Cutout Details for: ARFG-42 & AGBQ-42
1 3/4"
19"
FRONT VIEW CUT AWAY
TO SHOW RECEPTACLE
8"
3 1/2"
15"
LEFT END
FILE NAME: ARFG-42 CUTOUT
115V GFCI DUPLED
RECETACLE ON INSIDE
REAR WALL
2X 1½" WIDE RAILS
SEE TOP VIEW
CUTOUT FOR LOUVERED
PANEL 130-1636
2"
36"
8 1/4"
BETWEEN RAILS
13/16"
8"
4 1/4"
15"
FRONT VIEW
39"
CABINET FACE
TOP
CUTOUT FOR LOUVERED
PANEL 130-1636
42 1/2"
23"
13/16"
10 1/4"
21 3/8"
2"
