Saxby Lighting Dax CCT Bollard Instruction Manual

Wiring

Having correctly identified the wiring from your existing light fitting, pull the mains wire through the hole and connect to the
terminal block(not supplied) in the following way:
SUPPLY
NEUTRAL
EARTH
SWITCHED LIVE
Check that...
You have correctly identified the wires.
The connections are tight.
No loose strands have been left out of the connection block.

Technical data

Supply
240 V~, 50 Hz
Voltage:
Bulb
20W LED module (SMD) CCT, 3000/4200/6000K
Type:
The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole
luminaire shall be replaced.
Conformity with all relevant EC Directive requirements.
This is a Class 1 product and must be earthed.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or local store for recycling advice.
This product is not suitable for dimming.
This product is rated at IP65.
65
IP

Care and Safety

We recommend cleaning with a soft dry cloth. Do not use solvents or abrasive cleaners as these could damage the finish.
For your safety, always switch off the power supply before cleaning.
V2 05/06/2020
