Cantilever (long) with pivot, sensor process connection on rear
75 (2.9)
 30 Dimensions of cantilever (long) with pivot for sensor process connection on rear. Unit of
measurement mm (in)
Weight:
4.5 kg (9.92 lb)
Material
316L (1.4404)
Order number
71452316
• 35 mm (1.38 in) openings for all G 1" or MNPT 1" connections on rear
• 22 mm (0.87 in) opening can be used for an additional sensor
• Retaining screws are included in delivery
12.4.2

Installation type sensor process connection front side

A
 31 Installation type sensor process connection front side
A Installation with cantilever and wall bracket
B Installation with cantilever and mounting frame
1 Cantilever
2 Wall bracket
3 Mounting frame
1085 (42.7)
300 (11.8)
75 (2.9) 100 (3.9)
B
1
2
35 (1.4)
M8
750 (29.5)
35 (1.4)
1
3
Accessories
A0037807
A0028886
