Accessories
34
12.2
FAX50 screw-in flange
The FAX50 screw-in flange is a universal flange which can be used for three standards
(DIN - ASME - JIS) owing to its min./max. dimensions.
26
Dimensions of the UNI flange FAX50
L
Bore diameter
K1,
Diameter of pitch circle
K2
D
Flange diameter
b
Total flange thickness
B
Slotted hole (width)
Order number
FAX50-####
For available materials and dimensions, see TI00426F
D
L
K1
K2
Micropilot FMR10
A0029185
Endress+Hauser
