HV150/300
Throughout this manual statements
indicating precautions necessary
avoid equipment failure
Note. Statements indicating potential hazards
personal injury or property
that could result in
damage
are referenced in a CAUTION! box.
Installation and Operation Manual
Installation, Operation and Maintenance Manual
HV150, HV300, HV600, HV1000
HV600
to
are referenced in a
Donaldson Company reserves the right to change design
and specifications without prior notice.
Illustrations are for reference only as actual product may
vary.
HV1000
IOM AK0303201
Revision 0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HV150 and is the answer not in the manual?

Questions and answers

Summary of Contents for Donaldson HV150

  • Page 1 HV150, HV300, HV600, HV1000 HV150/300 HV600 HV1000 Throughout this manual statements Donaldson Company reserves the right to change design indicating precautions necessary and specifications without prior notice. avoid equipment failure are referenced in a Illustrations are for reference only as actual product may Note.
  • Page 2 • DO NOT allow sparks, cigarettes or other burning objects to enter the hood or duct of any dust or fume control equipment as these may initiate a fire or explosion. • For optimum collector performance, use only Donaldson Torit replacement parts. Warning – Improper operation of a dust control system may contribute to conditions in the work area or facility that could result in severe personal injury and product or property damage.
  • Page 3: Table Of Contents

    This manual contains specific precautionary statements relative to worker safety. Read thoroughly and comply as directed. Discuss the use and application of this equipment with a Donaldson Torit representative. Instruct all personnel on safe use and maintenance procedures. Data Sheet...
  • Page 4: Figure 1 Schematic

    Donaldson (Wuxi) Filters Co.,Ltd. 唐纳森(无锡)过滤器有限公司 1. Lift lug 2. Filter with access cover 3. Dust bin 4. Control panel 5. Inlet 6. Pressure gauge 7. Pushing button 8. Fan outlet 9. Power supply cable inlet 10. Compressed air inlet 11. Sprinkler coupling...
  • Page 5 HV150,300,600,1000 HV600/1000 HV150/300 Filter element cleaning Operation 7. Tube sheet 1. Dirty air inlet 4. Clean air outlet 8. Air pulse 2. Filter element 5. Manifold 3. Hopper 9. Dust (falling) 6 . Diaphragm valve Figure 2 Operational Schematic...
  • Page 6: Product Introduction

    Enter the cable through the cable gland locate diaphragm valve will send a pulse of at the lower right corner (HV150 and HV300) or compressed air through the filter elements top right corner (HV600 and HV1000) of the (from the inside outwards), removing the collector.
  • Page 7: Start Up And Operation

    HV150,300,600,1000 3.0 Start-up and Operation 2.3 Inlet Duct Connection Check that the outlet of the fan is free of The inlet collar is shown on figure 3. debris before starting. Make sure the dust disposal system is properly installed under the hopper.
  • Page 8: Service

    Donaldson (Wuxi) Filters Co.,Ltd. 唐纳森(无锡)过滤器有限公司 4.0 Service 4.2 Replacing of Filter Elements Caution: Caution When the airflow is low or the differential pressure is too high and alarm, must change Disconnect electrical power before the filter elements. servicing. All filters elements should be changed at the Shut off and bleed compressed air same time.
  • Page 9: Optional Equipment

    HV150,300,600,1000 5.0 Optional equipment HEPA BIBO for Filter BIBO for Hopper Figure 7 BIBO Module(Option) 6.0 Trouble shooting WARNING Disconnect all power before servicing to prevent injury or extensive  damage. Direct compressed air supply towards human body or equipment will ...
  • Page 10 Donaldson (Wuxi) Filters Co.,Ltd. 唐纳森(无锡)过滤器有限公司 Problem Probable Cause Remedy Not wired correctly. Check and correct internal motor wiring Fan does not start for proper connections for your voltage (see Wiring Diagram) Proper wire size not used Rewire per national and local electric for motor codes for proper wire size.
  • Page 11 HV150,300,600,1000 Problem Probable Cause Remedy Fan wheel rotating wrong Check fan rotation. Refer to 3.0 Insufficient airflow Openings not properly Check doors, that they are closed and sealed tightened securely. Also check hopper area that openings are closed off and that the hopper dust disposal is installed.
  • Page 12: Control Panel

    Donaldson (Wuxi) Filters Co.,Ltd. 唐纳森(无锡)过滤器有限公司 7.0 Control Panel Figure 8 HV150/300 Control Panel (Standard) 7.1 Control panel functions 7.2 Operation The “Start/Stop” button is for fan motor Ensure that the control panel is correctly on/off. And these 2 buttons also provides...
  • Page 13 HV150,300,600,1000...
  • Page 14 Donaldson (Wuxi) Filters Co.,Ltd. 唐纳森(无锡)过滤器有限公司 Figure 10 HV150/300 BIBO Control Panel (Option)
  • Page 15 HV150,300,600,1000 7.3 HV150/300 BI/BO Control panel 7.4 HV150/300 BI/BO Operation functions (Option) (Option) The “Auto/Manual” selection switch for Ensure that the control panel is correctly AUTO or MANUAL cleaning control model installed onto the dust collector before selecting. When the selection switch is at starting up (check main power supply the "Manual"...
  • Page 16 Donaldson (Wuxi) Filters Co.,Ltd. 唐纳森(无锡)过滤器有限公司...
  • Page 17 HV150,300,600,1000...
  • Page 18 Donaldson (Wuxi) Filters Co.,Ltd. 唐纳森(无锡)过滤器有限公司 Figure 13 HV600/1000 (BIBO) Control panel...
  • Page 19 HV150,300,600,1000 7.5 HV600/1000 (BIBO for option) 7.6 HV600/1000 (BIBO for option) Control panel functions Operation The “Local/Remote” selection switch is for Ensure that the control panel is correctly LOCAL or REMOTE fan motor on/off control installed onto the dust collector before selecting.
  • Page 20 Donaldson (Wuxi) Filters Co.,Ltd. 唐纳森(无锡)过滤器有限公司...
  • Page 21 HV150,300,600,1000...
  • Page 22: Spare Parts

    Donaldson (Wuxi) Filters Co.,Ltd. 唐纳森(无锡)过滤器有限公司 Spare Parts Item Description Part number P191115 Filter Assembly-Ultra Web FR P031851 Filter Assembly-Ultra Web SB P034080 Filter Assembly-Ultra Web AS 8PP-19307-00 Diaphragm valve 8PP-48948-10 Solenoid Valve(HV600) 8PP-48948-09 Solenoid Valve(HV1000) 8PP-AK00099-50 Relief valve 8PP-AK01004-00 Delta P-C01 115V/230V...
  • Page 23 , , , Service Notes Date Service Performed Notes...
  • Page 24 Such a refund will be in the full extent of Donaldson’s liability. Donaldson shall not be liable for any other costs, expenses or damages whether direct, indirect, special, incidental, consequential or otherwise. The terms of this warranty may be modified only by a special warranty document signed by a Director, General Manager or Vice President...
