Micropilot FMR10
Confirm distance
Navigation
Description
Selection
Factory setting
Mapping end point
Navigation
Description
User entry
Factory setting
Present mapping
Navigation
Description
User interface
Endress+Hauser
 Setup → Confirm distance
Does the measured distance match the real distance? Select one of the options: - Manual
map To be selected if the range of mapping is to be defined manually in the ' M apping end
point' parameter. A comparison between actual and indicated distance is not required in
this case. - Distance ok To be selected if the measured distance matches the actual
distance. The device performs a mapping. - Distance unknown To be selected if the actual
distance is unknown. A mapping can not be performed in this case. - Factory map To be
selected if the present mapping curve (if one exists) is to be deleted. The device returns to
the ' C onfirm distance' parameter and a new mapping can be recorded.
• Manual map
• Distance ok
• Distance unknown
• Factory map
Distance unknown
 Setup → Mapping end point
This parameter defines up to which distance the new mapping is to be recorded. The
distance is measured from the reference point, i.e. from the lower edge of the mounting
flange or sensor.
0 to 12 m
0 m
 Setup → Present mapping
Indicates up to which distance a mapping has already been recorded.
0 to 100 m
Operating menu


51
