Micropilot FMR10

Output current

Navigation
Description
User interface

Damping output

Navigation
Description
User entry
Factory setting

Turn down

Navigation
Description
Selection
Factory setting
Endress+Hauser
"Current output" submenu
Navigation  Setup → Advanced setup → Current output
 Setup → Advanced setup → Current output → Output current
Shows the actual calculated value of the output current.
3.59 to 22.5 mA
 Setup → Advanced setup → Current output → Damping output
Define time constant τ for the damping of the output current. Fluctuations of the
measured value affect the output current with an exponential delay, the time constant τ of
which is defined in this parameter. With a small time constant the output reacts
immediately to changes of the measrued value. With a big time constant the reaction of
the output is more delayed. For τ = 0 there is no damping.
0.0 to 300 s
1.0 s
 Setup → Advanced setup → Current output → Turn down
Using the turn down functionality it is possible to map a section of the measuring range to
the total range of the output current (4-20mA). The section is defined by the ' 4 mA value'
and ' 2 0 mA value' parameters. Without the turn down, the complete measuring range (0
to 100%) is mapped to the current output (4 to 20mA).
• Off
• On
Off
Operating menu


57
