TECHNICAL SPECIFICATIONS AND WATER BLOCK PARTS
TERMINAL COVER LED PANEL
TERMINAL COVER
TERMINAL SCREW M4X20 DIN7984
TERMINAL
TERMINAL O-RING 15x1
SCREW M4x8 DIN7984
MAIN O-RING
140x2mm
PLEXI INSERT
COLDPLATE
TERMINAL COVER
STICKERS
TOP PLATE(PLEXI/ACETAL)
LED D-RGB STRIP
STICKOUT
(BLACK /WHITE)
JET PLATE
STICKOUT STANDOFF
STANDOFF M4/M2,5 x 10,50
STANDOFF M4/2.5x2.5
Technical Specification:
- Dimensions (LxHxW): 314 x 155 x 21 mm
- D-RGB (Addressable RGB) Cable - Length: 500 mm
- D-RGB LED Count: Plexi – 8/Acetal – 8
- D-RGB Connector: Standard 3-Pin (+5V, Data, Blocked, Ground)
- 6 -
