Operating menu
Factory setting

Level correction

Navigation
Description
User entry
Factory setting

Evaluation distance

Navigation
Description
User entry
Factory setting
54
An automatic Blocking distance (→  53) of at least 0.1 m (0.33 ft) is configured as
standard. However, this can be overwritten manually (0 m (0 ft) is also permitted).
Automatic calculation of the Blocking distance = Empty calibration - Full calibration -
0.2 m (0.656 ft).
Each time a new entry is made in the Empty calibration parameter or Full calibration
parameter, the Blocking distance parameter is recalculated automatically using this
formula.
If the result of the calculation is a value < 0.1 m (0.33 ft), the Blocking distance of
0.1 m (0.33 ft) will continue to be used.
 Setup → Advanced setup → Level correction
The measured level is corrected by this value to compensate for a constant level error.
Level correction > 0: The level is increased by this value. Level correction < 0: The level is
decreased by this value.
–25 to 25 m
0.0 m
 Setup → Advanced setup → Evaluation distance
Extended signal search area. Is generally greater than the empty distance. If the signal is
found below the empty distance, ' 0 ' (empty) is indicated as measured value. Only for
signals, detected below the ' E valuation distance' , the error ' E cho Lost' is issued. e.g. flow
measurement in overflow weirs.
0 to 12 m
11.5 m
