1 SAFETY INFORMATION
Important Safety Information
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
• Do not defeat the safety purposes of the grounding-type plug. A
ground type plug has two blades and a third grounding prong. The third
prong is provided for your safety. If the provided plug does not fit in
to your outlet, consult an electrician for replacement of the obsolete
outlet.
• Protect the power cord from being walked on or pinching particularly
at plugs, convenience receptacles, and point where they exit from the
apparatus.
• Only use attachments/accessories specified by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.
• Unplug this apparatus during lightning storms or when unused for
long periods of time.
• Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
• Throughout this manual, a number of warning and caution notes may be presented to alert the user to important safety or operating information.
Please read and comply with any and all warning and caution notes in this manual.
• Always adhere to local building, safety and fire prevention codes during the installation and operation of this product.
• Use only power cords specified for this product and certified for the country of use.
• Connect the unit only to a power source with the specified voltage rating.
• Use only fuses of the type and rating specified.
• In case of an emergency ensure that power is disconnected.

Laser Safety Information

This unit is classified as a CLASS 1 LASER PRODUCT according to
EN60825-1 (EU) and FDA 21CFR 1040.10 (USA). Class 1 laser products
are considered safe and do not result in biological hazard if used
according to these instructions.
Instruction Manual, FS-900
Warning –indicate danger that requires proper procedures or
practices to prevent injury or death to personnel.
Cautions indicate proper procedures or practices to prevent
damage to equipment or property.
Warning –The safe operation of this product requires that a protective
earth connection be provided. A grounding conductor in the equipment's
mains supply cord provides this protective earth. To reduce the risk
of electrical shock to the operator and service personnel, this ground
conductor must be connected to an earthed ground. The mains plug shall
remain readily operable.
Warning –The apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids, such as vases,
shall be placed on the apparatus.
Warning - This symbol on the equipment indicates for use at
altitudes not exceeding 2000 m.
<2000m
Warning - Waste Electrical and Electronic Equipment Directive
(WEEE Directive) - Please contact your local authority for further
details of your nearest designated collection point. Penalties may
be applicable for incorrect disposal of this waste, in accordance
with your national legislation.
Warning – Use of controls, adjustments or performance of
procedures other than those specified herein may result in
hazardous radiation exposure.
Warning – Never look directly into the end of the optical fiber
while either end of the system is operating.
Warning – Never clean an optical fiber connector on equipment or
cable that is carrying light.
Warning – Always use dust caps on fiber optic connectors when
cables are not connected. This will protect the connector from
damage and accidental exposure of a human eye to an operating
laser.
Instruction Manual, FS-900
UNPACKING - FS-900 Triple Studio Camera Interface System
The following items listed are for a standard 3 Camera Head system. Quantities may differ dependent on amount of Camera Heads ordered:
SMPTE Option:
Qty Description
1 FS-900BS1S Base Station
(25 Pin Audio Connector included, 2 included)
3 FS-900CAM1S Camera Head
3 Return video cable 10" (MDCAB01142) *
9 Hirose Power cable (MDCAB01175) *
2 Line cord
3 Mounting Hardware Kit *
*Quantities included for standard 3 Camera Head system.

INSTALLATION INSTRUCTIONS

Base Station Unit:
When mounting the Base Station into a rack allow at least 1 RU of open space above and below it for proper cooling to occur.
Rack Mount Installation Safety Notes:
A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment
may be greater than room ambient. Therefore, consideration should be given to installing the equipment in an environment compatible with the
maximum ambient temperature (Tma) specified by the manufacturer.
B) Reduced Air Flow - Installation of the equipment in a rack should be such that the amount of air flow required for safe operation of the
equipment is not compromised.
C) Mechanical Loading - Mounting of the equipment in the rack should be such that a hazardous condition is not achieved due to uneven
mechanical loading.
D) Circuit Overloading - Consideration should be given to the connection of the equipment to the supply circuit and the effect that overloading
of the circuits might have on overcurrent protection and supply wiring. Appropriate consideration of equipment nameplate ratings should be used
when addressing this concern.
E) Reliable Earthing - Reliable earthing of rack-mounted equipment
Camera Head Unit :
JVC Camera Silverback attachment procedure instructions in the next 6 steps on the following page.
UNPACKING & INSATALLATION
Neutrik Option:
Qty Description
1 FS-900BS1N Base Station
(25 Pin Audio Connector included, 2 included)
3 FS-900CAM1N Camera Head
3 Return video cable 10" (MDCAB01142) *
9 Hirose Power cable (MDCAB01175) *
2 Line cord
3 Mounting Hardware Kit *
* Quantities included for standard 3 Camera Head system.
