Summary of Contents for Hasley Taylor HVRBL Series
- Page 1 HVR8BL(R)*1D HVR8BLWF*1D Owners Manual MANUAL DEL PROPIETARIO HALSEY TAYLOR MANUEL DE L'UTILISATION HALSEY TAYLOR HVRBL™ Series Vandal-Resistant Water Coolers Serie HVRBL™ enfriadores de agua a prueba de agresiones Série HVRBL™ anti-vandalisme refroidisseurs d’eau Page 1 98953C (Rev. B - 11/16)
- Page 2 HVR8BL(R)*1D HVR8BLWF*1D Note: Danger! Electric shock hazard. Disconnect power before servicing unit. Uses HFC-134A refrigerant See Fig. 5 See Fig. 5 See Fig. 5 See Fig. 5 FIG. 1 Page 2 98953C (Rev. B - 11/16)
- Page 3 HVR8BL(R)*1D HVR8BLWF*1D FIG. 2 Page 3 98953C (Rev. B - 11/16)
- Page 4 HVR8BL(R)*1D HVR8BLWF*1D FIG. 3 Page 4 98953C (Rev. B - 11/16)
- Page 5 HVR8BL(R)*1D HVR8BLWF*1D IMPORTANT ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON HANGER BRACKETS & TRAP INSTALLATION 1) Remove hanger bracket fastened to back of cooler by removing one (1) screw. 2) Mount the hanger bracket and trap as shown in Figure 2. NOTE: Hanger Bracket MUST be supported securely.
- Page 6 HVR8BL(R)*1D HVR8BLWF*1D Basin VANDAL RESISTANT BUBBLER DETAIL 27 (8) 40 (LH unit) 41 (RH unit) (Items 31 & 24 also used on the LH unit) 31 24 27 (6) 29 (4) Fig. 6 (Refrigerated side shown) Page 6 98953C (Rev. B - 11/16)
- Page 7 HVR8BL(R)*1D HVR8BLWF*1D PARTS LIST/ LISTA DE PIEZAS/ LISTE DES PIÈCES ITEM DESCRIPTION DESCRIPCIÓN PART NO. DESCRIPTION 97446C Bubbler Assy - VR Bubbler Assy - VR Bubbler Assy - VR 98777C Kit - Compressor Mtg/Clips/Studs/Grommets Kit - Kit - ojales de clips de los pernos prisioneros Kit - compresseur montage clips/goujons/oeillets de montaje del compresor Kit - Fan Motor/Blade/Shroud/Nut/Screws...
