- Page 1 Tennyson Fireplace FA8545ARTX- Classic Espresso For assistance with assembly contact: Southern Enterprises Inc. Assembly Instructions Customer Service 1-800-633-5096 service@seidal.com www.seidal.com...
-
Page 2: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Top Panel Back Panel (L/R) Base Upper Cross Brace Left Front Panel Lower Cross Brace Right Front Panel Front Rail Middle Front Panel Back Rail Left Side Panel Wood Connecter Right Side Panel Wood Holder Firebox (shipped in a separate carton) -
Page 3: Hardware Contents
HARDWARE CONTENTS Cam Lock Cam Bolt Wood Dowel Flat Head Long Screw Qty:10 Qty:40 Qty:10 Qty:44 Phillips screwdriver (not included). - Page 4 ASSEMBLY INSTRUCTIONS 1. Insert 2pcs cam bolts (A) and 8pcs wood dowels (B) into predrilled holes on front and back rails (11, 12) and fit into corresponding holes on ends of wood connecter (13). Insert 2pcs cam locks (C) into corresponding holes on underside of wood connecter (13) with slot for screwdriver facing outward.
- Page 5 ASSEMBLY INSTRUCTIONS 3. Insert 2pcs cam bolts (A), 12pcs wood dowels (B) into predrilled holes on edges of left and right front panels (3, 4), left and right side panels (6, 7) and fit into corresponding holes on ends of parts (5, 11, 12).
- Page 6 ASSEMBLY INSTRUCTIONS 5. Insert 4pcs cam bolts (A) and 8pcs wood dowels (B) into predrilled holes on edges of left and right back panels (8) and fit into corresponding holes on ends of upper and lower cross brace (9, 10). Insert 4pcs cam locks (C) into corresponding holes on back of upper and lower cross brace (9, 10) with slot for screwdriver facing outward.
- Page 7 ASSEMBLY INSTRUCTIONS 7. Insert 13pcs flat head long screws (D) through predrilled holes on parts (8, 9, 10) and tighten in a clockwise direction. HARDWARE USED Flat Head Long Screw x 13 8. Place top panel (1) onto top edges, attach it to the unit using 9pcs flat head long screws (D).
- Page 8 ASSEMBLY INSTRUCTIONS 9. Insert the firebox (15) into the unit. Make sure the firebox (15) is pressed tightly against the assembled unit. Attach the wood holders (14) on the sides of firebox (15). Insert 4pcs flat head long screws (D) through predrilled holes on wood holder (14) and tighten into corresponding holes on back of left and right back panels (8).
- Page 9 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
