ASSEMBLY
INSTRUCTIONS
Approximate Assembly Time
0.5hr
Before you start...
Please carefully unpack and lay out all of the component parts to ensure nothing
is missing and to check each component for any obvious damage.
Should you identify any concerns at this stage please contact the retailer from
whom this product was purchased. Please quote your order number, details of
your issue, the product code, and the batch number from the cartons which will
help to resolve your issue as quickly as possible.
Version Number - 1.0
Round Glass 120cm
People Required to Assemble
Tools Required
No Additional
Tools Required
Product Code - CHE101
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Julian Bowen Limited Round Glass CHE101
Summary of Contents for Julian Bowen Limited Round Glass CHE101
- Page 1 ASSEMBLY Round Glass 120cm INSTRUCTIONS Approximate Assembly Time People Required to Assemble Tools Required No Additional Tools Required 0.5hr Before you start... Please carefully unpack and lay out all of the component parts to ensure nothing is missing and to check each component for any obvious damage. Should you identify any concerns at this stage please contact the retailer from whom this product was purchased.
- Page 2 No Additional Tools Required...
- Page 3 Please check all hardware matches the list below. Should you notice any are missing please contact your retailer. T3.0mm x Ø15mm 3/8" x OD25 x T1mm 3/8"x OD14 x T8mm Bump On Flat Washer Hexagon Nut 3/8" Ring Spanner We strongly advise that you do not use Power Tools, such as drills or electric screwdrivers during the assembly as this may cause irreparable damage and will invalidate your warranty.
- Page 4 PARTS (4x) Please ensure you carefully check all the pieces, should you have any concerns please contact the retailer before assembly commences. Please have your order number, details of the issue, the product code, and the batch number from the cartons as this will help us to resolve your issue much faster.
-
Page 5: Assembly Advice
ASSEMBLY ADVICE Please take the time to carefully read through these instructions before you commence. Keep these instructions for future reference. We advise that the product is assembled in the room it is intended for. We advise that you keep the hardware in a bowl during assembly to avoid losing anything. - Page 7 180°...
-
Page 8: General Care And Maintenance
GENERAL CARE & MAINTENANCE We advise that when cleaning the product that a damp cloth is used. Avoid the use of all household cleaners and abrasive. Never push or drag the furniture. Never attempt to move the furniture when fully loaded. We advise that periodically all fixing are re-tightened.
