm-xxx-070C AFQm-xxx-100C AFQm-xxx-140C...
  • Page 111 AFQm Figure 108:Dimensions Cabinet-type AFQm� Instruction Manual...

  • Page 112: 12�- Technical Service

    AFQm 12.- TECHNICAL SERVICE In the case of any query in relation to device operation or malfunction, please contact the CIRCUTOR, SA Technical Support Service. Technical Assistance Service Vial Sant Jordi, s/n, 08232 - Viladecavalls (Barcelona) Tel: 902 449 459 ( España) / +34 937 452 919 (outside of Spain) email: sat@circutor.com...

  • Page 113: 14�- Ce Certificate

    AFQm 14.- CE CERTIFICATE Instruction Manual...
  • Page 114 AFQm Instruction Manual...
  • Page 115 AFQm Instruction Manual...
  • Page 116 CIRCUTOR, SA Vial Sant Jordi, s/n 08232 - Viladecavalls (Barcelona) Tel: (+34) 93 745 29 00 - Fax: (+34) 93 745 29 14 www.circutor.com central@circutor.com...

This manual is also suitable for:

Afqm 60 aAfqm 70 aAfqm 100 aAfqm 140 aAfqm 200 aAfqm 210 a ... Show all

Table of Contents
